Squeeze & Tease

Installation Guide

V I S I O N

Vision • Squeeze & Tease Installation Guide

• Ross Part Number: 4800DR-317-03

• Release Date: December 9, 2011. Printed in Canada.

The information contained in this guide is subject to change without notice or

obligation.

Contents of this publication may not be reproduced in any form without the

written permission of Ross Video Limited. Reproduction or reverse engineering

of copyrighted software is prohibited.

Patents

This product is protected by the following US Patents: 4,205,346; 5,115,314;

5,280,346; 5,561,404; 7,034,886; 7,508,455; 7,602,446; 7,834,886. This

product is protected by the following Canadian Patents: 2039277; 1237518;

1127289. Other patents pending.

Notice

The material in this guide is furnished for informational use only. It is subject to

change without notice and should not be construed as commitment by Ross

Video Limited. Ross Video Limited assumes no responsibility or liability for

errors or inaccuracies that may appear in this guide.

Trademarks

• is a trademark of Ross Video Limited.

• Ross, ROSS, ROSS®, and MLE are registered trademarks of Ross

Video Limited.

•All other product names and any registered and unregistered

trademarks mentioned in this guide are used for identification

purposes only and remain the exclusive property of their

respective owners.

Important Regulatory and Safety Notices to Service

Personnel

Before using this product and any associated equipment, refer to the

“Important Safety Instructions” listed in the front of your Engineering

Manual to avoid personnel injury and to prevent product damage.

Product may require specific equipment, and/or installation procedures to be

carried out to satisfy certain regulatory compliance requirements. Notices have

been included in this publication to call attention to these specific requirements.

General Handling Guidelines

• Careful handling, using proper ESD precautions, must be observed.

• Power down the system before PCB removal.

ESD Susceptibility — Avoid handling the switcher circuit

boards in high static environments such as carpeted areas, and

when synthetic fiber clothing is worn. Touch the frame to

dissipate static charge before removing boards from the frame,

and exercise proper grounding precautions when working on

circuit boards.

Environmental Information

The equipment that you purchased required the extraction and use

of natural resources for its production. It may contain hazardous

substances that could impact health and the environment.

To avoid the potential release of those substances into the environment and to

diminish the need for the extraction of natural resources, Ross Video encourages

you to use the appropriate take-back systems. These systems will reuse or

recycle most of the materials from your end-of-life equipment in an

environmentally friendly and health conscious manner.

The crossed-out wheeled bin symbol invites you to use these systems.

If you need more information on the collection, reuse, and recycling systems,

please contact your local or regional waste administration.

You can also contact Ross Video for more information on the environmental

performances of our products.

4 • Package Contents

Package Contents

The contents of the Squeeze & Tease™ upgrade kit depends on the number of

Squeeze & Tease MD channels you are installing. If any items are missing, or

damaged, contact Ross Video Technical Support.

Qtya

a. The number of boards and cards in the upgrade kit depends on the num-

ber of options ordered.

Part# Item

1-3 4800AR-047A Squeeze & Tease MD Carrier Board

1-12 4800AR-048 Squeeze & Tease MD Channel Card

1-6 4800AR-049 Squeeze & Tease MD WARP Card

Squeeze & Tease Overview • 5

Squeeze & Tease Overview

The Squeeze & Tease™ MD option consists of a carrier board and a number of

daughter cards that are installed into the frame.

In order to install the Squeeze & Tease MD option, you must upgrade the

switcher software, install the daughter cards onto the Squeeze & Tease Carrier

Board, and install the Squeeze & Tease Carrier Board into the frame.

Important — Although the Squeeze & Tease Carrier Boards

are hot-swappable, any Squeeze & Tease resources on those

cards that are being used, Flying Keys for example, will be lost

when the board is removed.

The hardware for the Squeeze & Tease MD option consists at least one Squeeze

& Tease MD Carrier Board. On this Squeeze & Tease MD Carrier Board, there

are slots for 4 Squeeze & Tease MD Cards, each providing 2 channels of DVE

resources, and slots for 2 Squeeze & Tease WARP MD Cards.

The total number of Squeeze & Tease MD cards you can use depends on the

number of MLEs you have and the switcher you are installing them into. Refer

to your Vision switcher documentation for the number of Squeeze & Tease MD

and Squeeze & Tease MD WARP cards you can install for each MLE.

Note — Squeeze & Tease MD DVE channel resources are

shared between both MLEs, the MLE-Pair, on the same Video

Processor Board. If all DVE channel resources are applied to

one MLE, there will be no resources available to the other MLE

in the MLE-pair.

6 • Software Upgrade

Software Upgrade

When a new board is installed, the switcher checks the current version of

software on the board. If the software on the board is the same as the software

on the switcher, there is no change. If the board has a software version that is

different than the version on the switcher, the switcher will upgrade the board to

the same version as the switcher. For this reason, it is important that you upgrade

your switcher to the latest version of software prior to installing a new board

into the frame. Refer to your Vision switcher documentation for information on

upgrading the switcher.

S&T MD Channel Card Installation • 7

S&T MD Channel Card Installation

Use the following procedure to install a Squeeze & Tease MD Card onto the

Squeeze & Tease Carrier Board:

1. Place the Squeeze & Tease Carrier Board on a clean, static-free

surface.

2. Locate the Squeeze & Tease MD Channel Card Slot (MD Slots 1

through 4) on the Squeeze & Tease Carrier Board that you want to

install the Squeeze & Tease MD Channel Card into (Figure 1).

Refer to the following tables for information on where to install the

Squeeze & Tease MD Channel Card for your frame configuration.

Table 1 Standard QMD-X Channel Card Slots

Frame

Slot MLE Slot 4 Slot 3 Slot 2 Slot 1

8 MLE 1&2 Yes Yes Yes Yes

6 MLE 3&4 Yes Yes Yes Yes

3 MLE 5&6 Yes Yes

3 MLE 7&8 Yes Yes

Table 2 Octane Frame QMD-X Channel Card Slots

Frame

Slot MLE Slot 4 Slot 3 Slot 2 Slot 1

3 MLE 1&2 Yes Yes

3 MLE 3&4 Yes Yes

Table 3 QMD Channel Card Slots

MLE Slot 4 Slot 3 Slot 2 Slot 1

MLE 1&2 Yes Yes

MLE 3&4 Yes Yes

8 • S&T MD Channel Card Installation

Figure 1 Squeeze & Tease Carrier Board — Daughter Card Slots

3. Align the Squeeze & Tease MD Card so that the 3connectors on the

bottom of the card line up with the connectors in the Squeeze & Tease

MD Card Slot. The Retaining Screw Holes on either side of the card

will line up with the mounts on the board (Figure 2).

Figure 2 Squeeze & Tease MD Card

4. Apply firm, even, pressure to seat the card in the slot.

Caution — Do not overtighten the Retaining Screws. These

screws only need to be snug in order to secure the card in place.

5. Install the 2Retaining Screws into the Retaining Screw Mounts on

the Squeeze & Tease Carrier Board to secure the card in position.

The screws insert from the bottom of the Squeeze & Tease Carrier

Board, into the daughter card.

This completes the procedure for installing the Squeeze & Tease MD Card. Use

this same procedure to install any additional Squeeze & Tease MD Cards.

Squeeze & Tease MD Cards

Connectors

MD Slot 1

WARP Slot 1WARP Slot 2

MD Slot 2MD Slot 3MD Slot 4

Squeeze & Tease WARP

MD Card Squeeze & Tease WARP

MD Card

Retaining Screw Hole

S&T WARP MD Card Installation • 9

S&T WARP MD Card Installation

Use the following procedure to install a Squeeze & Tease MD WARP Card onto

the Squeeze & Tease Carrier Board:

1. Place the Squeeze & Tease Carrier Board on a clean, static-free

surface.

2. Locate the Squeeze & Tease WARP MD Slot (WARP Slots 1and 2)

on the Squeeze & Tease Carrier Board that you want to install the

Squeeze & Tease WARP MD Card into (Figure 3). Refer to the

following tables for information on where to install the Squeeze &

Tease WARP MD Card for your frame configuration.

Table 4 Standard QMD-X WARP Card Slots

Frame

Slot MLE Slot 2 Slot 1

8 MLE 1&2 Yes Yes

6 MLE 3&4 Yes Yes

3 MLE 5&6 Yes

3 MLE 7&8 Yes

Table 5 Octane Frame QMD-X WARP Card Slots

Frame

Slot MLE Slot 2 Slot 1

3 MLE 1&2 Yes

3 MLE 3&4 Yes

Table 6 QMD WARP Card Slots

MLE Slot 2 Slot 1

MLE 1&2 Yes

MLE 3&4 Yes

10 • S&T WARP MD Card Installation

Figure 3 Squeeze & Tease Carrier Board — Daughter Card Slots

3. Align the Squeeze & Tease WARP MD Card so that the 3

connectors on the bottom of the card line up with the connectors in the

Squeeze & Tease WARP MD Card Slot. The Retaining Screw

Holes on either side of the card will line up with the mounts on the

board (Figure 4).

Figure 4 Squeeze & Tease WARP MD Card

4. Apply firm, even, pressure to seat the card in the slot.

Caution — Do not overtighten the Retaining Screws. These

screws only need to be snug in order to secure the card in place.

5. Install the 2Retaining Screws into the Retaining Screw Mounts on

the Squeeze & Tease Carrier Board to secure the card in position.

The screws insert from the bottom of the Squeeze & Tease Carrier

Board, into the daughter card.

This completes the procedure for installing the Squeeze & Tease MD WARP

Card. Use this same procedure to install any additional Squeeze & Tease MD

WARP Cards. Next, install the Squeeze & Tease Carrier Board into the frame.

Squeeze & Tease MD Cards

Connectors

MD Slot 1

WARP Slot 1WARP Slot 2

MD Slot 2MD Slot 3MD Slot 4

Squeeze & Tease WARP

MD Card Squeeze & Tease WARP

MD Card

Retaining Screw Hole
