Rocketfish RF-BPRACEX

AC Power Adapter

Contents

Introduction ................................................................. 2

Safety information ..................................................... 3

Features ......................................................................... 4

Using the AC power adapter.................................. 5

FAQ for Rocketfish Adapters .................................. 7

Specifications.............................................................10

Legal notices..............................................................10

Three-year limited warranty.................................13

Introduction

Thank you for purchasing a Rocketfish universal laptop

power adapter. This adapter plugs into any AC power outlet

anywhere in the world, and provides a reliable power source

to run your laptop computer and charge its internal battery.

Rocketfish adapters are made using the highest quality

components and feature all of the necessary voltage and

heat protection circuits to ensure maximum levels of safety

and efficiency.

NOTE: A physical adapter plug may be necessary to plug

into some AC power outlets outside of the United States, but

no voltage converter is needed anywhere in the world.

This adapter comes with a variety of numbered tips which

connect to the output cable of the adapter and control the

output voltage. To ensure that the proper voltage is

RF-BPRACEX 10-0806_ENG_V2.fm Page 2 Tuesday, July 27, 2010 4:08 PM

RF-BPRACEX

delivered to your laptop, you must always make sure that

you are using the correct tip for your specific laptop model.

Read the following instructions and refer to the Tip

Compatibility Guide included with this adapter to make sure

you select the correct tip for your laptop. You can also go to

the Tip Wizard at www.rocketfishproducts.com for a

complete listing of compatible models.

CAUTION: This AC power adapter is not compatible with

Mac computers.

Safety information

• Do not expose the power adapter to rain, moisture, or

excessive dust. It may cause shock hazards.

• Do not operate the adapter in direct sunlight.

• Operate the adapter in a well ventilated area. Maximum

ambient temperature around the power adapter must

not exceed 105° Fahrenheit (40° Celsius).

• Do not open the power adapter under any

circumstances. The power adapter is not intended to be

repaired in case of failure or component defect. There are

no internal serviceable parts.

• Discontinue use and contact our toll free help line for

assistance (800) 620-2790 if any of the following should

occur:

• The adapter shuts down when it is plugged into the

device (LED turns off).

• The adapter's LED light blinks when the adapter is

plugged into an AC power outlet.

• A cord or plug is damaged or frayed.

RF-BPRACEX 10-0806_ENG_V2.fm Page 3 Tuesday, July 27, 2010 4:08 PM

4Go to the Tip Wizard at www.rocketfishproducts.com

for a complete listing of compatible models.

• Do not use with notebooks that require more than

90 watts of power.

• Make sure to use the correct tip for your laptop listed in

the Tip Compatibility Guide. You can also go to the Tip

Wizard at www.rocketfishproducts.com for a complete

listing of compatible models. Do not use a tip that is not

listed for your laptop

• Keep away from children.

Features

Package contents

• 90 Watt universal laptop power adapter

•10tips

•ACcord

• Tip Compatibility Guide

• User Guide

RF-BPRACEX 10-0806_ENG_V2.fm Page 4 Tuesday, July 27, 2010 4:08 PM

RF-BPRACEX

Using the AC power adapter

To use the AC power adapter:

1Locate your laptop manufacturer and model from the

"Tip Compatibility Guide" (separate booklet), or go to

www.rocketfishproducts.com and go to RF-BPRACEX to

find the Tip Wizard.

2Identify the correct tip number for your laptop model.

CAUTION: The use of an incorrect tip may damage your

laptop. Do not use this product if you cannot locate your

laptop model in the Tip Compatibility Guide included with

this AC adapter or by using the Tip Wizard at

Input

Jack

Tip

Output cable AC adapter AC cord

power

outlet

RF-BPRACEX 10-0806_ENG_V2.fm Page 5 Tuesday, July 27, 2010 4:08 PM

6Go to the Tip Wizard at www.rocketfishproducts.com

for a complete listing of compatible models.

www.rocketfishproducts.com. If you still have questions,

contact our toll-free help line for assistance (800) 620-2790.

This AC power adapter is not compatible with Mac

computers.

NOTE: If the compatible tip for your device is not included in

the adapter package, one free tip can be ordered through

the Tip Wizard at www.rocketfishproducts.com. Simply use

the Tip Wizard to locate the manufacturer and model and

you can order your complementary tip. If you are unable to

locate your device on the Tip Wizard or need assistance

please contact Rocketfish customer service at (800)

620-2790.

3Locate the specified tip from the tip bundle provided.

Each tip is clearly numbered.

4Connect the selected tip to the end of the output cable,

making sure that the pins on the tip are aligned with the

holes in the cable. The ridge on the inside of the tip

RF-BPRACEX 10-0806_ENG_V2.fm Page 6 Tuesday, July 27, 2010 4:08 PM

RF-BPRACEX

should align with the groove in the output cable

connector. Make sure that the tip is pushed all the way

into the output cable's connector.

5Connect the AC cord to the socket on the AC adapter.

6Plug the AC cord into an AC power outlet. The LED on the

adapter turns blue indicating that the adapter is

powered and ready.

IMPORTANT: If the adapter's LED does not turn on, or if it

blinks, discontinue use and contact our toll free help line for

assistance (800) 620-2790.

7Plug the tip connected to the output cable into the DC

input jack on the side or back of your laptop. The adapter

powers the laptop and charges its battery.

FAQ for Rocketfish Adapters

What tip should I use for my laptop?

You can determine the correct tip for your laptop by

referencing the Tip Compatibility Guide included with the

adapter or by visiting the Tip Wizard at

www.rocketfishproducts.com. Locate your laptop

manufacturer and model and the correct tip will be listed.

If you cannot find your specific laptop model please contact

Rocketfish customer service at (800) 620-2790 for additional

assistance.

RF-BPRACEX 10-0806_ENG_V2.fm Page 7 Tuesday, July 27, 2010 4:08 PM

8Go to the Tip Wizard at www.rocketfishproducts.com

for a complete listing of compatible models.

My tip is not included, how do I order a new

one?

First review the included Tip Compatibility Guide to locate

the correct tip for your specific laptop. You can also go to the

Tip Wizard at www.rocketfishproducts.com for a complete

listing of compatible models. If the compatible tip for your

device is not included in the adapter package, one free tip

can be ordered through the Tip Wizard at

www.rocketfishproducts.com. Simply use the Tip Wizard to

locate your device manufacturer and model and you can

order your complimentary tip. If you are unable to locate

your device in the Tip Wizard please contact Rocketfish

customer service at (800) 620-2790.

How do I connect the tip to the adapter cable?

Once you have selected the correct tip for your laptop,

connect the tip to the output cable, making sure that the

ridge on the inside of the tip aligns properly with the groove

in the output cable connector. Additionally, the pins on the

inside of the tip should be in line with the holes in the output

cable. The tip should be pushed firmly onto the cable until

the tip and cable meet and there is no gap.

What other laptops can I use this adapter for?

The Rocketfish Universal Power Adapter is compatible with

thousands of laptop models. A complete list of compatible

laptops can be viewed through the Tip Wizard at

www.rocketfishproducts.com.

Why doesn't the tip fit into my laptop?

If the tip does not appear to fit into your laptop you may

have selected the incorrect tip for your device. The tip should

fit snugly inside the DC input jack on the side or back of your

laptop. If the tip will not fit into the jack do not force the tip.

Confirm you have selected the correct tip for your laptop by

RF-BPRACEX 10-0806_ENG_V2.fm Page 8 Tuesday, July 27, 2010 4:08 PM

RF-BPRACEX

referencing the included Tip Compatibility Guide or visiting

the Tip Wizard at www.rocketfishproducts.com. If you need

additional assistance please contact Rocketfish customer

service at (800) 620-2790.

Will using an incorrect tip damage my laptop?

The tips are designed to be used with specific laptops and so

you should only use the tip that is designated specifically for

your laptop. The correct tip can be identified by using the

online Tip Wizard at www.rocketfishproducts.com or by

locating your specific laptop in the included Tip

Compatibility Guide.

The use of an incorrect tip may cause performance issues,

including the inability to charge the internal battery or

power the laptop, or the display of an error message on the

laptop screen. It is also possible that the use of an incorrect

tip could damage your laptop. For these reasons, it is

necessary to use the tip designed specifically for your device.

The label on my Rocketfish adapter says DC

OUTPUT: 15-20V but my laptop is only 19V.

Will the adapter damage my laptop?

The 15-20V rating refers to the capability of the adapter and

it signifies that it can safely provide power to laptops with

voltages within this range. Once the correct tip has been

selected, the laptop and tip combination will output the

appropriate voltage for your laptop. Please refer to the

included Tip Compatibility Guide or online Tip Wizard at

www.rocketfishproducts.com to find the correct tip for your

laptop.

RF-BPRACEX 10-0806_ENG_V2.fm Page 9 Tuesday, July 27, 2010 4:08 PM

10 Go to the Tip Wizard at www.rocketfishproducts.com

for a complete listing of compatible models.

I notice that the adapter is warm when I use it.

Is this a problem?

During standard operation the adapter body may feel warm,

and this is normal. The adapter should always be placed in a

ventilated area in order to prevent over-heating.

How long is the cord from the wall to the

laptop?

The AC input cord is 6 feet.

If I leave the adapter plugged in when I'm not

using it does it waste energy?

This Rocketfish adapter meets EnergyStar and CEC IV energy

requirements which means it is an energy-efficient product

designed to conserve power. When the adapter is plugged in

and not being used it draws less than 0.5W of power.

Specifications

Input voltage: 100 to 240 volts AC

Output power: 90 watts continuous power

Legal notices

FCC Part 15

This device complies with Part 15 of the FCC Rules. Operation

of this product is subject to the following two conditions: (1)

this device may not cause harmful interference, and (2) this

device must accept any interference received, including

interference that may cause undesired operation.

This equipment has been tested and found to comply within

the limits for a class B digital device, pursuant to Part 15 of

the FCC Rules. These limits are designed to provide

RF-BPRACEX 10-0806_ENG_V2.fm Page 10 Tuesday, July 27, 2010 4:08 PM

Tabla de contenidos

Otros manuales de Adaptador de Rocket Fish

Rocket Fish

Rocket Fish RF-GWII008 Manual de usuario

Rocket Fish

Rocket Fish RF-MBT30 Manual de usuario

Rocket Fish

Rocket Fish RF-ACU9025 Guía de inicio rápido

Rocket Fish

Rocket Fish RF-BPRAC2 Manual de usuario

Rocket Fish

Rocket Fish RF-BSLAC Guía de inicio rápido

Rocket Fish

Rocket Fish RF-BPRAC3 Manual de usuario

Rocket Fish

Rocket Fish RF-BTAPDT RF-BTDGLE Manual de usuario

Rocket Fish

Rocket Fish RF-MRBTAD Manual de usuario

Rocket Fish

Rocket Fish RF-BPRACDC2 Manual de usuario

Rocket Fish

Rocket Fish RF-BTAPDT RF-BTDGLE Guía de inicio rápido

Rocket Fish

Rocket Fish RF-BPRAC3 Manual de usuario

Rocket Fish

Rocket Fish RF-G1179 Manual de instalación y operación

Rocket Fish

Rocket Fish RF-RBCARD Guía de inicio rápido

Rocket Fish

Rocket Fish RF-BCDM4 Manual de usuario

Rocket Fish

Rocket Fish RF-BPRACDC2 Manual de usuario

Rocket Fish

Rocket Fish RF-PCC132 Manual de instalación y operación

Rocket Fish

Rocket Fish RF-BSLAC Guía de inicio rápido

Rocket Fish

Rocket Fish RF-GWII012 Manual de instalación y operación

Rocket Fish

Rocket Fish RF-NBAC Manual de usuario

Rocket Fish

Rocket Fish RF-G1175 Manual de lista de piezas

Rocket Fish

Rocket Fish RF-NBACDC Manual de usuario

Rocket Fish

Rocket Fish RF-NBAC Manual de usuario

Rocket Fish

Rocket Fish RF-GUV1124 Manual de usuario

Rocket Fish

Rocket Fish RF-MRBTAD Guía de inicio rápido

Manuales populares de Adaptador de otras marcas

PCB Piezotronics

PCB Piezotronics 090B274 Manual de usuario

Auvidea

Auvidea J20 Manual del producto

Gossen MetraWatt

Gossen MetraWatt AT3-III E Manual de usuario

Akribis

Akribis ITF-21-BISS-MIT Manual de usuario

Tenda

Tenda W54U Manual de usuario

ROHO

ROHO AGILITY Manual de usuario

PROLiNK

PROLiNK WN2001 Manual de usuario

Hawking

Hawking HUF2 Manual de usuario

Airlink101

Airlink101 AWLC4030 Manual de usuario

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Manual de usuario

Philips

Philips SWA4554S/10 Manual de usuario

JVC

JVC TS-C9D2B Manual de instrucciones

NETGEAR

NETGEAR A6100 Manual de usuario

D-Link

D-Link DWA-121 Manual de usuario

Philips

Philips SWA2037 Manual de usuario

Basalte

Basalte 0610-20 Manual de usuario

Yealink

Yealink EHS40 Manual de usuario

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Manual de usuario
