Roberts Sports DAB 3 Manual de usuario
ROBERTS
Enjoy Listening
Please read this manual before use
DAB / FM personal digital radio with loudspeaker
Controls ........................................................... 3-4
Using the AC adaptor ...................................... 5-6
Keylock function .............................................. 7-8
Navigation....................................................... 9-10
Display icons ................................................. 11-12
Operating your radio - DAB ........................... 13-14
Selecting a station - DAB............................... 15-16
Display options - DAB.................................... 17-20
Signal strength display - DAB........................ 21-22
Finding new stations - DAB ........................... 23-24
Secondary services - DAB.............................25-26
Manual tuning - DAB .....................................27-28
Dynamic range control settings - DAB...........29-30
Station order setup - DAB..............................31-32
Operating your radio - Search tuning - FM....33-34
Contents
1
If you need any further advice, please call our Technical
Helpline on :- 020 8758 0338 (Mon-Fri)
Manual tuning - FM........................................ 35-36
Display options - FM...................................... 37-38
FM stereo/mono (Earphones only)................ 39-40
Scan sensitivity setting - FM.......................... 41-42
Preset stations DAB and FM ......................... 43-46
Sleep function................................................ 47-48
Contrast......................................................... 49-50
Software version............................................ 51-52
ScreenTimeOut function................................ 53-54
System reset.................................................. 55-56
Earphones ..................................................... 57-58
General.......................................................... 59-60
Specifications ......................................................61
Circuit features ....................................................61
Guarantee............................................................62
2
3
Controls
1. Loudspeaker
2. OLED display
3. Lock switch
4. Earphone socket
1
2
43
If you need any further advice, please call our Technical
Helpline on :- 020 8758 0338 (Mon-Fri) 4
5. On / Off button
6. Volume Up button
7. Volume Down button
8. Band button
5
6
7
11
12
10
9. Info button
10. Telescopic aerial
11. Jog wheel
12. Charging socket
Controls
8
9
5
Using the AC adaptor
The SportsDAB3 features a built-in 1850mAH
rechargeable Lithium battery to power your radio.
Before operating the radio for the first time, ensure
that you fully charge the radio.
1. Place your radio on a flat surface. Carefully pull
back the protection cover and insert the adaptor
plug into the Charging socket on the right hand
side of your radio.
2. Plug the adaptor into a standard 13A mains
socket outlet. If the radio is switched on the
battery indicator will become animated showing
charging in progress. Note: If charging the radio
when the radio is switched off, the battery power
icon will not show on the display.
3. The radio will begin charging the built-in battery.
Charging time will take 4 hours with the radio
switched off and 10 hours if the radio is switched
on.
4. The battery power icon will flash whilst charging
and stop flashing when the radio is fully charged.
Reduced power, distortion, 'stuttering' sounds or
the battery power indicator low are all signs that
the battery needs to be recharged.
If you need any further advice, please call our Technical
Helpline on :- 020 8758 0338 (Mon-Fri) 6
Note: The mains adaptor which is supplied with your
radio is a high efficiency type, designed to minimise
energy consumption, whether the radio is playing,
charging its battery or switched off. Do not use any
other mains adaptor in place of the unit supplied.
Such use will invalidate your guarantee.
IMPORTANT: The mains adaptor is used as the means
of connecting the radio to the mains supply.The mains
socket used for the radio must remain accessible
during normal use. In order to disconnect the radio
from the mains completely, the mains adaptor should
be removed from the mains socket outlet completely.
The AC adaptor
should be
disconnected
from the mains
supply and the
radio when not
in use.
7
Keylock function
The Keylock function is used to prevent
unintentional operation of your radio.
1. Set the Lock switch located on the top of your
radio to the 'Lock'position. The On/Off
and all other buttons will be disabled. This
will prevent accidental operation when your
radio is packed in a suitcase or travel bag. If
a button is accidentally pressed then ‘Button
Lock’ will show on the display.
2. To release the Lock switch, move the lock
switch to the 'Unlock' position.
If you need any further advice, please call our Technical
Helpline on :- 020 8758 0338 (Mon-Fri) 8
1
2
Button Lock
09:30DAB
Navigation
This page describes the basic means of controlling
your Sports DAB 3. Instructions for each operating
mode are given in the later sections of this book.
1. Press and hold in the Jog wheel to access
the main menus.
2. Many operations require the user to make
a selection from the menus. Push the Jog
wheel Up or Down to highlight the desired
menu item and then click the Jog wheel to
select that item. A scroll bar is used to show
that there are more items in that menu.
3. If an error is made or you wish to go to the
previous screen there is a ‘Back’menu item in
most menus. Push the Jog wheel Up or Down
until ‘Back’ is highlighted on the display and
click the Jog wheel to select. After a period of
inactivity the display will revert to the previous
information display.
9
