FS-1-WL Connection Guide

(Connect with the GX-100)

This guide shows you how to pair the FS-1-WL

wirelessly to the GX-100 using BLE MIDI.

“Pairing” involves registering the MIDI device that

you want to use (making the devices recognize each

other) with the FS-1-WL.

Pairing the FS-1-WL with another compatible

device lets you control that device via MIDI from the

FS-1-WL.

* You must update the GX-100 to Ver. 1.11 or later

to use the FS-1-WL.

https://www.boss.info/support/

What is“BLE MIDI”?

“BLE MIDI” is the technology used to transmit

and receive MIDI messages wirelessly via

Bluetooth® LE standard.

This is ocially known as “MIDI over Bluetooth Low

Energy”.

Connecting the FS-1-WL to the

GX-100

1. Turn on the GX-100 (to which the BT-DUAL is

attached) and the FS-1-WL, and place them

nearby.

2. Hold down the pairing button on the BT-DUAL

until the Bluetooth indicator blinks rapidly.

3. Press the [Bluetooth] (INSTRUMENT) button on

the FS-1-WL.

The Bluetooth indicator on the FS-1-WL blinks

white, and pairing begins.

The Bluetooth indicators on both units stop

blinking and remain lit when pairing is nished,

and now the GX-100 and FS-1-WL are paired.

If connected correctly, it will be in the following

state.

BT-DUAL Bluetooth indicator Lit blue

FS-1-WL [Bluetooth] (INSTRUMENT)

indicator Lit white

* If the devices do not pair after one minute has

passed, pairing mode is automatically canceled.

* The units automatically connect next time they

are restarted.

The FS-1-WL remembers the information

for the last Bluetooth device to which it was

connected.

When connecting to a dierent device after

connecting to the GX-100, or when turning

o the power while the Bluetooth indicator is

blinking white (not connected), or when doing

a factory reset of the FS-1-WL, the unit does not

pair automatically.

In this case, you must start from step 1 to

congure the settings.

Connecting the GX-100, FS-1-WL,

and BOSS TONE STUDIO for GX-100

at the same time

When connecting at the same time, the following

two steps are required.

STEP 1: Connect the GX-100 and the FS-1-WL

STEP 2: Connect the FS-1-WL and the BOSS TONE

STUDIO for GX-100 (iOS/Android)

1. Turn on the GX-100 (to which the BT-DUAL is

attached) and the FS-1-WL, and place them

nearby.

2. Hold down the pairing button on the BT-DUAL

until the Bluetooth indicator blinks rapidly.

3. Press the [Bluetooth] (INSTRUMENT) button on

the FS-1-WL.

The [Bluetooth] (INSTRUMENT) indicator on the

FS-1-WL blinks white, and pairing begins.

The Bluetooth indicators on both units stop

blinking and remain lit when pairing is nished,

and now the GX-100 and FS-1-WL are paired.

4. Press the [Bluetooth] (Smartphone/PC) button on

the FS-1-WL.

The unit enters pairing mode, and the

[Bluetooth] (Smartphone/PC) indicator on the

FS-1-WL blinks blue.

5. On the BOSS TONE STUDIO for GX-100 app, select

“FS-1-WL+”.

The [Bluetooth] (Smartphone/PC) indicator on

the FS-1-WL stops blinking and remains lit when

pairing is nished.

If connected correctly, it will be in the following

state.

BT-DUAL Bluetooth indicator Lit blue

FS-1-WL [Bluetooth] (INSTRUMENT)

indicator

Lit white

FS-1-WL [Bluetooth] (Smartphone/PC)

indicator

Lit blue

BOSS TONE STUDIO for GX-100

device name FS-1-WL+

The FS-1-WL remembers the information for the

last Bluetooth device to which it was connected.

When connecting to a dierent device after

connecting to the GX-100, or when turning

o the power while the Bluetooth indicator is

blinking white (not connected), or when doing

a factory reset of the FS-1-WL, the unit does not

pair automatically.

In this case, you must start from step 1 to

congure the settings.

NOTE

You cannot use the BOSS TONE STUDIO for GX-

100 and the FS-1-WL Editor at the same time.

* The GX-100 and FS-1-WL are connected

automatically next time they are restarted.

To connect the BOSS TONE STUDIO for GX-100

you must perform steps 4 and 5 each time.

* If the devices do not pair after one minute has

passed, pairing mode is automatically canceled.

GX-100 Settings

Assign the CC numbers that correspond to the

FS-1-WL in ASSIGN SETTING - SOURCE, found in the

GX-100 “CTL/EXP” settings.

The default CC numbers for the FS-1-WL are set as

shown below.

Parameter MIDI CC numbers

PEDAL L CC#80

PEDAL C CC#81

PEDAL R CC#82

EXP CC#11

CTL1 CC#85

CTL2 CC#86
