Rivers Edge LOCKDOWN Manual de usuario
Get parts online at
www.HuntRiversEdge.com
PARTICIPATING MEMBER
PRODUCT MEETS
INDUSTRY STANDARDS
RECOGNIZED BY
P/N: 42847
C/N: 42859
REV2: 03/21/2023
© 2022 RETI
All Rights Reserved
Operator's Manual
MODEL LD204
LOCKDOWN
21’ 360 1-MAN
Ladder Stand
Maximum Height
21’1” to shooting rail
Wear Your
Harness!
Maximum Field Rating
300 lbs
Tree Diameter Range
12” to 30”
PAT. WWW.ARDISAM.COM/PATENTS
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007
2
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
INTRODUCTION
Rivers Edge® Treestands are engineered with you the hunter in mind. We appreciate your purchase of one of our world class
treestands. Follow these few simple instructions and your stand will provide you many years of trouble-free pleasure. Instructions
should be kept in a safe place and reviewed at least annually.
If for any reason you have a problem with your product or are missing any parts, DO NOT return to the retailer, contact Rivers
Edge® Customer Service Department at 800-345-6007 for assistance.
CONTENTS
Introduction/Warranty ..................................................................................................................................................................................................................2
Warnings.........................................................................................................................................................................................................................................3-4
Inspection and Maintenance ......................................................................................................................................................................................................4
Hardware Identication Chart................................................................................................................................................................................................5-6
Assembly Instructions ............................................................................................................................................................................................................ 7-16
Warnings.......................................................................................................................................................................................................................................... 17
Setup and Use Instructions.................................................................................................................................................................................................18-24
Finished Ladder............................................................................................................................................................................................................................. 25
Illustrated Parts Breakdown................................................................................................................................................................................................26-28
Notes................................................................................................................................................................................................................................................. 29
WARRANTY
RETI oers a one-year warranty for all components of the treestand. These warranties apply to the original owner with a proof of purchase. These warranties
begin on the date of purchase by the rst retail consumer and continue for the period specied above. These warranties apply to products that are not modied,
abused or used in a manner that deviates from the product’s intended usage. Minor fading in color is normal and is not covered by warranty. Any corrosion
of painted surfaces that occurs as a result of paint being removed or damaged is also not covered by warranty. RETI oers no other warranty expressed or
implied. Products for which warranty work has been approved must be sent directly to RETI and performed by RETI. To obtain warranty service and/or
replacement instructions, you must obtain prior approval from RETI before shipping your package to us by calling our customer service department
at 800-345-6007 or by writing to: Ardisam, Inc., P.O. Box 755, 1730 Industrial Avenue, Cumberland, WI 54829 for a return material authorization
number (RMA#). All items must be shipped prepaid. RETI will, at no charge, repair or replace, in RETI’s sole discretion, any product that satises the conditions
stated above. RETI retains the right to change models, specications and price without notice.
This equipment has been manufactured under strict quality and safety guidelines. As with any equipment of this type, full understanding of the instructions and
its use is mandatory and imperative for the safety of its user. RETI is not responsible for any damages or injuries sustained due to improper use or modication
of any of its products, or resulting from any use which deviates from the product’s intended usage. RETI is not responsible for any injuries sustained due to
failure to read and adhere to the instructions for use. Any misunderstanding or questions regarding the products of their use should be directed to RETI prior to
any use. All RETI treestands are sold with a full body harness (“Fall Arrest System”) that meets standards recognized by theTreestand Manufacturer’s
Association (“TMA”). It is the owner's sole responsibility to inspect the product regularly for damage, improper installation, or conditions that could jeopardize
the ultimate safety of the product. Failure to use or improper use of the provided Fall Arrest System may result in serious injury or death. ALWAYS wear the
provided Fall Arrest System while using this product. Owner is responsible to understand and follow product eld weight rating and must never
exceed maximum weight rating. RETI is not responsible for any malfunction or injury resulting from normal wear and tear, damage caused by improper use,
improper maintenance, negligence or accidents. This product, if used safely as intended, will provide trouble free service for the useful life of the product. We
hope you will enjoy the quality of our products for years to come, and have a safe hunt.
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 3
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
READ AND UNDERSTAND THE FOLLOWING WARNINGS BEFORE ASSEMBLY
STOP
MODEL LD204
MAXIMUM USE HEIGHT 21’1”TO SHOOTING RAIL
MAXIMUM OCCUPANCY ONE 1
TOTAL WEIGHT LIMIT 300 LB
TREE DIAMETER RANGE 12”TO 30”
WARNING
This product carries strict height and weight restrictions.
Do Not use this product if you exceed the total weight
limit. Please note that the total weight limit includes the
user(s) and their equipment.
WARNING
When hunting from a treestand falls can occur any
time after leaving the ground causing injury or death.
Always wear a Fall Arrest System (FAS) comprising a full
body harness at all times after leaving the ground. You
must stay connected at all times after leaving the ground
while using climbing and hang-on treestands. Single
safety belts and chest harnesses are no longer allowed
and shall never be used. If you are not wearing a full body
harness properly attached to the tree that is protecting
you from a fall, do not leave the ground.
Read and understand all of the manufacturer’s Warnings
and Instructions and use all safety devices provided by
the manufacturer. Contact the manufacturer for any
questions. Failure to do so could result in injury or death.
Never exceed the total weight limit of the treestand.
Never use a treestand during inclement weather such as
rain, lightning, windstorms or icy conditions and end your
hunt and return to the ground if inclement conditions arise.
Never use a treestand while using drugs (even
prescription drugs) or alcohol.
Never use a treestand while feeling ill, nauseous or dizzy,
or if you have a prior medical condition that could cause
a problem, that is, heart condition, joints that lock-up,
spinal fusions, etc., or if you are not well rested. Never
sleep in stand.
Never use a treestand on a dead, leaning, diseased or
loose barked tree, or a utility pole. Always avoid electrical
power lines.
Never rely on a tree branch for support.
WARNING
Never jump or bounce on a treestand to seat it to the tree.
Pull up a bow, backpack, or rearm or other equipment
only after being secure in the treestand and a rearm
must be pulled up with it unloaded, chamber open, and
muzzle down.
Always inform someone of the hunting location, where
the treestand will be located and the expected duration
of the hunt.
A signal device such as a mobile phone, radio, whistle,
signal are or personal locator device (PLD) must be on
your person and readily available at all times.
Never leave a treestand in a tree for more than two weeks
since weather or animals could cause damage. Tree
growth can also stress and damage straps and buckles.
Inspect the treestand and all safety devices each time
before use and Do Not store a treestand outdoors when
not in use.
Never modify your treestand in any way by making
repairs, replacing parts, or altering it except if explicitly
authorized in writing by the manufacturer.
Practice installing, adjusting and using your treestand at
ground level prior to using it at elevated positions. Study
your new stand to become familiar with all of its features
and design. Doing so will conrm that the product is
manufactured, assembled and installed correctly.
Instructions (written and video) shall be kept in a safe place
and reviewed at least annually. It is the responsibility of
the treestand owner to furnish the complete instructions
to any person who borrows or purchases the treestand.
Use at least three (3) people to install or take down a
ladder treestand.
The criss-cross straps/ropes and stabilization devices
must be attached before climbing to the platform.
When installing a ladder stand, always bounce on the
rst rung to set the ladder into the ground according to
manufacturer’s instructions before proceeding to climb
any higher.
Check every ladder section connection every time you
use the stand before you leave the ground. If ladder
sections are separating, do not use the stand.
Check the ground under the stand to make sure it is rm
and level. Sloping ground or uneven surface (one side on
a rock) can cause your ladder to tilt or shift o the tree as
you climb.
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007
4
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
BEFORE EACH USE PERFORM THE FOLLOWING:
• Inspect all webbing, rope, cord, and strap assemblies for
wear or damage.
• Inspect cables and/or cable ends for damage or kinking.
• Inspect all hardware and chain components for damage or
wear.
• Inspect for any structural damage to product. (If any exists
stop use immediately and call RETI Customer Service.)
• Inspect all nut and bolt assemblies to be certain none are
loose.
• Inspect for any missing parts.
• Lubricate all pivot and slide together points with powder
graphite, petroleum jelly or silicone spray to prevent noise,
wear and rust.
• Inspect entire product for any rust, corrosion, cracks,
freezing, excessive heat or rotting damage that may eect
the safety of your product. Discard any questionable
product.
• Inspect entire product for any structural damage - pay
close attention to all weld locations. (Discard product if any
damage is found.)
• Using correct wrenches inspect all nut & bolt assembly
locations and snug up any that may be loose. Be careful not
to crush tubing when tightening!
• Inspect and check operation of all cables, cable ends, cord,
rope, webbing, and strap or chain assemblies. Replace
with RETI original replacement parts any item or assembly
that shows signs of wear, damage, kinking, or functions
incorrectly.
• Inspect seat for damage or wear. Replace any seat with
factory new that shows signs of structural damage or wear.
• Never modify your stand in any way by making repairs,
replacing parts, or altering by adding or attaching anything
to it except if explicitly authorized in writing by the
manufacturer.
INSPECTION AND MAINTENANCE
WARNING
Always maintain three (3) points of contact when
climbing a ladder treestand. Proper three-point contact
means having either two feet with one hand or one foot
with two hands on the step portion of the ladder or
climbing aid at all times.
Always lean forward as you climb and attach your harness
to the tree before securing the platform to the tree and
stepping onto the platform.
Never exceed the stated maximum use height.
Do Not use this product until you have watched the
online safety video, understand it, and practiced the
techniques for safe hunting discussed in this video. Video
can be found with the QR code and/or URL shown on
front cover of this manual.
Read and perform all inspection and maintenance tasks
before each and every use. Replace any questionable
components immediately with RETI original replacement
parts.
Do Not crush tubing when tightening bolt assemblies!
Identify and familiarize yourself with all parts before you
start. Bolt identication chart can be found in the back.
Double check assembly steps to be certain you have
correctly assembled this product.
Never use any product that has not been maintained or
inspected properly - Your life depends on it!
Replace any and all treestand straps every two years or
when any signs of damage or wear exist before.
Always wear the appropriate footwear when using a
ladder treestand. A good non-slip safety boot is important
to your personal safety. Be especially careful that boot
laces do not get hooked on the stand or any of its
components (tuck shoelaces into boots before climbing).
WARNING
Only use approved RETI parts. Failure to do so may result
in serious injury or death!
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 5
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
- - 7/16 IN
WRENCHES 2
TOOLS REQUIRED
HARDWARE LIST
Item Part No. Description Image Qty
1 23603 KNOB SILENT
LADDER 4
17 36719 KNOB SILENT
LADDER W/ STUD 8
34 48042B WING NUT
1/4 20 IN 2
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007
6
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
Item Part No. Description Image Qty
35 48044B WING BOLT
1/4 X 13/4 IN 1
36 48057B WING BOLT
1/4 X 21/4 IN 1
37 48240B BOLT
1/4 X 11/2 IN 20
38 48250B BOLT
1/4 X 13/4 10
39 48261B WASHER
1/4 IN 10
40 48270B BOLT
1/4 X 21/2 IN 12
41 48271B BOLT
1/4 X 21/4 IN 9
42 48273B BOLT
1/4 X 31/4 IN 4
43 48280B BOLT
1/4 X 3 IN 8
44 48752B NUT
1/4 IN 67
45 8909B BOLT
1/4 X 11/4 IN 4
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 7
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
ASSEMBLY INSTRUCTIONS
IMPORTANT ASSEMBLY TIP:
Do not tighten any nut and bolt combinations completely
until all parts are assembled together! Finger tighten plus
one turn of a wrench only! This will temporarily hold the
lock- nut on the bolt while helping alignment of all parts!
After all parts are assembled together, all nut and bolt
combinations must be completely tightened.
All assembly must be done in this order at ground
level before uprighting.
Do not remove labels/warnings from product, they are
there for your safety.
Recommended for adult use only.
STEP 1
STEP 2
38
26
44
25
1. Insert each J-tube extension (26) into a J-tube
with pocket (25) and secure using a 1/4 X 1-3/4
IN bolt (38) and nut (44).
2 Attach the platform sections (27) together using
three 1/4 X 2-1/4 IN bolts (41) and nuts (44).
Attach the platform assembly to the J-tube
assemblies (25,26) using eight 1/4 X 3 IN bolts
(43) and nuts (44).
mesh hidden
for clarity
41
25
44
27 26
43
44
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007
8
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
STEP 3
STEP 4
3. Insert bottom tree blade (14) into ends of each
J-tube extension (26). Slide a strap guide (8)
onto each J-tube extension (26) and align with
rear hole on each side. Secure top tree blade
(23) and strap guide (8) to J-tube extensions
(26) using two 1/4 X 2-1/2 IN bolts (40) and nuts
(44). Secure the bottom tree blade to the J-tube
extensions using two 1/4 X 1-1/2 IN bolts (37)
and nuts (44). Pay close attention to DETAIL A
for proper positioning of strap guides (8).
4. Attach the bottom seat post (3) to the assembled
platform using four 1/4 X 1-3/4 IN bolts (38), four
1/4 IN steel washers (39) and nuts (44).
mesh hidden
for clarity
23
40
37
8
44
26
14
5
27
38
3
39
44
DETAIL A
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007 9
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
STEP 5
STEP 6
5. Attach four vertical supports (24) to the
assembled platform using four 1/4 X 2-1/4 IN
bolts (41) and nuts (44). Attach one support
brace (18) to the inside of each vertical support
(24) using a 1/4 X 1-1/4 IN bolt (45) and nut (44).
Attach to the opposite end of each support
brace (18) to the platform assembly using four
1/4 X 1-1/2 IN bolts (37) and nuts (44).
6. Assemble the shooting rail by inserting a
shooting rail hub (20) into each end of the
shooting rails (19). Secure using eight 1/4 X
1-1/2 IN bolts (37) and nuts (44).
NOTE: Pay close attention to the
orientation of the shooting rail hubs
(20). The four adjustment holes
should face the inside.
mesh hidden
for clarity
24
4445
41
18
37
37
44
20
19
Check for parts online at www.HuntRiversEdge.com or call 800-345-6007
10
Operator's Manual
LOCKDOWN™ 21’ 360 1-MAN
STEP 7
7. Attach the assembled shooting rail to the
assembled stand by inserting the four vertical
supports into the four hubs. Secure with the
push button pins at the highest height position
at this time. Later, once the stand is completely
set up, use the push button pins to adjust the
height of the shooting rail. Work your way
around and move each hub one adjustment hole
at a time until you reach the desired height.
Este manual sirve para los siguientes modelos
1
Tabla de contenidos
Otros manuales de Rack y soporte de Rivers Edge
Rivers Edge
Rivers Edge BIG FOOT XL Manual de usuario
Rivers Edge
Rivers Edge BIG FOOT XXXL Manual de usuario
Rivers Edge
Rivers Edge DELUXE RE647 Manual de usuario
Rivers Edge
Rivers Edge BIG FOOT XL LOUNGER RE552 Manual de usuario
Rivers Edge
Rivers Edge Pack-n-Stack RE622 Manual de usuario
Rivers Edge
Rivers Edge RELAX WIDE RE631 Manual de usuario
Rivers Edge
Rivers Edge LOCKDOWN 2-MAN Manual de usuario
