Quick Installation Guide

00825-0100-4809, Rev DB

December 2009 Flanged 485 Annubar

Step 1: Location and Orientation

Step 2: Drill Holes into Pipe

Step 3: Assemble and Check Fit-up

Step 4: Weld Mounting Hardware

Step 5: Insert the Annubar

Step 6: Mount the Transmitter

Product Certifications

Start

End

Rosemount 485 Annubar®Flanged Assembly

0100-4809 Rev DB.fm Page 1 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009

Flanged 485 Annubar

registered trademarks of Rosemount Inc.

Rosemount Inc.

8200 Market Boulevard

Chanhassen, MN USA 55317

T (US) (800) 999-9307

T (Intnl) (952) 906-8888

F (952) 949-7001

Emerson Process Management GmbH & Co. OHG

Argelsrieder Feld 3

82234 Wessling

Germany

T 49 (8153) 9390

F49 (8153) 939172

Emerson Process Management Asia Pacific

Private Limited

1 Pandan Crescent

Singapore 128461

T (65) 6777 8211

F (65) 6777 0947/65 6777 0743

Beijing Rosemount Far East Instrument Co.,

Limited

No. 6 North Street,

Hepingli, Dong Cheng District

Beijing 100013, China

T (86) (10) 6428 2233

F (86) (10) 6422 8586

IMPORTANT NOTICE

This installation guide provides basic guidelines for Rosemount

485 Annubar. It does not provide instructions for configuration, diagnostics, maintenance,

service, troubleshooting, Explosion-proof, Flameproof, or Intrinsically Safe (I.S.)

installations. Refer to the 485 Annubar reference manual (document number

00809-0100-4810) for more instruction. This manual is also available electronically on

www.rosemount.com.

If the 485 Annubar was ordered assembled to a Rosemount 3051S transmitter, see the

following Quick Installation Guide for information on configuration and hazardous

locations certifications: Rosemount 3051S Series Pressure Transmitter (document

number 00825-0100-4801).

If the 485 Annubar was ordered assembled to a Rosemount 3095 transmitter, see the

following Quick Installation Guide for information on configuration and hazardous

locations certifications: Rosemount 3095 (document number 00825-0100-4716).

WARNING

Process leaks may cause harm or result in death. To avoid process leaks, only use

gaskets designed to seal with the corresponding flange and o-rings to seal process

connections. Flowing medium may cause the 485 Annubar assembly to become hot and

could result in burns.

CAUTION

If pipe/duct wall is less than 0.125-in. (3,2 mm) use extreme caution when installing

sensor. Thin walls can deform during welding, installation or from the weight of a

cantilevered flowmeter. These installations may require a fabricated outlet, saddle or

external flowmeter support. Please consult factory for assistance.

0100-4809 Rev DB.fm Page 2 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009 Flanged 485 Annubar

485 Annubar Flange Assembly Exploded View

NOTE

Use an appropriate pipe sealing compound rated for the service temperature on all threaded

connections.

Transmitter

Sensor Flange

Coplanar Flange with

Drain Vents

O-Rings (2)

485 Annubar Sensor

Mounting Flange Assembly

Direct Mount Transmitter

Connection with Valves

Studs

Gasket

Nuts

Opposites Side Support

Transmitter and housing

are shown for clarity

purposes – only supplied

if ordered.

0100-4809 Rev DB.fm Page 3 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009

Flanged 485 Annubar

STEP 1: LOCATION AND ORIENTATION

Correct orientation and straight run requirements must be met for accurate and repeatable

flow measurements. Refer to Table 1 for minimum pipe diameter distances from upstream

disturbances.

Table 1. Straight Run Requirements

Upstream Dimensions

Downstream

Dimensions

Without

Straightening

Vanes

With Straightening

Vanes

Plane A Out of

Plane A A’ CC’ B

—

0100-4809 Rev DB.fm Page 4 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009 Flanged 485 Annubar

STEP 1 CONTINUED...

NOTE

• Consult the factory for instructions regarding use in square or rectangular ducts.

• “In Plane A” means the sensor is in the same plane as the elbow. “Out of Plane A”

means the sensor is perpendicular to the plane of the elbow.

• If proper lengths of straight run are not available, position the mounting such that 80%

of the run is upstream and 20% is downstream.

• Use straightening vanes to reduce the required straight run length.

• Row 6 in Table 1 applies to gate, globe, plug, and other throttling valves that are

partially opened, as well as control valves.

Misalignment

485 Annubar installation allows for a maximum misalignment of 3°.

Figure 1. Misalignment

Upstream Dimensions

Downstream

Dimensions

Without

Straightening

Vanes

With Straightening

Vanes

Plane A Out of

Plane A A’ CC’ B

—

±3°

0100-4809 Rev DB.fm Page 5 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009

Flanged 485 Annubar

STEP 1 CONTINUED...

Horizontal Orientation

For proper venting and draining, the sensor should be located in the upper half of the pipe

for air and gas applications. For liquid and steam applications, the sensor should be located

in the bottom half of the pipe. The maximum temperature for a direct mounted transmitter is

500 °F (260 °C).

NOTE:

For steam applications with DP readings between 0.75 and 2 inH2O in horizontal pipes, it is

recommended to install the primary element / flowmeter mounting above the pipe.

Figure 2. Gas Figure 3. Liquid and Steam

Figure 4. Top Mounting for Steam (direct mount up

to 400 °F (205 °C))

45°45°

Recommended

Zone 90°

30° Recommended

Zone 30°

Recommended

Zone 30°

45° 45°

30° Recommended

Zone 30°

Recommended

Zone 30°

45° 45°

0100-4809 Rev DB.fm Page 6 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009 Flanged 485 Annubar

STEP 1 CONTINUED...

Vertical Orientation

The sensor can be installed in any position around the circumference of the pipe, provided

the vents are positioned properly for bleeding or venting. Optimal results for liquid or steam

are obtained when flow is up. For steam applications, a 90° spacer will be added to provide

water legs to ensure the transmitter stays within temperature limits. The maximum

temperature for a direct mounted transmitter is 500 °F (260 °C).

Figure 5. Steam Figure 6. Liquid

Figure 7. Gas

360°

Flow

360°

Flow

360°

Flow

0100-4809 Rev DB.fm Page 7 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009

Flanged 485 Annubar

STEP 2: DRILL HOLES INTO PIPE

1. Determine the sensor size based on the probe width (see Table 2).

2. Depressurize and drain the pipe.

3. Select the location to drill the hole.

4. Determine the diameter of the hole to be drilled according to the specifications in Table 2.

Drill the mounting hole into the pipe with a hole saw or drill. DO NOT TORCH CUT THE

HOLE.

Table 2. Sensor Size / Hole Diameter Chart

5. If opposite-side support model is supplied, a second identically sized hole must be drilled

opposite the first hole so that the sensor can pass completely through the pipe. (To

determine if you have an opposite-side support model, measure the distance from the tip

to the first slot or hole. If the distance is greater than 1-in. (25,4 mm), it is the

opposite-side support model.) To drill the second hole, follow these steps:

a. Measure the pipe circumference with a pipe tape, soft wire, or string. (For the most

accurate measurement the pipe tape needs to be perpendicular to the axis of flow.)

b. Divide the measured circumference by two to determine the location of the second

hole.

c. Re-wrap the pipe tape, soft wire, or string from the center of the first hole. Then, using

the number calculated in the preceding step, mark the center of what will become the

second hole.

d. Using the diameter determined in step 3, drill the hole into the pipe with a hole saw or

drill. DO NOT TORCH CUT THE HOLE.

6. Deburr the drilled holes on the inside of the pipe.

Sensor

Size Sensor Width Hole Diameter

1 0.590-in. (14.99 mm) 3/4-in. (19 mm) + 1/32-in (0,8 mm)

– 0.00

21.060-in. (26.92 mm) 15/16-in. (34 mm) + 1/16-in. (1,6 mm)

– 0.00

3 1.935-in. (49.15 mm) 21/2-in. (64 mm) + 1/16-in. (1,6 mm)

– 0.00

Drill the appropriate diameter

hole through the pipe wall.

Note: Drill the hole 180° from

the first hole for opposite- side

support models.

0100-4809 Rev DB.fm Page 8 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009 Flanged 485 Annubar

STEP 3: ASSEMBLE AND CHECK FIT-UP

For accurate measurement, use the following steps to ensure that Ports A and B are equal

distances from the inside walls of the pipe.

1. Assemble the 485 to the mounting hardware with the gaskets and bolts.

2. Hand tighten the bolts just enough to hold the position of the sensor centered in the

mounting hardware.

3. Measure the distance from the high point of the weldolet to the first sensing hole, port B,

then subtract 1/16-in (1,6 mm).

4. Measure the distance from the end of the transferred length in step 4 to the last sensing

hole, port A.

5. Compare the numbers obtained in steps 3 and 4.

Small discrepancies can be compensated for with the fit-up of the mounting hardware. Large

discrepancies may cause installation problems or error.

Figure 8. Fit-up check for 485 Annubar with Opposite-Side Support

Liquid or Steam Gas

ODF

Port B

Port A

Pipe

Outside

Diameter

The

same

within

1/8-in.

(3 mm)

The

same

within

1/8-in.(3

mm)

Pipe Outside

Diameter

Port A

Port B

ODF

0100-4809 Rev DB.fm Page 9 Wednesday, December 30, 2009 3:57 PM

Quick Installation Guide

00825-0100-4809, Rev DB

December 2009

Flanged 485 Annubar

STEP 4: WELD MOUNTING HARDWARE

1. Center the flanged assembly over the mounting hole, gap 1/16-in. (1,6 mm), and measure

the distance from the outer diameter of the pipe to the face of the flange. Compare this to

Table 3 and adjust the gap as necessary.

Table 3. Flange Sizes and ODF Per Sensor Size

2. Place four 1/4-in. (6 mm) tack welds at 90° increments. Check alignment of the mounting

both parallel and perpendicular to the axis of flow (see Figure 9). If alignment of the

mounting is within tolerances, finish weld per local codes. If alignment is outside of

specified tolerance, make adjustments prior to making the finish weld.

Figure 9. Alignment

3. If opposite-side support is being used, center the fitting for the opposite side support over

the opposite side hole, gap 1/16-in. (1,6 mm), and place four 1/4-in. (6 mm) tack welds at

90° increments. Insert the sensor into the mounting hardware. Verify that the tip of the

sensor is centered in the opposite side fitting and the plug will fit around sensor. Finish

weld per local codes. If alignment of the sensor does not allow enough clearance to

insert the opposite side plug, make the necessary adjustments prior to making the finish

weld.

4. To avoid serious burns, allow the mounting hardware to cool before continuing.

Sensor Size Flange Size ODF (in. (mm)) Size ODF (in. (mm)

1/2-in. 150# 3.88 (98.5) DN40 PN16 3.09 (78.6)

1 11/2-in. 300# 4.13 (104.9) DN40 PN40 3.21 (81.6)

1/2-in. 600# 4.44 (112.7) DN40 PN100 3.88 (98.6)

1 11/2-in. 900# 4.94 (125.4) Not Applicable Not Applicable

1/2-in. 1500# 4.94 (125.4) Not Applicable Not Applicable

1 11/2-in. 2500# 6.76 (171.6) Not Applicable Not Applicable

2 2.0-in. 150# 4.13 (104.8) DN50 PN16 3.40 (86.3)

22.0-in. 300# 4.38 (111.2) DN50 PN40 3.51 (89.3)

2 2.0-in. 600# 4.76 (120.8) DN50 PN100 4.30 (109.3)

22.0-in. 900# 5.88 (149.2) Not Applicable Not Applicable

2 2.0-in. 1500# 5.88 (149.2) Not Applicable Not Applicable

23.0-in. 2500# 9.87 (250.7) Not Applicable Not Applicable

3 3.0-in. 150# 4.63 (117.5) DN80 PN16 3.84 (97.6)

33.0-in. 300# 5.00 (126.9) DN80 PN40 4.16 (105.6)

3 3.0-in. 600# 5.38 (136.6) DN80 PN100 4.95 (125.6)

34.0-in. 900# 8.19 (208.0) Not Applicable Not Applicable

3 4.0-in. 1500# 8.56 (217.5) Not Applicable Not Applicable

34.0-in. 2500# 11.19 (284.2) Not Applicable Not Applicable

ODF

Tack Welds

0100-4809 Rev DB.fm Page 10 Wednesday, December 30, 2009 3:57 PM

Tabla de contenidos

Otros manuales de Instrumento de medición de Rosemount

Rosemount

Rosemount 8800D Series Manual de usuario

Rosemount

Rosemount TankRadar Pro Manual de lista de piezas

Rosemount

Rosemount 405 Manual de usuario

Rosemount

Rosemount 702 Manual de usuario

Rosemount

Rosemount 5708 Manual de usuario

Rosemount

Rosemount 1495 Manual de usuario

Rosemount

Rosemount Series 8700 Manual de usuario

Rosemount

Rosemount TankRadar Rex 3900 Series Guía del usuario

Rosemount

Rosemount 5081-P Manual de usuario

Rosemount

Rosemount FCL Manual de usuario

Rosemount

Rosemount 7D Manual de usuario

Rosemount

Rosemount 4500 Manual de usuario

Rosemount

Rosemount 1159 Manual de usuario

Rosemount

Rosemount SOLU COMP II Manual de usuario

Rosemount

Rosemount P330 Manual de usuario

Rosemount

Rosemount 148 Manual de usuario

Rosemount

Rosemount 8732 Series Manual de usuario

Rosemount

Rosemount 1199 Manual de usuario

Rosemount

Rosemount 1054B Manual de usuario

Rosemount

Rosemount 1151DP Manual de usuario

Rosemount

Rosemount 702 Manual de usuario

Rosemount

Rosemount 3051S Series Manual de usuario

Rosemount

Rosemount 1151 Manual de usuario

Rosemount

Rosemount 951C Manual de usuario

Manuales populares de Instrumento de medición de otras marcas

Suaoki

Suaoki D40 Manual de usuario

Elster

Elster BK-G1.6 Manual de usuario

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manual

Duratool

Duratool D03128 Manual de usuario

Vega

Vega VEGAPULS 65 Manual de usuario

Tonghui

Tonghui TH2618B Manual de usuario

Tenmars

Tenmars TM-801 Manual de usuario

MSR

MSR 145 Manual de usuario

TPS

TPS WP-82 Manual de usuario

ELMETRON

ELMETRON CP-511 Manual de usuario

PCB Piezotronics

PCB Piezotronics 003C30 Manual de usuario

Tenma

Tenma 72-10465 Manual de usuario

Endress+Hauser

Endress+Hauser Proline Promag 50 Especificaciones técnicas

Siemens

Siemens SITRANS F Coriolis FCT030 Manual de lista de piezas

KLINGER

KLINGER CMF V Series Manual de usuario

EXFO

EXFO FTB-2 Manual de operación y mantenimiento

Keysight

Keysight M8290A Manual de usuario

ADTEK

ADTEK MW-5 Manual de usuario
