Air Frame
User Manual
Manual No. AF-180709
Version: 1.0
Updated: 9, July 2018.
Air Frame Manual No. AF-180709
1
Copyright ©
All rights reserved. No part of this document may be copied, reproduced or translated. It shall not
otherwise be recorded, transmitted or stored in a retrieval system without the prior written consent of
ROE.
Warranty Policy
ROE Visual Co., Ltd. is pleased to offer a 2-year warranty on all standard products①against
manufacturers defects, covering parts and labors. ROE will provide both factory and on-site technical
support when necessary during the warranty period. Following cases are not included:
1. If replacement parts required, customers should ship defective parts at their cost. ROE will ship
replacement parts at our cost, during the warranty period.
2. In terms of customized products②and/or systems③, every order will be clearly specified in the
contract and will be handled on an individual basis.
3. After the 2-year warranty, customers should bear charges of service and/or repair in accordance with
the industrial standard.
4. The warranty will be void as follows:
(1) Accidents or human error.
(2) Any modification, disassembly, repair, maintenance or testing unauthorized by ROE.
(3) Product series number is broken, including SN, ESN, MEID, and IMEI.
(4) Gross negligence.
Notes:
①Standard products refer to products officially launched by ROE.
②Customized products refer to ROE standard products which are partially or totally designed in line
with customers’ requirements and demands.
③Customized systems refer to products with special systems required by customers.
Air Frame Manual No. AF-180709
2
Contents
1. Safety Information........................................................................................................................................ 3
2. Usage............................................................................................................................................................. 4
2.1 Frame and Bracing ................................................................................................................................ 4
2.2 Side Lock................................................................................................................................................. 6
2.3 Bottom Lock............................................................................................................................................ 7
2.4 Alternative Bracing................................................................................................................................. 8
2.5 Position Ladder....................................................................................................................................... 9
2.5.1 Bracing Position.............................................................................................................................. 9
2.5.2 Transport Position......................................................................................................................... 10
3. Stacking System......................................................................................................................................... 11
4. Rigging System........................................................................................................................................... 12
5. Safety during Cabling ................................................................................................................................ 13
6. Brackets....................................................................................................................................................... 14
6.1 Hanging Bracket................................................................................................................................... 14
6.2 Coupler Bracket.................................................................................................................................... 14
7. Dolly and Storage....................................................................................................................................... 15
8. Storage and Truck Pack............................................................................................................................ 16
9. Parts............................................................................................................................................................. 17
10. Contact Information.................................................................................................................................. 19
Air Frame Manual No. AF-180709
3
1. Safety Information
This product is for professional use only. It is not for household use.
This product presents risk of severe injury if not used in the correct way.
Before use, always visually inspect for damage. Do not use if damage is found.
Do not use any abrasive or corrosive products to clean any of the carbon parts.
Do not use any clamps on the carbon parts.
Do not use tools to open/close the locks.
Read this manual before installing or servicing this product.
Follow safety precautions listed below and observe all warnings in this manual
and printed on the product.
No magnesium alloy is used in this frame
All carbon fiber used is fire retardant.
Air Frame Manual No. AF-180709
4
2.Usage
2.1 Frame and Bracing
Open Bracing position
Total depth: 448mm
Closed Bracing position
Total depth: 120mm
Clamps are opened and closed using the red
actuator.
Arms need to be positioned according to the
desired configuration. (bracing or transport)
A transport lock is foreseen on the carbon frame
tube.
A red actuator is used to unlock.
Air Frame Manual No. AF-180709
5
To lock the bracing, move part A upwards and
rotate clockwise until part A is locked into part B.
To unlock the bracing, move part B upwards and
rotate part A counterclockwise.
Locked position
Air Frame Manual No. AF-180709
6
2.2 Side Lock
The frame can be put in a +10 / +5 / 0 / -5 / -10 degree position.
Also, any angle between +10 and -10 can be achieved by just tightening A to the correct position.
To achieve this, part Aneeds to be loosened by turning 90 degrees away from the tile.
Pull part B and position part C in the desired position. Retighten part A.
Push lever D to unlock.
Always put locking handle D and latch E in this position for transport, to prevent damage to the next tile in the
dolly.
E
D
A
B
C
Air Frame Manual No. AF-180709
7
2.3 Bottom Lock
The red levers need to be pulled backwards and moved sideways (outwards) to lock frames top to
bottom.
Make sure the red markings are not visible, otherwise frames are not locked.
Air Frame Manual No. AF-180709
8
2.4 Alternative Bracing
A keyhole lock is
provided to connect
with ROE standard
rear bridge stacking
accessory.
Placing clamps on the carbon
parts is not allowed.
To accommodate for this, a ring is
positioned on the bracing’s upright.
This ring can take standard clamps
for 48-51mm tubing.
Baby arm clamps to upright part
Air Frame Manual No. AF-180709
9
2.5 Position Ladder
2.5.1 B racing Position
Click the arm in the top slots.
Bracing ladder is placed
between frames.
To install, click ladder
clamps in
the 3 slots.
Only use the steps in the
ladder to climb the LED
wall.
