Model GD-K7D2 (24 VDC)

Sample Draw Detector

Operator’s Manual

Part Number: 71-0078RK

Revision: A

Released: 3/1/11

Model GD-K7D2 (24 VDC) Sample Draw Transmitter

WARNING

Read and understand this instruction manual before operating

detector. Improper use of the detector could result in bodily harm

or death.

Periodic calibration and maintenance of the detector is essential

for proper operation and correct readings. Please calibrate and

maintain this detector regularly! Frequency of calibration

depends upon the type of use you have and the sensor types.

Typical calibration frequencies for most applications are between

3 and 6 months, but can be required more often or less often

based on your usage.

Model GD-K7D2 (24 VDC) Sample Draw Transmitter

Product Warranty

RKI Instruments, Inc. warrants gas alarm equipment sold by us to be free from defects in

materials, workmanship, and performance for a period of one year* from the date of

shipment from RKI Instruments, Inc. Any parts found defective within that period will be

repaired or replaced, at our option, free of charge. Parts must be returned to RKI

Instruments, Inc. for repair or replacement. This warranty does not apply to those items

which by their nature are subject to deterioration or consumption in normal service, and

which must be cleaned, repaired or replaced on a routine basis. Examples of such items

are:

Warranty is voided by abuse including mechanical damage, alteration, rough handling, or

repair procedures not in accordance with instruction manual. This warranty indicates the

full extent of our liability, and we are not responsible for removal or replacement costs,

local repair costs, transportation costs, or contingent expenses incurred without our prior

approval.

THIS WARRANTY IS EXPRESSLY IN LIEU OF ANY AND ALL OTHER

WARRANTIES AND REPRESENTATIONS, EXPRESSED OR IMPLIED, AND

ALL OTHER OBLIGATIONS OR LIABILITIES ON THE PART OF RKI

INSTRUMENTS, INC. INCLUDING BUT NOT LIMITED TO, THE WARRANTY OF

MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO

EVENT SHALL RKI INSTRUMENTS, INC. BE LIABLE FOR INDIRECT,

INCIDENTAL OR CONSEQUENTIAL LOSS OR DAMAGE OF ANY KIND

CONNECTED WITH THE USE OF ITS PRODUCTS OR FAILURE OF ITS

PRODUCTS TO FUNCTION OR OPERATE PROPERLY.

This warranty covers instruments and parts sold to users only by authorized distributors,

dealers and representatives as appointed by RKI Instruments, Inc.

We do not assume indemnification for any accident or damage caused by the operation of

this gas monitor and our warranty is limited to the replacement of parts or our complete

goods. Warranty covers parts and labor performed at RKI Instruments, Inc. only, and does

not cover field labor or shipment of parts back to RKI.

a) Pump diaphragms and valves c) Batteries

b) Fuses d) Filter elements

Model GD-K7D2 (24 VDC) Sample Draw Transmitter

Table of Contents

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Cover. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Detection Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Installation Bracket. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Disassembling the GD-K7D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Mounting the GD-K7D2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Connecting Sample Lines to the GD-K7D2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Wiring the GD-K7D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Assembling the GD-K7D2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Startup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Introducing Incoming Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Setting the Zero Signal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Normal Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Low Flow Alarm. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Preventive Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Storing the GD-K7D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Replacing Components of the GD-K7D2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Calibration Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Preparing for Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Setting the Zero Reading . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Setting the Response Reading. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Model GD-K7D2 (24 VDC) Sample Draw Transmitter • 1

Overview

This manual describes the 24 VDC version of the Model GD-K7D2 sample draw 4 - 20 mA

transmitter detector head. This manual also describes how to install, start up, maintain,

and calibrate the GD-K7D2 when it is used with a gas monitoring controller. A parts list at

the end of this manual lists replacement parts and accessories for the GD-K7D2.

Specifications

Table 1 lists specifications for the 24 VDC version of the GD-K7D2.

WARNING: When using the GD-K7D2, you must follow the instructions and warnings

in this manual to assure proper and safe operation of the GD-K7D2 and to

minimize the risk of personal injury. Be sure to maintain and periodically

calibrate the GD-K7D2 as described in this manual.

Table 1: Specifications

Target Gas & Detector Range Refer to the RKI Instruments Inc. List of Detectable Gasses

Area Classification Indoor, non-hazardous locations

Sampling Method Sample-draw

Input Power 24 VDC

Signal Output 4 to 20 mA

Response Time 90% in 60 seconds

Accuracy ± 10% of reading or ± 5% of full scale (whichever is greater)

Flow Rate Approximately 0.5 liters/minute

Recommended Sample Tubing 4 mm I.D. x 6 mm O.D. Teflon PTFE

Recommended Sample Tubing Length See Table 2 in the Installation section on p. 10

2 • Model GD-K7D2 (24 VDC) Sample Draw Transmitter

Description

This section describes the components of the GD-K7D2. The GD-K7D2 consists of three

separate sections: the cover, the detection unit, and the installation bracket. The detection

unit (front section) includes the flow system and gas detection components. The L-shaped

installation bracket (rear section) includes installation components including a terminal

strip, tube fittings and a card edge connector socket.

The detection unit and installation bracket are secured together by a captive screw located

in the bottom right of the detection unit. The detection unit’s main circuit board plugs into

the socket on the installation bracket. The socket is above the terminal strip.

Figure 1: Sections of the GD-K7D2

A hydrophobic sample filter is also provided with the GD-K7D2 for installation near the

sample in fitting. The filter scrubs particulates out of the sample stream and keeps water

and many other liquids from entering the GD-K7D2 flow system.

Cover

The painted steel cover slides over both the detection unit and installation bracket. It is

radio frequency (RF)- and dust-resistant. A thumbscrew on the front of the cover near the

bottom secures the cover to the installation bracket (see Figure 1). The cover includes a

label on the front that indicates the target gas and detection range of the GD-K7D2.

Cover

Detection Unit

Installation Bracket

Model GD-K7D2 (24 VDC) Sample Draw Transmitter • 3

The flow light and flowmeter are visible through the cover. The flow rate potentiometer

(pot) is accessible through the cover.

Figure 2: GD-K7D2 Cover Components

Detection Unit

The detection unit includes the main circuit board, flowmeter, gas sensor, amplifier,

pump, and lithium battery pack.

Figure 3: Detection Unit Component Location

GAS DETECTOR MODEL GD-K7D

FLOWADJ.

Flowmeter

Flow light

Flow rate

potentiometer

ID card holder

Gas name

card holder

Thumbscrew

TP1 (+)

TP2 (+) mA

Output

Factory Adjust Pot

Gain Pot

(Factory Adjust)

Span Pot

Zero Pot

Low Flow

Sensor

Flowmeter

Factory Adjust Pot

ON/OFF Switch

Flow Rate Pot

Flow Light Lithium Battery

Pack

Gas Sensor

Sample Adapter

Sensor Retaining

Clamp

Main Circuit Board

Fuse

Captive Retaining Screw

Amplifier

Pump

Bracket

Pump

4 • Model GD-K7D2 (24 VDC) Sample Draw Transmitter

Main Circuit Board

The main circuit board includes the flow light, flow rate pot, ON/OFF switch and fuse.

The end of the board at the rear of the detection unit plugs into a socket on the installation

bracket.

Flow light

The flow light is at the top left corner of the detection unit (see Figure 2 and 3). The green

flow light is on when the GD-K7D2’s flow rate is at an acceptable flow rate. If the flow rate

drops below or rises above the acceptable flow rate, the flow light turns off.

Flow rate pot

The flow rate pot is to the right of the flow light (see Figure 2 and 3). You can adjust the

GD-K7D2’s flow rate with the flow rate pot. The pot is accessible through a hole in the

cover.

ON/OFF switch

The ON/OFF switch is to the right of the flow rate pot (see Figure 3). The On/Off switch

turns the GD-K7D2 on and off. The switch is in the ON position when the toggle switch is

in the right position.

Fuse

A 2 amp, 5 mm x 20 mm fuse is located on the middle left of the main board. It is

accessible by removing four screws that retain a metal cover over the main board.

Flowmeter

The flowmeter is below the flow light (see Figure 2 and 3). A ball in the flowmeter column

indicates the flow rate of the GD-K7D2. Two horizontal lines on the flowmeter mark the

acceptable flow rate for the GD-K7D2. Use the flow rate pot to keep the flowmeter ball

between the two lines. A flow sensor at the bottom of the flowmeter senses when the

flowmeter ball is low enough to be at the bottom of the flowmeter and initiates a low flow

alarm.

Gas Sensor

The gas sensor is below and to the right of the flowmeter (see Figure 3). Through a series

of electrical and chemical reactions, the gas sensor produces an electrical current that is

proportional to the detection range of the target gas in the test sample. Electrodes within

the gas sensor housing are surrounded by liquid electrolyte. The chemical and electrical

reactions are facilitated by the electrolyte.

A sample adapter is attached to the front of the sensor. It directs the sample over a gas

permeable membrane on the front of the sensor and into the sensor.

Amplifier

The amplifier is to the right of the sensor (see Figure 3). The amplifier converts the output

of the sensor to a 4 to 20 mA signal (that is proportional to the detection range of the GD-

K7D2) and transmits the signal to a controller. The amplifier includes the span pot, zero

pot, gain pot, and output check pins.

Span pot

The span pot is at the top of the amplifier. Use the span pot to adjust the GD-K7D2’s

response output during the calibration procedure.

Zero pot

The zero pot is below the span pot. Use the zero pot to adjust the GD-K7D2’s fresh air

Model GD-K7D2 (24 VDC) Sample Draw Transmitter • 5

output during start-up and calibration procedures.

Gain pot

The gain pot is below the zero pot. It is used to make coarse span adjustments. The gain

pot is factory set and for adjustment by a field service technician only.

Another factory adjust pot is located below the gain pot. Do not adjust this pot.

Output check pins

Two output check pins [marked 1 (+) and 2 (-)] are below the pots. Use the output check

pins to read the signal output of the GD-K7D2 with a milliampmeter during the start-up

and calibration procedures.

Pump

The pump is behind the sensor. The pump pulls the test sample into the GD-K7D2. The

pump operates on AC voltage that is generated by the GD-K7D2 from the 24 VDC input

power.

Lithium Battery Pack

A 3.6 volt lithium battery pack is above the pump on the right side of the GD-K7D2. The

lithium battery pack maintains a bias voltage on the gas sensor when the GD-K7D2 is not

receiving incoming power, such as during shipment or storage. If the GD-K7D2 is off

power for an extended period and the lithium battery pack is dead, the gas sensor

operation will be affected when the GD-K7D2 is started up. See Storing the GD-K7D2 in

the Maintenance section for battery pack replacement recommendations.

Installation Bracket

The L-shaped installation bracket facilitates mounting and wiring of the GD-K7D2. The

three mounting holes on the back of the bracket are used to mount it to a vertical surface.

The installation bracket includes the socket, external wiring terminal strip, cable bushing,

and sample fittings.

Figure 4: Installation Bracket Component Location

Socket for

Main Board

External Wiring

Terminal Strip

Mounting Holes

Cable Bushing

Gas In

Sample Fitting

Gas Out

SampleFitting

Factory Installed

Jumper*

*Jumper is factory installed when

GD-K7D2 is used with a controller

that does not have a built in flow

alarm circuit and flow alarm

wiring terminals.

6 • Model GD-K7D2 (24 VDC) Sample Draw Transmitter

Socket

A card edge connector socket on the back of the bracket mates with the main circuit board

on the detection unit.

External Wiring Terminal Strip

A seven point terminal strip is located below the socket and used for wiring the GD-K7D2

to a controller.

A jumper is normally factory installed between the second and third terminals from the

right. This jumper is installed when the GD-K7D2 is used with a controller that does not

have a flow alarm circuit and flow alarm terminals for wiring to the GD-K7D2. It is not

installed when the GD-K7D2 is used with a controller that has flow alarm circuitry and

flow alarm terminals. See Wiring the GD-K7D2 to a Controller in the Installation section

for both types of wiring.

Cable Bushing

The 1/2 in. (1.25 cm) cable bushing on the bottom of the bracket allows you to route

wiring from a controller to the seven point external wiring terminal strip on the back of

the bracket.

Gas In & Gas Out Sample Fittings

There are two tube fittings on the bottom of the bracket, the gas in and gas out sample

fittings. The gas in fitting is forward of the gas out fitting. The gas in fitting allows sample

to enter the GD-K7D2 and the gas out fitting is for exhausting the sample. Both fittings

accept 6 mm O.D. x 4 mm I.D. Teflon PTFE tubing.

Otros manuales para GD-K7D2

Tabla de contenidos

Otros manuales de Sensor de seguridad de RKI Instruments

RKI Instruments

RKI Instruments 35-3010RKA-03 Manual de usuario

RKI Instruments

RKI Instruments 65-2494RK Manual de usuario

RKI Instruments

RKI Instruments 35-3001-01H-DIL Manual de usuario

RKI Instruments

RKI Instruments 35-3001-13 Series Manual de usuario

RKI Instruments

RKI Instruments 65-2427RK-05 Manual de usuario

RKI Instruments

RKI Instruments 65-2495RK Manual de usuario

RKI Instruments

RKI Instruments 65-2515RK Manual de usuario

RKI Instruments

RKI Instruments 35-3001A-12-02 Manual de usuario

RKI Instruments

RKI Instruments 61-1001RKSS Manual de usuario

RKI Instruments

RKI Instruments 35-3001A-01H Manual de usuario

RKI Instruments

RKI Instruments 65-2301RKSS Series Manual de usuario

RKI Instruments

RKI Instruments 35-3001-06H-DIL Manual de usuario

RKI Instruments

RKI Instruments 35-3001-05 Series Manual de usuario

RKI Instruments

RKI Instruments 35-3001A-01 Manual de usuario

RKI Instruments

RKI Instruments 71-0288RK Manual de usuario

RKI Instruments

RKI Instruments 65-2427-05-01 Manual de usuario

RKI Instruments

RKI Instruments 35-3001-05-03 Manual de usuario

RKI Instruments

RKI Instruments 35-3001A-07-03 Manual de usuario

RKI Instruments

RKI Instruments 35-3010RK-04 Manual de usuario

RKI Instruments

RKI Instruments 65-2428 Manual de usuario

RKI Instruments

RKI Instruments 82-5221 Manual de usuario

RKI Instruments

RKI Instruments 35-3010RK-06-02 Manual de usuario

RKI Instruments

RKI Instruments 65-2423RK-05 Manual de usuario

RKI Instruments

RKI Instruments Eagle Series Manual de usuario

Manuales populares de Sensor de seguridad de otras marcas

THORLABS

THORLABS PDA10JT Manual de usuario

Waeco

Waeco UV-DETECT Manual de usuario

Intermatic

Intermatic IOS-DSIMF Manual de usuario

urmet domus

urmet domus 1083 Manual de usuario

Siemens

Siemens AZL66 Series Manual de usuario

BTI

BTI Profiline Multi Finder Manual de usuario

Challenger

Challenger SL01 Manual de usuario

DMP Electronics

DMP Electronics 1122INT Manual de usuario

Rielta

Rielta Ladoga MK-RK Manual de usuario

Mirion Technologies

Mirion Technologies ACCURAD PRD Manual de usuario

Bosch

Bosch DS835 Manual de usuario

DBI SALA

DBI SALA EZ Stop Manual del operador

Lamptime

Lamptime ST05C Manual de usuario

Ubiquiti

Ubiquiti MFI-MSC Manual de usuario

Subsite

Subsite 910R Instrucciones de instalación

Satel

Satel OPAL Pro Manual de usuario

Aleph

Aleph XC-1XTEU Manual de usuario

Pima

Pima LARIS QUAD Manual de usuario
