Instruction Manual

Eagle Series

Portable Multi-Gas Detector

Part Number: 71-0028RK

Edition: Third

Released: July 2001

Warranty Eagle Instruction Manual

Warranty

RKI Instruments, Inc., warranties gas alarm equipment manufactured

by RKI and sold by RKI to be free from defects in materials and

workmanship for a period of one year from date of shipment from

RKI Instruments, Inc. Any parts found defective within that period

will be repaired or replaced, at our option, free of charge. This

warranty does not apply to items that are subject to deterioration or

consumption in normal service, and which must be cleaned, repaired,

or replaced routinely. Those items include, but are not limited to:

This warranty is voided by mechanical damage, misuse, alteration,

rough handling, or repairs not in accordance with the operator’s

manual. This warranty indicates the full extent of our liability. We are

not responsible for removal or replacement costs, local repair costs,

transportation costs, or contingent expenses incurred without our

prior approval.

THIS WARRANTY IS IN LIEU OF ANY OTHER WARRANTIES AND

REPRESENTATIONS, EXPRESSED OR IMPLIED, AND ALL OTHER OBLIGATIONS

OR LIABILITIES ON THE PART OF RKI INSTRUMENTS, INC., INCLUDING BUT

NOT LIMITED TO THE WARRANTY OF MERCHANTABILITY OR FITNESS FOR A

PARTICULAR PURPOSE. INNO EVENT SHALL RKI INSTRUMENTS, INC., BE

LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL LOSS OR DAMAGE

OF ANY KIND CONNECTED WITH THE USE OF ITS PRODUCTS OR FAILURE OF

ITS PRODUCTS TO FUNCTION OR OPERATE PROPERLY.

This warranty covers instruments and parts sold to end users by

authorized distributors, dealers, and representatives of RKI

Instruments, Inc.

We do not assume indemniﬁcation for any accident or damage caused

by the operation of this gas monitor. Our warranty is limited to

replacement of parts or our complete goods.

absorbent cartridges ﬁlter elements

pump diaphragms and valves batteries

lamp bulbs and fuses

Eagle Instruction Manual Table of Contents

Table of Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

About this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Speciﬁcations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Case. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Alarm Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Battery Charger Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Interface Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Buzzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Sample-Drawing System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Circuit Boards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Methane Elimination Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

CAL/SETUP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Starting Up the Eagle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Normal Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Monitoring Combustible Gas in the PPM Range. . . . . . . . . . . . . . . . . 11

Monitoring Combustible Gases Other than Methane . . . . . . . . . . . . . 12

Setting User Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Turning Off the Eagle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Alarm Indications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Resetting Gas Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Table of Contents Eagle Instruction Manual

Display Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

User and Station ID Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Peak Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Elapsed Time Screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

TWA/STEL Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Battery Voltage Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Date/Time Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Clear Data Logger Screens. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Remaining Log Time Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Tips for Using Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Entering Setup Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Updating the Battery Type Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Updating Channel Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Updating the Combustible Gas Channel’s Units of Measure. . . . . . . 31

Updating the Alarm Point Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Updating the Eagle’s Serial Number . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Updating the Lunch Break Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

Updating the Alarm Latching Setting . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Updating the Alarm Silence Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Turning the User ID Function On or Off . . . . . . . . . . . . . . . . . . . . . . . . 35

Updating the Auto Calibration Settings . . . . . . . . . . . . . . . . . . . . . . . . 35

Updating the Back Light Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

Turning the Auto Fresh Air Function On or Off. . . . . . . . . . . . . . . . . . 36

Updating the Interval Time Setting (data log option) . . . . . . . . . . . . . 37

Updating the Log Data Over Write Setting (data log option) . . . . . . 37

Updating the Time Calibration Setting (data log option). . . . . . . . . . 38

Updating the Date and Time Settings (data log option) . . . . . . . . . . . 38

Updating the Zero Following Settings. . . . . . . . . . . . . . . . . . . . . . . . . . 39

Updating the Conﬁrmation Beep Setting . . . . . . . . . . . . . . . . . . . . . . . 39

Returning to Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Eagle Instruction Manual Table of Contents

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41

Calibration Supplies and Equipment. . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Preparing for Calibration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Calibrating the Eagle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42

Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46

Displaying the Battery Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Replacing Alkaline Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Recharging Ni-Cd Batteries. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Replacing Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47

Appendix A: Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50

Appendix B: Methane Elimination . . . . . . . . . . . . . . . . . . . . . . . . .52

Appendix C: Non-Standard Toxic Gas Sensors. . . . . . . . . . . . . . .54

Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Calibrating Non-Standard Toxic Gas Sensors. . . . . . . . . . . . . . . . . . . . 55

Replacing Non-Standard Toxic Gas Sensors. . . . . . . . . . . . . . . . . . . . . 57

Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Appendix D: Carbon Dioxide Sensors . . . . . . . . . . . . . . . . . . . . . .59

Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59

Normal Operation of Carbon Dioxide Sensors. . . . . . . . . . . . . . . . . . . 60

Demand Zero for Carbon Dioxide Sensors. . . . . . . . . . . . . . . . . . . . . . 60

Calibrating Carbon Dioxide Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Replacing Carbon Dioxide Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Appendix E: Infrared Methane Sensors . . . . . . . . . . . . . . . . . . . . .64

Target Gases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Speciﬁcations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Calibrating Infrared Methane Sensors. . . . . . . . . . . . . . . . . . . . . . . . . . 65

Replacing Infrared Methane Sensors . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Table of Contents Eagle Instruction Manual

Appendix F: Eagle Tank Tester Model . . . . . . . . . . . . . . . . . . . . . .67

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69

Appendix G: Five-Gas and Six-Gas Models . . . . . . . . . . . . . . . . .70

Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Displaying Additional Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Calibration, Display, and Setup Modes . . . . . . . . . . . . . . . . . . . . . . . . . 71

Appendix H: Eagle Transformer Gas Tester. . . . . . . . . . . . . . . . . .72

Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Alarms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Appendix I: Installing the Data Logger Board . . . . . . . . . . . . . . .74

Eagle Instruction Manual Introduction • 1

Introduction

Overview

The RKI Eagle is the most advanced portable gas detection system

available. The Eagle is built for rugged reliability and ease of use and

includes the latest innovations in gas detection technology:

• Simultaneous detection of one to six gases. Standard target gases

include combustible gas (% LEL and ppm), oxygen deﬁciency,

carbon monoxide, and hydrogen sulﬁde.

• Powerful sample-drawing pump with up to 100-foot range.

• Dot-matrix liquid crystal display (LCD) for complete,

understandable information at a glance.

• Microprocessor control for all functions, including data logging

and user-adjustable alarms.

•Visible and audible alarms for hazardous conditions and

malfunctions.

•UL and CSA classiﬁed. Intrinsic safety for Class I, Division I,

Groups A, B, C, and D hazardous atmospheres (standard 4-gas

model and non-standard toxic gas versions). Consult RKI

Instrument, Inc., for classiﬁcation of other Eagle versions.

•Tough case with a balanced, light-weight design.

WARNING: The Eagle detects a combination of combustible gas,

oxygen deﬁciency, hydrogen sulﬁde and carbon

monoxide, or other toxic gases which can be lethal. Users

must follow the instructions and warnings in this

manual to assure proper and safe operation of the Eagle.

2 • Introduction Eagle Instruction Manual

About this Manual

This manual is intended for use with all Eagle models. Examples used

in this manual are for the standard four-gas model (combustible gas,

oxygen, carbon monoxide, and hydrogen sulﬁde). Differences

between the standard four-gas model and other Eagle models are

noted where applicable. This manual is organized as follows:

• The standard sections included in pages 1 through 49 describe the

Eagle’s speciﬁcations and internal and external components. These

sections also describe the operation, calibration, and maintenance

of the Eagle.

•Appendix A lists part numbers for the Eagle’s replacement parts

and accessories.

• Appendix B describes the Eagle’s methane elimination feature.

• Appendices C through E describe the Eagle’s non-standard

sensors.

• Appendix F describes the Eagle tank tester model.

• Appendix G describes the Eagles’s ﬁve- and six-gas models.

• Appendix H describes the procedure to install the Eagle’s optional

Data Logger board.

Eagle Instruction Manual Specifications • 3

Speciﬁcations

Table 1 lists physical and environmental speciﬁcations for the Eagle.

Table 2 lists speciﬁcations for the Eagle’s standard sensors.

Table 1: Eagle Speciﬁcations

Target Gases1Combustible gas; Oxygen (O2),

Carbon monoxide (CO); Hydrogen sulﬁde (H2S)

Case High-impact polycarbonate-polyester blend

Safety/Regulatory2CSA/NTRL and UL classiﬁed intrinsically safe

(Class I, Division 1, Groups A, B, C, and D)

Dimensions 10.5 in. x 5.9 in. x 7.0 in. (26.7 cm x 15.0 cm x 17.8 cm)

Weight 5 lbs. (2.25 kg)

Power Four D-size batteries (alkaline or Ni-Cd)

Continuous Operating

Hours Alkaline: 30 hours (minimum)

Ni-Cd: 18 hours (minimum)3

Operating Temperature 14°F to 104°F (-10°C to 40°C)

Humidity 0 to 95% (non-condensing)

Standard Accessories Shoulder strap; alkaline batteries; hydrophobic probe;

5-foot hose

Optional Accessories Ni-Cd batteries; battery charger (115 VAC);

continuous operation adapter (115 VAC or 12 VDC);

dilution ﬁtting (1:1 or 3:1); remote alarm; data logger

1Appendices C, D, and E describe the Eagle’s non-standard sensors.

2Consult RKI Instruments, Inc., for regulatory classiﬁcations of versions other than the standard 4-gas

and non-standard toxic gas versions.

3Based on RKI part number 49-1240RK.

4 • Specifications Eagle Instruction Manual

Table 2 lists speciﬁcations for the Eagle’s standard sensors. Your Eagle

model may not include all of the sensors listed below. The alarm

settings are user-adjustable (see “Updating the Alarm Point Settings”

on page 32.)

Table 2: Standard Sensor Speciﬁcations

Combustible

Gas (%LEL1)Combustible

Gas (PPM2)Oxygen Hydrogen

Sulﬁde Carbon

Monoxide

Range 0 to 100% LEL Depends on

target gas40 to 40% O20 to 100

ppm 0 to 500

ppm

Alarm 1 10% LEL 5000 ppm 19.5% O2

(decreasing) 10.0 ppm 25 ppm

Alarm 2 50% LEL 25,000 ppm 23.5% O2

(increasing) 30.0 ppm 50 ppm

TWA Alarm N/A N/A N/A 10.0 ppm 25 ppm

STEL Alarm N/A N/A N/A 15.0 ppm 400 ppm

Detection

Principle Catalytic

combustion Catalytic

combustion Electro-

chemical Electro-

chemical

Response Time

(to 90%)530 seconds 30 seconds 30 seconds 30 seconds 30 seconds

Accuracy

(of fullscale) ± 5% ± 5% ± 5% ± 5% ± 5%

1LEL (Lower Explosive Limit)

2PPM (Parts Per Million)

3Alarms settings are user adjustable. See “Updating the Alarm Point Settings” on page 32.

4The PPM range represents the same range as 0 to 100% LEL for that gas. For example, 100% LEL for methane

= 5% by volume = 50,000 PPM. Therefore, the PPM range for methane is 0 to 50,000.

5With the Eagle’s standard hose and probe attached.
