ELECTRONICS

Vista Family

Rose Electronics product overview

Best and most complete low cost KVM switch family

Full range of products

2 port mini

2 and 4 port PC version

2 and 4 port PC/Apple version

4 and 8 port PC version with OSD option

350 Mhz bandwidth

Supports all keyboard modes and mouse types

Switch from front panel or keyboard

Heavy duty steel chassis with rackmount

DB25 or PC connectors

Front panel has individual switches and LEDs

Vista Mini

Rose Electronics product overview

ELECTRONICS

Low cost switch for two PCs to one KVM

Perfect for desktop in home or office

Small size .8” high by 3.2” wide by 4.2” deep

Ultra-high resolution video

Switches stereo audio with very low distortion

Available with DB25 connectors or PC connectors

Supports wheel mouse, converts PS/2 to serial mouse

Switch from keyboard or front panel

LEDs show status, power, and computer select

Steel chassis

Self powered

Vista PC 2/4

Rose Electronics product overview

ELECTRONICS

Two or four PCs to one KVM

Perfect for desktop or computer rack

Small size 1.75” high by 8.8” wide by 3.4” deep

Steel chassis is rack-mountable

Ultra-high resolution video

Available with DB25 connectors or PC connectors

Mouse type can be serial, PS/2, or PS/2 wheel

Supports wheel mouse, converts PS/2 to serial mouse

Switch from keyboard or front panel

LEDs show status, power, and computer select

Self powered

Vista PC-Apple 2/4

Rose Electronics product overview

ELECTRONICS

Two or four PC or Apples to one KVM

Perfect for desktop or computer rack

Each port programmable as PC or Apple

Small size 1.75” high by 8.8” wide by 3.4” deep

Steel chassis is rack-mountable

Ultra-high resolution video

DB25 connectors and PC keyboard only

Supports wheel mouse, converts PS/2 to serial mouse

Supports Apple power key

Switch from keyboard or front panel

LEDs show status, power, and computer select

Vista 4/8

Rose Electronics product overview

ELECTRONICS

Up to eight PCs to one KVM

Perfect for computer rack or server room

Optional OSD with security and many features

Steel chassis rack-mountable for 19”, 23” & 24” racks

Very high resolution video

Available with DB25 connectors or PC connectors

Supports wheel mouse, converts PS/2 to serial mouse

Switch from keyboard or front panel

LEDs show status, power, and computer select

Self powered or optional external power

Vista front and back

Rose Electronics product overview

ELECTRONICS

Model KVL-4PC 4-port PC connectors add /OV for OSD option

Model KVL-4U 4-port DB25 connectors add /OV for OSD option

Model KVL-8U 8-port with DB25 connectors add /OV for OSD option Model KVM-4UPM 4-port DB25 connectors for PC/Apple

Model KVM-2UPM 2-port DB25 connectors for PC/Apple

Model KVM-4UPA 4-port DB25 connectors

Model KVM-2UPA 2-port DB25 connectors

Model KVT-2PC

2-port PC connectors

with audio

Model KVM-4UPC 4-port PC connectors

Model KVT-2U

2-port DB25 connectors

with audio

Model KVM-2UPC 2-port PC connectors

Model KVL-8PC 8-port PC connectors add /OV for OSD option
