RIOTEC DC9257A Manual de usuario

Programming Quick Guide

-DC9257A:Docking Scanner

-DC9267A:Wearable Scanner

Docking Scanner:

Gently tap the trigger area at the middle of scanner, to enable the

scanner (for reading barcode)

Wearable Scanner:

Press the ring trigger to enable the scanner.

Up Side

Lower Side

The touch sensor area is around middle of the scanner as drawing shown.

Installation

They are Plug &Play USB (HID) devices. When plugged into your Android

OTG devices, it can be recognized as barcode scanner and begin to scan

the barcode. Before using scanner, make sure the smartphone or tablet

is fully charged. Open your APP, they can work as a keyboard input.

Reset Configuration to Defaults

If you are unsure of the scanner configuration or have scanned the

incorrect codes, please scan the “Default” barcode. This will reset the

scanner to its factory defaults. (scan from 1 to 7)

Barcode Configuration Method:

(Flow chart for setup procedure :)

Start

Configuration

End

Configuration

Keyboard Language (For USB HID only)

Scan the appropriate country code as below to program the keyboard

layout for your country or language. As a general rule, the following

characters are supported, but need special care for countries other

than the United States: @ | $ # { } [ ] = / ‘ \ < > ~

USA

(Original setting)

Japan

Denmark

Finland

France

Germany

Italy

Norway

1D Symbologies – 1

ENABLE

CODE 39

DISABLE

ENABLE

CODE 39 Transmit

Start/Stop Character

DISABLE

ENABLE

CODE 39

FULL ASCII

DISABLE

ENABLE

CODE 11

DISABLE

Trigger

Area

Barcode Configuration Method:

(Flow chart for setup procedure :)

Start

Configuration

End

Configuration

1D Symbologies – 2

ENABLE

MSI

DISABLE

ENABLE

EAN-8

DISABLE

ENABLE

EAN-13

DISABLE

ENABLE

UPC-E

DISABLE

1D Symbologies – 3

ENABLE

UPC-A

DISABLE

ENABLE

Interleaved

DISABLE

ENABLE

Matrix

DISABLE

ENABLE

Industrial 25

DISABLE

ENABLE

CODE 93

DISABLE

ENABLE

CODABAR

DISABLE

ENABLE

CODE 128

DISABLE

ENABLE

GS1-128

UCC/EAN-128

DISABLE

ENABLE

GS1-Databar

(RSS)

DISABLE

1D Symbologies – 4

ENABLE

GS1-Databar

(RSS-Limited)

DISABLE

ENABLE

GS1-Databar

(RSS-Expand)

DISABLE

ENABLE

ISSN

DISABLE

ENABLE

ISBN

DISABLE

Inter-Keystroke Delay (FOR USB HID Only)

This parameter specifies the delay between emulated keystrokes

No Delay

Short Delay

(5ms)

Medium Delay

(10ms)

Long Delay

(15ms)



Information in this document is subject to change without notice.

R_151117_01
