Rocket Drones Stage 1 Kit Manual de usuario
Rocket Drones
Stage 1 Kit
Rocket Drones
Stage 1 Kit
Instruc�on Manual
TABLE OF
CONTENTS
1. Product Overview
2. Package Includes
3. Quadcopter OSD Menu Operation
3.1 Device Introduction
3.2 Device Features
3.3 Device Overview
3.4 Device Description
01
02
02
02
03
03
04
4. Launch Controller
4.1 Device Introduction
4.2 Device Features
4.3 Device Overview
4.4 Device Description
06
06
06
07
08
5. Fat shark Goggles
5.1 Device Introduction
5.2 Device Features
5.3 Device Overview
5.4 Device Description
13
13
13
13
14
7. Advanced Setting
7.1 Re-Bind for Quadcopter
7.2 Quadcopter Level Calibration
7.3 Launch Controller Calibration
7.4 Turning On/Off the Optical Flow positioning
25
25
26
27
27
6. LED Light/ Beep Status codes
6.1 Quadcopter LED light
6.2 Launch controller LED light Status and Beep codes
22
22
24
8. Supplement
8.1 Warning and Security
8.2 Precautions for Battery use and charging
8.3 After-sale service
29
9. FAQs 30
10. FCC Satement 34
29
29
30
01
1. Product Overview:
Stage 1 Drone Kit Instruction Manual
Launch Controller
Goggles
Accessories
Stage 1 Drone
02
•1 x Rocket Drone
•1 x Launch Controller
•1 x Fat Shark Scout Goggles
2. Package include:
•10 x BT2.0 450 mAh 1S Lipo Battery
• 1 x BT2.0 Battery Charger and Voltage Tester
• 1 x USB Charging Cable (Type-C)
• 1 x Type-C to FC Adapter
• 1 x Prop Removal Tool
• 4 x 31mm 4-Blade Prop (Replacement)
• 1 x Portable Storage Card
• 1 x User Manual
• 1 x Six port battery charger
Box Contents:
3.1 Device Introducon:
The Stage 1 drone is a brushless
quadcopter with a Lite 1-2S Pro
Brushless Flight Controller”
1102-18000KV brushless motors,
and 40mm 3-blade props,
which is capable of performing
diverse freestyle tricks.
3. Stage 1 rocket drone
Stage 1 Drone Kit Instruction Manual
03
3.2 Device Features:
• Self-protection
• Emergency Landing Function
• Turtle Mode
• 3 Flight modes
• Compatible with FPV Beginners
• Altitude hold Function
• Training-friendly
3.3 Device Overview:
Propellers
Camera
Stage 1 Drone Kit Instruction Manual
04
3.4 Device Descripon:
1. Quadcopter OSD Menu Operation:
The OSD menu is a set of operation interfaces designed to modify the
configuration of the quadcopter.
•Turn on/off sensor.
• Add/Remove information from the flight OSD.
2. Operation Instructions:
Setting OSD Menu:
The position of joysticks to access the OSD setting menu is as shown below. The
throttle joystick is moved to the left-center and the direction joystick towards the
upward center.
Caution: Make sure the quadcopter is disarmed before accessing the OSD menu.
After accessing the OSD menu, the pilot will see the following menu interface on
the FPV screen.
Stage 1 Drone Kit Instruction Manual
05
The OSD menu cursor can be controlled by the right joystick to operate the OSD
interface:
• Up: move the cursor up
• Down: move the cursor down
• Right: confirm/modify selection
Customizing OSD Flight information:
The information displayed in the OSD flight interface can be customized. This
information includes receiver protocol, flight mode, battery voltage, and speed
threshold.
•In the MAIN menu, select LAYOUT and enter the LAYOUT menu, as shown
below.
•Select the target information item, OFF means no display, ON means display.
•Select SAVE in the MAIN menu to save the settings and exit the OSD.
Stage 1 Drone Kit Instruction Manual
06
4.2 Device Features:
• 8 channels in total.
• USB Joystick supports most practice simulators.
• Nano module bay for external RF TX module.
• New designed joystick gimbal for longer usage life.
• Frsky protocol version for option.
•Built-in 2000mAh battery.
•USB charge supported.
4.1 Device Introducon:
The launch controller is a rcontroller designed primarily for RC models, including
multi-copters and airplanes. It gives you more than you have ever thought
possible from an entry-level 8-channel radio.
4. Launch Controller:
Stage 1 Drone Kit Instruction Manual
07
Front View:
Upper View:
Back View:
4.3 Device Overview:
LEDRing
Power Button
ThrottleJoystick DirectionJoystick
Switch A
Switch BSwitch C
Switch D
SETUP BIND
Audio Port Type -C Port
NANO Bay
NC
VCC
GND
CRSF .port
Stage 1 Drone Kit Instruction Manual
08
4.4.1 Button Functions:
There are three buttons on the Launch controller.
• Power Button: Turn the Launch controller on/off.
• BIND Button: Enter binding mode after the Launch controller is powered on.
• SETUP Button: Enter joystick calibration mode after the Launch controller is
powered on.
4.4 Device Descripon:
4.4.2 Operation Instructions:
1. Power On/Off:
• Power On: Long press the power button on the Launch controller for 3 seconds
until it beeps three times (do re mi) then release. The Launch controller LED
ring will flash red quickly, then remain blue.
• Power Off: A long press of the power button on the Launch controller will turn it
off after three beeps (mi re do).
STATE OFTHE
LED RING REASON SOLUTION
Red light solid on The throttle joystick or
switches are not in the lowest Lower throttle and switch to the lowest
position. Turn to blue then.
Red light flashing
quickly The Launch controller is
binding Wait for completing the binding
Blue light flashing
slowly The battery reaches the low
voltage limit Charge the Launch controller
Blue light flashing
slowly Charge complete
Red light breathes
slowly On charging
Stage 1 Drone Kit Instruction Manual
