Rocket Fish RF-BTHP01 Manual de usuario

Power/Talk

button

Microphone

LED

Speakers

Volume –

button Volume +

button

USB

port

Backward

button

Play/Pause

button

Forward

button

QUICK SETUP GUIDE

Bluetooth Stereo Headset

RF-BTHP01

Congratulations on your purchase of the Rocketﬁsh

Mobile Bluetooth Stereo Headset. Listen to music

wirelessly with Bluetooth audio devices and answer

phone calls hands-free.You can use the headset to answer

and make calls and to play music stored on your

Bluetooth-enabled device.

Features

Package contents

• Bluetooth stereo headset

• AC power adapter

• USB charging cable

• Quick Setup Guide

Turning the headset on and oﬀ

• To turn the headset on or oﬀ, press and hold

the Power button for three seconds.

Pairing the headset

1Turn oﬀ the headset, then press and hold Talk for

six seconds. Pairing mode is activated.

2On your device, select RF-BTHP01 from the list of

discovered Bluetooth devices, then enter the

password 0000 to pair the headset.

Note: After your headset has been successfully paired

with your device, the headset will automatically

connect to your device the next time the headset is

turned on.

Making phone calls

To: Do this:

Voice dial Press Talk once. (Some phones

might not support this feature.)

Redial Press Talk twice.

Answer a call Press Talk once.

End a call Press Talk once.

Refuse a call While your phone is ringing,

press Play/Pause.

Change the volume Press +or –.

Transfer a call between Double-click Talk.

connected devices

Speciﬁcations

Bluetooth version: 2.1

Supported proﬁles: A2DP, AVRCP, HFP, HSP

Frequency spectrum: 2.4~2.4835 GHz

Working distance: Maximum 33 feet (10 m)

Operating temperature: 14~140° F (-10 ~ 60° C)

Operating time: Voice: 8 hours;

Music: 7 hours

Standby time: 150 hours

Size: 5.5 × 5.4 × 1.9 inches

(141 × 138 × 50 mm)

Weight: 1.2 oz (34 g)

Average charging time: 2 hours

Notes

For speciﬁcations, legal notices, warranty, and

instructions for multiple Bluetooth pairings, see your

online User Guide.

Playing music

To: Do this:

Play/Pause Press || to launch the

phone’s MP3 player and

begin playing music.

Press || to pause and

resume playback. Press and

hold || stop playback.

Select a song Press and release  or .

Rewind or While music is playing,

fast forward a song press and hold  or .

(Some phones may not

support this feature.)

Answer a call while Press Talk, or press || to

playing music reject the call. Press Talk

again to end the call. Music

resumes playing after a call

is rejected or ended.

Change the volume Press +or –.

Using EQ sound

There are three types of EQ sound eﬀects:

• Normal (EQ oﬀ )

• Bass

• Normal

• Soft

The mode sequence is: Bass – Normal – Soft – Normal –

Bass – etc. A“beep” sound indicates each mode change.

To select a sound mode:

• While in play/pause mode, quickly press twice

|| (play/pause).

Resetting the headset

To reset your headset:

Press || (play/pause),  and  buttons at the same

time.

Headset Status LED Status

Power on Blue LED is on

Turning oﬀ Red LED dims and disappears

Low battery Red LED blinks continuously

Recharging Red LED stays on

Recharging complete Blue LED stays on

Pairing mode Blue and red LEDs ﬂash rapidly

Connection complete Blue LED blinks every

three seconds

Receiving a call Blue LED ﬂashes rapidly

Talking on the phone Blue LED brightens and

dims repeatedly

Playing music Blue LED brightens and

dims repeatedly

LED indicator messages

7601 Penn Avenue South, Richfield, MN USA 55423-3645

ENGLISH 09-0819
