20V BRUSHLESS DRIVER HAMMER DRILL
8905K
USER MANUAL 1
TECHNICAL SPECIFICATIONS
Model 8905K Accessory
No Load Speed 0-450/0-2000 rpm Battery QTY 2
Voltage 20V Battery
capacity and
voltage
20V
2.0Ah
Impact Rate 0~30000 ipm
Max Torque 55 N.m Charger
QTY 1
Torque Setting 21+3 setting Charger
Parameter
22V
2.2A
Chuck 13mm metal single sleeve
with lock
PART LIST
Adjustable torque clutch
Keyless chuck
Work light
Power trigger
Direction button
Battery
GENERAL POWER TOOL SAFETY RULES
WARNING!
-Save all warnings and instructions for future reference.
-The term «power tool» in the warnings refers to your mains-operated
CORDLESS DRIVER DRILL
2
(corded) power tool or battery-operated (cordless) power tool.
.WORK AREA SAFETY
-Keep work area clean and well lit. Cluttered or dark areas invite accidents.
-Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases or dust. Power tools create
sparks which may ignite the dust or fumes.
-Keep children and bystanders away while operating a power tool.
Distractions can cause you to lose control.
.ELECTRICAL SAFETY
-Power tool plugs must match the outlet. Never modify the plug in any
way. Do not use any adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk of electric shock.
-Avoid body contact with earthed or grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
-Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electric shock.
-Power tool in a damp location is unavoidable, use a ground fault circuit.
Interrupter (GFCI) protected supply. Use of a GFCI reduces the risk of
electric shock.
.PERSONAL SAFETY
-Stay alert, watch what you are doing and use common sense when
operating a power tool. Do not use a power tool while you are tired or under
the influence of drugs, alcohol or medication. A moment of inattention while
operating power tools may result in serious personal injury.
-Use personal protective equipment. Always wear eye protection.
Protective equipment such as dust mask, non-skid safety shoes, hard
hat, or hearing protection used for appropriate conditions will reduce
personal injuries.
-Prevent unintentional starting. Ensure the switch is in the off-position
USER MANUAL 3
before connecting to power source and/or battery pack, picking up or
carrying the tool. Carrying power tools with your finger on the switch or
energizing power tools that have the switch on invites accidents.
-Remove any adjusting key or wrench before turning the power tool on.
A wrench or a key left attached to a rotating part of the power tool may
result in personal injury.
-Do not overreach. Keep proper footing and balance at all times. This
enables better control of the power tool in unexpected situations.
-Dress properly. Do not wear loose clothing or jewelry. Keep your hair,
clothing, and gloves away from moving parts. Loose clothes, jewelry or
long hair can be caught in moving parts.
-If devices are provided for the connection of dust extraction and
collection facilities, ensure these are connected and properly used. Use
of dust collection can reduce dust-related hazards.
.POWER TOOL USE AND CARE
-Do not force the power tool. Use the correct power tool for your
application. The correct power tool will do the job better and safer at the
rate for which it was designed.
-Do not use the power tool if the switch does not turn it on and off. Any
power tool that cannot be controlled with the switch is dangerous and
must be repaired.
-Disconnect the plug from the power source and/or the battery pack from
the power tool before making any adjustments, changing accessories,
or storing power tools. Such preventive safety measures reduce the risk
of starting the power tool accidentally.
-Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power
tool. Power tools are dangerous in the hands of untrained users.
-Maintain power tools. Check for misalignment or binding of moving
parts, breakage of parts and any other condition that may affect the
power tool’s operation. If damaged, have the power tool repaired before
use. Many accidents are caused by poorly maintained power tools.
CORDLESS DRIVER DRILL
4
-Keep cutting tools sharp and clean. Properly maintained cutting tools
with sharp cutting edges are less likely to bind and are easier to control.
-Use the power tool, accessories and tool bits etc. in accordance with
these instructions, taking into account the working conditions and the
work to be performed. Use of the power tool for operations different from
those intended could result in a hazardous situation.
.BATTERY TOOL USE AND CARE
-Recharge only with the charger specified by the manufacturer. A
charger that is suitable for one type of battery pack may create a risk of
fire when used with another battery pack.
-Use power tools only with specifically designated battery packs. Use of
any other battery packs may create a risk of injury and fire.
-When battery pack is not in use, keep it away from other metal objects,
like paper clips, coins, keys, nails, screws or other small metal objects
that can make a connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
-Under abusive conditions, liquid may be ejected from the battery; avoid
contact. If contact accidentally occurs, flush with water. If liquid contacts
eyes, additionally seek medical help. Liquid ejected from the battery
may cause irritation or burns.
.SERVICE
-Have your power tool serviced by a qualified repair person using only
identical replacement parts. This will ensure that the safety of the power
tool is maintained.
-Follow instruction for lubricating and changing accessories.
-Keep handles dry, clean and free from oil and grease.
CORDLESS DRILL/SCREW DRIVER SAFETY
WARNING!
-Hold power tool by insulated gripping surfaces, when performing an
USER MANUAL 5
operation where the fastener may contact hidden wiring or its own cord.
Fasteners contacting a «live» wire may make exposed metal parts of
the power tool live and could give the operator an electric shock.
-Always be sure you have a firm footing. Be sure no one is below when
using the tool in high locations.
-Hold the tool firmly.
-Keep hands away from rotating parts.
-Do not leave the tool running. Operate the tool only when hand-held.
-Do not touch the drill bit or the work piece immediately after operation;
they may be extremely hot and could burn your skin.
-Some material contains chemicals which may be toxic. Take caution to prevent
dust inhalation and skin contact. Follow material supplier safety data.
WARNING!
Do not let comfort or familiarity with product (gained from repeated use)
replace strict adherence to safety rules for the subject product. Misuse
or failure to follow the safety rules stated in this instruction manual may
cause serious personal injury.
IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY
CARTRIDGE
-Before using battery cartridge, read all instructions and cautionary markings
on (1) battery charger, (2) battery, and (3) product using battery.
-Do not disassemble battery cartridge.
-If operating time has become excessively shorter, stop operating
immediately. It may result in a risk of overheating, possible burns and
even an explosion.
-If electrolyte gets into your eyes, rinse them out with clear water and
seek medical attention right away. It may result in loss of your eyesight.
.DO NOT SHORT THE BATTERY CARTRIDGE
1.Do not touch the terminals with any conductive material.
2.Avoid storing battery cartridge in a container with other metal objects
CORDLESS DRIVER DRILL
6
such as nails, coins, etc.
3.Do not expose battery cartridge to water or rain. A battery short can cause
a large current flow, overheating, possible burns and even a breakdown.
-Do not store the tool and battery cartridge in locations where the
temperature may reach or exceed 500 C (1220 F).
-Do not incinerate the battery cartridge even if it is severely damaged or
is completely worn out. The battery cartridge can explode in a fire.
-Be careful not to drop or strike battery.
-Do not use a damaged battery.
TIPS FOR MAINTAINING MAXIMUM BATTERY LIFE
-Charge the battery cartridge before completely discharged. Always stop tool
operation and charge the battery cartridge when you notice less tool power.
-Never recharge a fully charged battery cartridge. Overcharging shortens
the battery service life.
-Charge the battery cartridge with room temperature at 100C - 400C
(500F - 1040F). Let a hot battery cartridge cool down before charging it.
LIGHTING UP THE FRONT LAMP
CAUTION:
Do not look in the light or see the source of light directly. Pull the switch
trigger to light up the lamp. The lamp keeps on lighting while the switch
trigger is being pulled.
Lamp
NOTE:
Use a dry cloth to wipe the dirt off the lens of lamp. Be careful not to
scratch the lens of lamp, or it may lower the illumination.
USER MANUAL 7
REVERSING SWITCH ACTION
This tool has a reversing switch to change the direction of rotation.
Depress the reversing switch lever from the Right side for clockwise
rotation or from the Left side for counterclockwise rotation. When the
reversing switch lever is in the neutral position, the switch trigger cannot
be pulled.
FUNCTIONAL DESCRIPTION
CAUTION:
Always be sure that the tool is switched off and the battery cartridge is
removed before adjusting or checking function on the tool.
INSTALLING OR REMOVING BATTERY CARTRIDGE
-To remove the battery cartridge, withdraw it from the tool while sliding
the red button on the front of the cartridge.
-To insert the battery cartridge, align the tongue on the battery cartridge
with the groove in the housing and slip it into place. Always insert it all
the way until it locks in place with a little click.
-Do not use force when inserting the battery cartridge. If the cartridge
does not slide in easily, it is not being inserted correctly.
Battery cartridge
Button
SWITCH ACTION
CAUTION:
-Before inserting the battery cartridge into the tool, always check to
CORDLESS DRIVER DRILL
8
see that the switch trigger actuates properly and returns to the «OFF»
position when released.
-Always check the direction of rotation before operation.
-Use the reversing switch only after the tool comes to a complete stop. Changing
the direction of rotation before the tool stops may damage the tool.
-When not operating the tool, always set the reversing switch lever to
the neutral position.
Switch trigger
SPEED CHANGE
To change the speed, first switch off the tool and then slide the speed
change lever to the «2» side for high speed or «1» side for low speed.
Be sure that the speed change lever is set to the correct position before
operation. Use the right speed for your job.
CAUTION:
-Always set the speed change lever fully to the correct position. If you
operate the tool with the speed change lever positioned halfway between
the «1» side and «2» side, the tool may be damaged.
-Do not use the speed change lever while the tool is running. The tool
may be damaged.
Tabla de contenidos
Otros manuales de Perforar de Ronix
Ronix
Ronix 2214 Manual de usuario
Ronix
Ronix 2110 Manual de usuario
Ronix
Ronix 2513T Manual de usuario
Ronix
Ronix 8101K Manual de usuario
Ronix
Ronix 8105K Manual de usuario
Ronix
Ronix 8900 Manual de usuario
Ronix
Ronix 2111 Manual de usuario
Ronix
Ronix RP-8812 Manual de usuario
Ronix
Ronix 2213 Manual de usuario
Ronix
Ronix 8512 Manual de usuario
Ronix
Ronix 8012 Manual de usuario
Ronix
Ronix 2221 Manual de usuario
Ronix
Ronix RS-0005 Manual de usuario
Ronix
Ronix 2210C Manual de usuario
Ronix
Ronix 2214K Manual de usuario
Ronix
Ronix 2106C Manual de usuario
Ronix
Ronix 2112 Manual de usuario
Ronix
Ronix 8612 Manual de usuario
Ronix
Ronix 2290 Manual de usuario
Ronix
Ronix 221 Series Manual de usuario
