ROBERTS
Please read this manual before use
DAB / DAB+ / FM / Bluetooth digital radio
Controls ..............................................................3-4
Charging your radio............................................5-6
Keylock function .................................................7-8
Display icons ......................................................7-8
Navigation.........................................................9-10
Operating your radio - DAB ............................11-12
Selecting a station - DAB................................13-14
Display options - DAB.....................................15-18
Finding new stations - DAB ............................19-20
Manual tuning - DAB ......................................23-24
Dynamic range control settings - DAB............25-26
Station order setup - DAB...............................27-28
Prune stations - DAB......................................29-30
Operating your radio - Search tuning - FM.....31-32
Manual tuning - FM.........................................33-34
Display options - FM.......................................35-36
FM stereo/mono (Earphones only).................37-38
Contents
1
Scan sensitivity setting - FM........................... 39-40
Preset stations DAB and FM ..........................41-44
Bluetooth mode .............................................. 45-46
Connecting Bluetooth devices........................47-50
Playing audio files in Bluetooth mode.............51-52
Connecting & Disconnecting Bluetooth ..........53-56
Bluetooth information......................................57-58
Clock settings .................................................59-66
Equaliser.........................................................67-72
Contrast..........................................................73-74
Software version.............................................75-76
Language........................................................77-78
System reset...................................................79-80
Earphones / Auxiliary input.............................81-82
General & Safety precautions.........................83-86
Specifications & circuit features......................87-88
Guarantee.......................................................90
2
3
Controls
1
6
2
3
4
5
11
10
9
8
1. On/Off button
2. Menu/Preset/Play/Pause button
3. Tuning Down/Previous button
4. Volume Down button
5. LCD display
6. Earphone socket (under rubber cover)
7. Loudspeaker
8. Volume Up button
9. Tuning Up/Next button
10.Select/Info/Lock button
11.Mode button
7
4
Controls
12. Auxiliary input socket (under rubber cover)
13. Antenna
14. Belt clip
15. Strap holder
16. LED charging indicator
17. Charging socket (under rubber cover)
12
13
14
15
16
17
Charging your radio
The features a built-in 1850mAh rechargeable
Lithium battery to power your radio. Before operating
the radio for the first time, ensure that you fully charge
the radio.
1. Place your radio on a flat surface. Carefully pull
back the protection cover and insert the adaptor
plug into the Charging socket marked ‘DC In’ on
the rear of your radio.
2. Plug theadaptorintoa standardmainssocketoutlet.
The radio will begin charging the built-in battery.
During this time the LED charging indicator next to
the charging socket will light brightly. Charging will
take up to 4 hours. The radio can only be charged
when the radio is switched off.
3. Charging is completed when the battery is fully
charged. The LED charging indicator will then
change from the bright level to very much dimmer
level. It will remain at the dim level while the charger
is connected to the radio and to the mains. The
battery power icon will not be displayed on the
LCD when charging.
4. Reduced power, distortion, ‘stuttering’ sounds or
the low battery power indicator are all signs that
the battery needs to be recharged.
5
Note: The mains adaptor which is supplied with your
radio is a high efficiency type, designed to minimise
energy consumption, whether the radio is playing,
charging its battery or switched off. Do not use any
other mains adaptor in place of the unit supplied.
Such use will invalidate your guarantee.
IMPORTANT: The mains adaptor is used as the means
of connecting the radio to the mains supply. The mains
socket used for the radio must remain accessible
during normal use. In order to disconnect the radio
from the mains completely, the mains adaptor should
be removed from the mains socket outlet completely.
The AC adaptor
should be
disconnected
from the mains
supply and the
radio when not
in use.
6
Note: Never use, charge or operate the radio in rainy or
moist conditions to prevent moisture entering the radio.
Keylock function
The Keylock function is used to prevent
unintentional operation of your radio.
1. When your radio is playing, press and hold the
Select / Lock button for several seconds. ‘Keys
Locked’ will show on the display.
2. This will prevent accidental operation when your
radio is being carried in a bag, pocket or when
using the belt clip. If a button is accidentally
pressed then ‘Keys Locked’ will show on the
display.
3. To disable the key lock function, press and hold
the Select / Lock button again for several seconds
until ‘Keys Unlocked’ is shown on the display.
7
Display icons
a. Radio text
b. Battery indicator
c. Signal strength indicator
d. Time (12/24 hr format)
e. AM/PM indicator
f. Preset station indicator
1,3
09:30
Keys Locked
8
09:30
DAB
Now playing: Ton
AM
P2
c d
e
09:30
Keys Unlocked
f
b
a
Navigation
This page describes the basic means of controlling
your . Instructions for each operating mode are
given in the later sections of this book.
1. Press and hold the Menu button to access the
main menus.
2. Many operations require the user to make a
selection from the menus. Press the Tuning Up
or Down buttons until the desired menu item is
displayed and then press and release the Select
button to select that item. Arrows are used to
show that there are more items in that menu.
3. If an error is made or you wish to go to the previous
screen press and release the Menu button. The
display will revert to the previous display with each
press. After a period of inactivity the display will
revert to the previous information display.
9
