Rohnson R-1560 Manual de usuario

VACUUM CLEANER R-1560

VACUUM CLEANER

MODEL NO.: R-1560

INSTRUCTION MANUAL

VACUUM CLEANER R-1560

This appliance is intended for normal household use. Use only as described in

this manual.

Use only manufacturer recommended attachments.

Safety instructions:

⚫Check if the dust bag has been inserted correctly before you use the

appliance for the first time

⚫Never suck up water or any other liquid. Never suck up ashes until they

are cold.

⚫Don’t use the vacuum cleaner to suck up inflammables and glass or

metal splinters: Don’t suck up surface covered with plastic, cement,

stone dust or flour.

⚫Sucking up fine dust may cause the pores of the dustbag to become

clogged. This will obstruct the passage of air through the bag. If this

happens, the dustbag will have to be replaced, even if it is nout full yet.

⚫To avoid damage: Never use the vacuum cleaner without the motor

protection filter.

⚫If the apliance has breakdown. It may only be repaired by the

maintenance center. Never dismantle it by yourself blindly.

⚫If the supply cord is damaged, it must be replaced by the manufacturer

or its service agent or a similarly qualified person in order to avoid a

hazard.

⚫This appliance can be used by children aged from 8 years and above and

persons with reduced physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand

the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without

supervision.

⚫The plug must be removed from the socket-outlet befpre cleaning or

maintaining the apliance.

VACUUM CLEANER R-1560

⚫Pull out the power cord up to the yellow marker length, prohibited more

than the red mark.

PARTS DESCRIPTION

VACUUM CLEANER R-1560

Handle 9.

ON/OFF button 17.

Floor Brush

Hose connectionopening 10. Exhaust filtergrille 18. Crevice nozzle

Indicator Display 11. Cord rewindbutton 19. Cover

MIN Suction Power 12.

Mains plug 20. Dustbag holder

Middle SuctionPower 13. Clip 21. Dustbag

MAX Suction Power 14.

Hose clip 22. Front wheel

Dustbag FullIndicator 15. Hose connector 23. Clip

Speed controlknob 16. Telescopic tube

24. Rear wheel

DISPLAY PANEL

1. Min suction power

2. Middle suction power

3. Max suction power

4. Dust full indicator

How to use the appliance

⚫To connect the suction hose: insert the suction hose into the opening.

To disconnect the suction hose: press the buttons on both sides of the

suction hose and pull out the hose.

⚫To connect the suction hose: insert the suction hose into the opening.

To disconnect the suction hose: press the buttons on both sides of the

suction hose and pull out the hose.

⚫To connect the tube to the handgrip. Please connect the metal

telescopic tube to the upper side of the hose.

⚫To adjust the combi nozzle to the type of floor to be cleaned (for

carpets) or (for hard floor)

⚫To switch the appliance on: press the on/off button

VACUUM CLEANER R-1560

⚫To adjust the suction power: please turn the speed control knob

⚫To carry the appliance: lift it by the handle

Insufficient suction power?

Please check:

⚫If the dustbag is full?

⚫If the nozzle, tub or hose is blocked?

⚫To remove the obstruction, let the air flow through the hose and/or tube

in opposite direction.

Accessory

⚫Take out the accessory (combination noozle) and connect it to the

handgrip.

Storage

⚫Switch the appliance off

⚫Remove the mains plug from the wall socket

⚫Rewind the mains cord by pressing the cord rewind button

⚫Attach the lower tube to the vacuum cleaner

Cleaning the inlet spnge filter

1. Turn off and unplug cleaner.

2. Take the inner filter out.

3. Hold the protective motor filter over a dustbin.

For a rough clean, gently knock over a dustbin.

4. Insert the filter back into its position.

Clean the outer HEPA filter with the same way or replace it by following the

below procedure:

VACUUM CLEANER R-1560

⚫Remove the holder

⚫Insert the bottom edge of the new filter properly into the ridges o the holder.

⚫Close the holder by pressing it home gently. Make sure that the filter fits

completely into the holder

TECHNICAL SPECIFICATIONS

Rated voltage

220-240 V

Rated frequency

50 Hz

Nominal maximum power

650 W

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN

ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as urban

waste. It must be taken to a special local authority differentiated waste

collection centre or to a dealer providing this service. Disposing of a

household appliance separately avoids possible negative consequences for

the environment and health, deriving form inappropriate disposal and

enables the constituent materials to be recovered to obtain significant

savings in energy and resources. As a reminder of the need to dispose of

household appliances separately, the product is marked with a crossed-out

wheeled dustbin.
