RoboMaster Type A 2020 Manual de usuario

RoboMaster

Type A 2020 Self-Assembly Robot

竞赛机器人 2020 自组装版 A型

2020.11

Disclaimer

Thank you for purchasing this ROBOMASTERTM Type A 2020 Self-

Assembly Robot product. Read this disclaimer carefully before using

this product. By using this product, you hereby agree to this disclaimer

and signify that you have read it carefully. Install and use this product in

strict accordance with the document. SZ DJI TECHNOLOGY CO., LTD.

and its affiliated companies assume no liability for damages or injuries

incurred directly or indirectly from using, installing or modifying this

product improperly, including but not limited to using non-designated

accessories.

DJI™ and RoboMaster™ are trademarks or registered trademarks of SZ

DJI TECHNOLOGY CO., LTD. (abbreviated as “DJI”) and its affiliated

companies. Names of products, brands, etc. appearing in this document

are trademarks or registered trademarks of their respective owner

companies. This product and document are copyrighted by DJI with all

rights reserved. No part of this product or document shall be modified,

reproduced or transmitted in any form without the prior written consent or

authorization of DJI.

The final interpretation right of this disclaimer is reserved by DJI.

免责声明

感谢您购买 RoboMasterTM 竞赛机器人 2020 自组装版 A型。在使用之前，

请仔细阅读本声明，一旦使用，即被视为对本声明全部内容的认可和接受。

请严格遵守手册、产品说明和相关的法律法规、政策、准则安装和使用该

产品。因用户不当使用、安装、改装造成的任何损失，DJITM 将不承担法律

责任。

DJI 和RoboMaster 是深圳市大疆创新科技有限公司及其关联公司的商标。

本文出现的产品名称、品牌等，均为其所属公司的商标。本产品及手册为

关于免责声明的最终解释权，归大疆创新所有。

In the Box

Check that all of the following items are in the package before using the product. In case any item is missing, contact RoboMaster or your distributor.

物品清单

使用本产品之前，请检查产品包装内是否包含以下所有物品。若有缺失，请联系 RoboMaster 组委会或您的代理商。

RoboMaster C610 Brushless DC

Motor Speed Controller

RoboMaster C610 无刷电机调速器

RoboMaster M2006 P36 Brushless

DC Gear Motor

RoboMaster M2006 P36 直流无刷

减速电机

RoboMaster GM6020 Brushless

DC Motor

RoboMaster GM6020 直流无刷电

机

RoboMaster C620 Brushless DC

Motor Speed Controller

RoboMaster C620 无刷电机调速器

RoboMaster M3508 P19 Brushless

DC Gear Motor

RoboMaster M3508 P19 直流无刷

减速电机

RoboMaster TB47 Battery 100 W

Charger AC Cable (self-provided)

RoboMasterTB47 电池 100W 充电器

AC 线( 用户自备 )

RoboMaster 17mm Florescent

Projectile

RoboMaster 17mm 荧光弹丸

RoboMaster Robot Remote

Controller

RoboMaster 机器人专用遥控器套

装

180W Charger

180W 充电器单品

RoboMaster RFID Card

(self-provided)

RoboMaster 标签模块

(用户自备 )

×1 ×1 ×1 ×1 ×500

×1 ×4 ×2×1 ×4

RoboMaster SNAIL 2305 Brushless

DC Motor

RoboMaster SNAIL 2305 直流无刷

电机

RoboMaster C615 Brushless DC

Motor Speed Controller

RoboMaster C615 无刷电机调速器

RoboMaster Development Board

Type C

RoboMaster 开发板 C 型

RoboMaster ESC Center Board 2

RoboMaster 电调中心板 2

RoboMaster 17mm Fluorescent

Projectile Charger

RoboMaster 17mm 荧光弹丸充能装置

×1 ×2 ×2 ×1 ×1

×2×2×1 ×2×1

×4×1×1×1×1

TB47S Battery (with Battery Rack)

TB47S 电池（含电池架）

RoboMaster VTM Transmitter VT02

(self-provided)

RoboMaster 裁判系统相机图传模块

（发送端）VT02 （用户自备）

RoboMaster Referee System Main

Controller Module MC02 (self-

provided)

RoboMaster 裁判系统主控模块

MC02（用户自备）

RoboMaster Referee System RFID

Interaction Module FI02 (self-

provided)

RoboMaster 裁判系统场地交互模块

FI02（用户自备）

RoboMaster Referee System

Speed Monitor Module SM01 (self-

provided)

RoboMaster 裁判系统测速模块

SM01 （用户自备）

RoboMaster Referee System

Light Indicator Module LI01

(self-provided)

RoboMaster 裁判系统灯条模块

LI01（用户自备）

RoboMaster Mecanum Wheel (right)

RoboMaster 右旋麦克纳姆轮

RoboMaster Mecanum Wheel (left)

RoboMaster 左旋麦克纳姆轮

RoboMaster Referee System

Power Management Module

PM02 (self-provided)

RoboMaster 裁判系统电源管理模

块PM02（用户自备）

RoboMaster Referee System Armor

Module AM02 and Armor Frame

AH02 (self-provided)

RoboMaster 裁判系统装甲模块 AM02

及装甲支撑架 AH02 （用户自备）

Referee System UWB Module (self-

provided)

裁判系统 UWB 模块（用户自备）

RoboMaster Video Transmitter

Module VT12 (with adapter, self-

provided)

RoboMaster 裁判系统图传模块

VT12（含适配器，用户自备）

A-01 A-03（312）A-02

×2×1×1×12 ×4

A-04（402）A-05

×2×2

A-08A-07A-06

×1×4×2

A-13A-12A-11

×4×4×1

A-10A-09

×4×4

B-03B-02B-01

×2×1×4

A-14（245）A-15

×1×2

B-13B-12B-11（299）

×2×20 ×1

B-09 B-10

×2×14

B-08B-07B-06B-05B-04

×4×2×3×4×4

B-18

B-17

B-16（364.5）

×2×2×1

B-15

B-14（240）

×2×1

B-20B-19

×1×1

C-05C-04C-03

×1×1×2

C-02C-01

×1×1

B-23

B-22

(M3*16 Double-End Copper Pillar)

（M3*16 双头铜柱）

B-21

×1×8×1

C-10C-09C-08

×1×2×2

C-07C-06

×1×1

D-09D-08D-07

×2×1×1

D-04D-03D-02

×1×8×1

D-06D-05

×1×1

D-01C-11

×4×1

D-14D-13D-12

×1×1×1

D-11D-10

×1×1

×1×1×1×1×1

D-21

×1

D-22

×1

D-16D-15 D-17 D-18 D-19 D-20

×1

D-24

×1×1

D-23 D-25 D-26

×1×1
