Dual Arm Monitor Stand for LCD/LED Displays

RHMS-11002

User Manual

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

1

IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL BEFORE USING THIS

PRODUCT

Specifications

　◆Weight capacity-DO NOT EXCEED: 9*2=18 kg (40 lbs) includes monitor and allaccessories.

　◆Minimum surface thickness: 0.6 ''. (15mm)

　◆Maximum surface thickness: 3.3 ''. (84mm)

　◆Raise/Lower: 11.8 '' (300mm)

　◆Extension: 11.8'' (300mm)

　◆Level: ±180°

　◆Swivel: ±5°

　◆Tilt: ±15°

CAUTION: Avoid potential personal injuries and property damage!

　Do not use this product for any purpose not explicitly specified by manufacturer.

　If you do not understand these instructions, or have doubts about installation, disassembly or use of this product, contact

manufacturer customer Service.

　Manufacturer is not responsible for any damage or injury caused by incorrect assembly or useage

Supplied Parts and Hardware Kit

Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the item to your dealer but

please contact Sunnyford Systems Customer Service. Never use damaged parts!

NOTE: Not all hardware included will be used.

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

2

Step 1 –Attach base assembly to desk

A : Desk Clamp 0.6＂（16mm）＜board depth <2.75＂(70mm)

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

3

B : Through-Desk 1＂(25.4mm)diameter<=2.95＂(75mm)

You need disassemble the base［02］assembly at first ,then assembling again according to the

following pic

C: Grommet Hole 2.95＂(75mm)<=hole diameter<=3.9＂(100mm)

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

4

D: Side Mount board depth >2.95＂（75mm）and no mount hole

Step 2 –Insert the mount arm[02] to base[01]

WARNING:TIGHTENING TORQUE[01-d] BEFORE INSERT THE MOUNT

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

5

Step 3 –Lcd mornitor assembling

Insert the hand screw [08],through the mount board[01-a] , into the threaded hole in the back

of the monitor and lock it.

Step 4 –Adjusted the rotating friction

As following chart ,adjusting the tightness of head,middle and base location, insert the

attached wrench [0A]into the lock screw to keep proper friction during rotation .

Dual Arm Monitor Stand for LCD/LED Displays RHMS-11002 User Manual

6

Step5 –Cables placement

Route the cables through the clip [02-b] under the arm and [01-c] on the pole

Thank you for purchasing a quality Rosewill Product.

Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
