Rishabh RISH CON - V Manual de usuario
IC 15000930 REV. C - 17/12/2013
Programmable Voltage Transducer
RISH CON - V
1
Section Contents
1. Introduction
2. Input and Output screens
3. Programming
3.1 Programming via Front LCD & Two keys
3.1.1 Password Protection
3.1.1.1 Password Verification
3.1.1.2 Editing Existing Password
3.1.2 Potential Transformer parameter
Setting
3.1.2.1 Potential Transformer primary
value
3.1.2.2 Potential Transformer secondary
value
3.1.3 Communication Parameter Setting
3.1.3.1 Address Setting
3.1.3.2 RS 485 Baud rate
3.1.3.3 RS 485 Parity selection
3.1.4 Output Type Selection
3.1.4.1 Output 1 Type selection
3.1.4.2 Output 2 Type selection
3.1.5 Input Characteristics Setting
3.1.5.1 End value of input
3.1.5.2 Start value of input
3.1.5.3 Elbow Function Selection
3.1.5.4 Elbow value of input
Voltage Transducer
Programmable Voltage Transducer
Installation & Operating Instructions
3.1.6.1 Output 1 Characteristics Setting
3.1.6.1.1 End value of output 1
3.1.6.1.2 Start value of output 1
3.1.6.1.3 Elbow value of output 1
3.1.6.2 Output 2 Characteristics Setting
3.1.6.2.1 End value of output 2
3.1.6.2.2 Start value of output 2
3.1.6.2.3 Elbow value of output 2
3.2 Programming Via Programming port available at
front of Transducer using optional PRKAB601
Adapter.
Installation
5.1 EMC Installation Requirements
5.2 Case Dimension
5.3 Wiring
5.4 Auxiliary Supply
5.5 Fusing
5.6 Earth / Ground Connections
5.7 Maintenance
6. Specification
7. Connection Diagram
3.1.6 Output Characteristics Setting
3.3
DIP Switch Setting for Output
4.
Programming Via optional RS485(MODBUS)
communication port.
3.3.1
RS 485 ( ModBus )
5.
2
1. Introduction
The Voltage Transducer is a DIN Rail/wall mounted 43.5 X
65.5mm Transducer.
Input Voltage and Output Voltage/Current are displayed on
LCD and indicated by LED’s.
The Voltage Transducer is used to measure and convert AC
Voltage input into proportional DC current or voltage output
signal. Output signal generated is proportional to the True
RMS (upto 15th Harmonic) of the input Voltage.
Voltage Transducer can be
configured and programmed at
site for the following :
PT Primary ,PT Secondary, Input
Characteristics (i.e start, end and
elbow value of Input) and Output
parameters (i.e as Voltage or as
Current and start, end and elbow
value of outputs).
1.1 LED Indication
O/P 2
ON
O/P 1
LED
Red LED continuous ON
Green LED continuous ON
Green LED continuous ON
Green LED continuous ON
Red LED continuous ON
Output1 voltage
Output1 Current
Aux. Supply healthy condition
Output2 voltage
Output2 Current
LED OPERATING STATUS
LED OPERATING CONDITION
The front panel has two push buttons through which the user
may scroll through the output screens & configure the
product.
3
Screen 1 : Display Test Screen 2 : Version Screen
Screen 3 : Voltage Input & Screen 4 : Voltage Input &
Output 1 as Voltage Output 1 as Current
Table 1: Measured parameters
Measured parameters Unit of Measurement
Voltage V
2. Input and Output screens
In normal operation the user is presented with display test
screen followed by version screen to one of the output
screen. These screens may be scrolled through one at a
time by pressing the “ Up key” or “ Down key”.Ù Ú
4
3. Programming
3.1 Programming via Front LCD & Two keys
The following sections comprise step by step procedures for
configuring the Voltage Transducer for individual user
requirements.
To access the set-up screens press and hold the “ Down”
and “ Up” keys simultaneously for 5 seconds. This will
take the User into the Password Protection Entry Stage .
3.1.1. Password Protection
3.1.1.1 Password Verification
Password protection can be enabled to prevent
unauthorised access to set-up screens, by default password
protection is not enabled.
Programming of transducer can be done in three ways
3.1. Programming Via Front LCD & two keys.
3.2. Programming Via Programming port available at front of
Voltage transducer using optional PRKAB601 Adapter.
3.3. Programming Via optional RS485(MODBUS)
communication port.
Ú
Ù
5
Screen 5 : Voltage Input
& as Voltage
Screen 6 : Voltage Input &
Output 2 Output 2 as Current
by selecting a four digit number
other than 0000,setting a
password of 0000 disables the
password protection
Enter Password, prompt for first
digit. (*Denotes that digit will be
flashing).
Pressing the “ Down” key will scroll the value of the first
digit from 0 through to 9, the value will wrap from 9 round to 0.
Pressing the “ Up” key will advance the operation to the
next digit and set the first digit.
In the special case where the Password is “0000” pressing
the “ Up” key when prompted for the first digit will advance
to the “Password Set/Confirmed” screen.
Enter Password, first digit
entered, prompt for second digit.
(*Denotes that digit will be
flashing).
Pressing the “ Down” key will
scroll the value of the second
digit from 0 through to 9, the
value will wrap from 9 round to 0.
Pressing the “ Up” key will
advance the operation to the next
digit and set the second digit.
Enter Password, second digit
entered, prompt for third digit.
(*Denotes that digit will be
flashing).
Pressing the “ Down” key will
Password protection is enabled
Ú
Ù
Ù
Ú
Ù
Ú
6
scroll the value of the third digit from 0 through to 9, the
value will wrap from 9 round to 0.
Pressing the “ Up” key will advance the operation to
the next digit and set the third digit.
Enter Password, third digit
entered, prompt for (*Denotes
that digit will be flashing). fourth
digit.
Pressing the “ Down” key will
scroll the value of the fourth digit
from 0 through to 9, the value will
wrap from 9 round to 0.
Pressing the “ Up” key will advance the operation to the
“Password Set / Confirmed” and set the fourth digit.
Password Set / Confirmed.
Pressing “ Down” key will
enter to the “New change
Password” entry stage. (section
3.1.1.2)
Pressing the “ Up” key will
advance to the Potential
Transformer parameter
selection (section 3.1.2).
Password Incorrect.
This screen is displayed when
the unit has not accepted the
Password entered.
Pressing the " Down" key will
re -enter to the “Enter Password”
entry stage.
Pressing the “ Up” key will exit the setup menu.
Ù
Ú
Ù
Ú
Ù
Ú
Ù
7
3.1.1.2 Editing Existing Password
(*Denotes that digit will be
flashing).
Pressing the “ Down” key will
scroll the value of first digit from 0
through to 9, the value will wrap
from 9 round to 0.
Pressing the “ Up” key will
advance the operation to the next
digit and set the first digit, in this case to “4”
Enter New Password, first digit
entered, prompting for second
digit. (*Denotes that digit will be
flashing).
Pressing the “ Down” key will
scroll the value of the second
digit from 0 through to 9, the
value will wrap from 9 round to 0.
Pressing the “ Up” key will advance the operation to the
next digit and set the second digit, in this case to “1”
Enter New Password, second
digit entered, prompting for third
digit. (*Denotes that digit will be
flashing).
Pressing the “ Down” key will
scroll the value of the third digit
from 0 through to 9, the value will
wrap from 9 round to 0.
Pressing the “ Up” key will advance the operation to the
next digit and set the third digit, in this case to “4”
Ú
Ù
Ú
Ù
Ú
Ù
8
