Ronbow KEYSTONE Instrucciones de montaje

INSTALLATION AND CARE GUIDE

FIRECLAY APRON SINK

KEYSTONE

K203030-F1

CANVAS

K203730-F1

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

Tools Required

PRE-INSTALLATION

MATERIALS INCLUDED

(1) ﬁreclay kitchen sink

MATERIALS REQUIRED

(2) 2x4 cut to ﬁt in cabinet

(1) 3/4” plywood

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

INSTALLING THE SINK

Step 1: Determine the ideal location of your new

ﬁreclay kitchen sink.

Measure and cut the cabinet to ﬁt the

kitchen sink.

See Figure 1.

Figure 1.

Step 2: Cut 2 pieces of 2x4 beams to attach to

the inside of the cabinet.

Note: It is highly recommended to

secure each 2x4 beam with wood glue

and screws.

See Figure 2.

Figure 2.

NOTE: To Install ﬂush, mea-

sure the desired height of the

sink and cut the cabinet front

accordingly.

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

Step 3: Follow the directions on the back of

the wood glue and allow enough time

for it to dry.

Fasten each 2x4 beam with wood

screws.

See Figure 3.

Figure 3.

Step 4: This step is optional.

Cut and ﬁt a 3/4” thick plywood board

that sits on top of the beams.

This step is to ensure the bottom of

the sink has enough support.

Cut the area for the faucet lines and

drain / garbage disposal installation.

Secure the plywood board with wood

screws to the beams.

Verify the board is level.

See Figure 4.

Figure 4.

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

Step 5: Place the sink over the plywood.

Verify the overall appearance and

check for levelness.

See Figure 5.

Figure 5.

Step 6: Place the countertop over the cabinets

and kitchen sink.

Verify the countertop is level.

See Figure 6.

Figure 6.

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

Figure 7.

Step 1: Clean the surface of the cabinet and

sink with a damp cloth.

INSTALL THE VANITY TOP

Step 2: Verify the sink is installed properly.

Step 3: Apply a thin bead of silicone to the

surface of the cabinet and sink.

Carefully place the countertop on the

cabinets.

Clean o any excess silicone

immediately.

Verify the countertop is level.

See Figure 7.

Step 4: Follow the directions on the silicone

tube to allow for ample drying time.

Refrain from moving/using the vanity

during this time.

Step 5: Install the faucet and drain per

manufacturers instructions.

170424

ronbow.com

INSTALLATION SHEET

Model : K203030-F1

K203730-F1

KEYSTONE & CANVAS 30”

Fireclay Surfaces

The ﬁne furniture ﬁnish of your new vanity, mirror or other bathroom accessories are designed to

protect against normal home use. With proper care, your product will provide years of use and beauty

in your home.

General Care Tips

PRODUCT CARE AND MAINTENANCE

• We recommend using a soft sponge or cloth and a mild abrasive.

• To avoid water spotting, wipe down the sink bottom after use. Waxing the sink will

encourage drainage.

• Fireclay sinks from Ronbow are constructed with a durable glaze for years of beautiful

performance. On the occasion that a metal pot or pan may leave a mark on the surface

of the sink, we recommend a mild abrasive cleaner is acceptable.

• Test cleaning product on small, discrete area prior to applying to entire surface.

• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.

• Do not allow liquids and moisture to accumulate on the surface of products.

• For warranty information, please visit our website at www.ronbow.com or contact the

Customer Service Department at (510) 713-1188.

170427

40650 Encyclopedia Circle

Fremont, CA 94538

T 510.713.1188

F 510.657.9388 ronbow.com
