RODE Microphones M2 Manual de usuario

(EMC, LVD)

Instruction Manual

www.rodemic.com

- 2 -

Introduction

Thank you for chosing the M2 live condenser

microphone.

The M2 beneﬁts from ’s extensive experience

in crafting premium condenser microphones for

studio, live and location use and is a direct result of the

foundation set by the award winning S1.

Combining sound quality equal to that of the ﬁnest

studio microphones with features such as integrated

shock mounting to reduce handling noise and a

tailored response to reduce feedback, the M2 is a

sturdy versatile add to your live microphone kit.

Please take the time to visit www.rodemic.com and

While there you can view studio tips and techniques, as

well as browse a comprehensive range of accessories

for the M2 and other microphones.

Peter Freedman

Microphones

Sydney, Australia

- 3 -

Speciﬁcations

Acoustic

Principle:

Pressure gradient

Polar Pattern: Super-Cardioid

(see graph)

Frequency

Range:

35Hz ~ 20,000Hz

(see graph)

Output

Impedence:

50Ω

Sensitivity: -44dB ± 2 dB re 1V/Pa

(6.3mV @ 94 dB SPL) @ 1 kHz

Equivalent Noise: 23 dB SPL

(A-weighted per IEC651)

Maximum

Output:

5.2dBu

(@1kHz, 1% THD into 1KΩ

load)

Dynamic Range: 118 dB SPL

(A-weighted per IEC651)

Maximum SPL: 141dB

(@1kHz, 1% THD into 1KΩload)

Signal/Noise: 71 dB SPL

(A-weighted per IEC651)

Power

Requirement:

Phantom P48, P24

Output

Connection:

3-pin XLR

Net Weight: 308g

Dimensions: Length: 187mm

Width: 47mm

- 4 -

Speciﬁcations

Frequency Response

Polar Response

Accessories

RM1

stand mount

ZP1

zip pouch

0.0

-2.0

-4.0

-6.0

-8.0

-10.0

-12.0

-14.0

-16.0

-18.0

-20.0

-22.0

-24.0 -25.0

dB rel. 1V/Pa

+5.0

uenc

Frequency

500 Hz –

1000 Hz –

4000 Hz –

dB re 1 V/Pa

-10

-20

-30

20Hz 100 1000 10 000 20 000

- 5 -

Features

• Feedback rejecting super-cardioid pick up pattern

• Locking on/off switch

• Heavy-duty metal body

• High level of RF rejection

• Designed & manufactured in Australia

• Full 10 year guarantee*

Using the M2

• The M2 requires a power supply which for

optimum results should be a ‘P48’ standard,

48 Volt DC Supply.

Most professional mixing consoles have an internal

48 V supply; alternatively you can purchase a

separate supply. Ensure that the power supply you

use is a professional unit that is operating correctly.

Damage due to connection of the M2 to a faulty

power supply is not covered by the warranty.

• The M2 comes complete with a microphone

stand-mount (RM1). This should be used to attach

the microphone to a good quality stand.

The stand-mount includes a thread adaptor

allowing connection to either 3/8” or 5/8”

stand thread.

• Always use a high quality microphone cable and

ensure that it is wired Pin 1 screen, Pin 2 (+), Pin 3 (-).

*Online product registration required.

- 6 -

• We recommend that any connections made to the

mixer or recorder are made with the attenuation

(gain) set to OFF as well as the microphone switch

set to OFF.

• When ﬁrst switching the mixer on and when

phantom power has been applied to the M2, or

when the microphone is switched on, you should

allow several seconds for the microphone to

stabilize.

• To ensure the lowest noise/distortion your mixer

input gain control should be set so that the Peak

Program Indicator (PPI) LED ﬂashes ON during

peaks of the source (voice/instrument).

If there is no PPI, adjust the input gain while

listening for distortion of the sound. If distortion is

heard, gradually reduce the gain until it is no longer

present.

• Microphone technique, or how to get the sound

you want, requires experimentation.

We suggest that you start with the channel EQ set

to ‘OFF’ or ‘FLAT’ (no boost or cut).

you

want

requires

experimentation

We su

est that

ou start with the channel EQ set

to ‘OFF’ or ‘FLAT’ (no

oost or cut).

- 7 -

• The M2’s primary function

is a live vocal microphone.

When setting it up on

stage, make sure the

foldback monitors are

positioned as pictured in

Figure 1. This will direct

the sound to the vocalist

and towards the least

responsive section of the

M2’s pick up pattern.

• To avoid feedback and make full use of the M2’s

pick up pattern, it is best not to cup your hands

over the head of the microphone, as

shown in Figure 2.

• After use the M2 should be removed from its stand

mount, wiped with a dry, soft cloth and placed in its

protective zip pouch.

• An absorbent crystal pack is supplied with the M2.

This should stay in the zip pouch at the head of the

microphone when not in use, as condensers are

highly susceptible to moisture. When the crystals

turn pink, they can be dryed out in an oven at

100 - 150 degrees celsius for approximately ten

minutes. Once they turn blue they can be reused.

Storage

Figure 1.

Figure 2.

- 8 -

Warranty

All microphones are warranted for one year

from date of purchase. You can extend that to a full

ten years if you register online at www.rodemic.com.

The warranty covers parts and labour that may be

required to repair the microphone during the warranty

period. The warranty excludes defects caused by

normal wear and tear, modiﬁcation, shipping damage,

or failure to use the microphone as per the instruction

guide.

If you experience any problem, or have any questions

regarding your microphone, ﬁrst contact the

dealer who sold it to you. If the microphone requires a

factory authorised service, return will be organised by

that dealer.

We have an extensive distributor/dealer network, but

if you have difﬁculty getting the advice or assistance

you require, do not hesitate to contact us directly.

Microphones

International

PO Box 6685

Silverwater NSW 2128 Australia

Ph: +61 2 9648 5855

Fax: +61 2 9648 2455

USA

P.O. Box 4189

Santa Barbara, CA 93140-4189

Ph: 805 566 7777

Fax: 805 566 0071

Technical Support

For information and technical support questions contact:

support@rodemic.com

In the Unites States and Puerto Rico, contact

usasupport@rodemic.com or call 805 566 7777

In Australia, contact ozsupport@rodemic.com or call (02) 9648 5855

Anywhere except Australia, the United States and Puerto Rico,

contact support@rodemic.com or call +61 2 9648 5855
