Rikaline GPS-22 Manual de usuario

Rikaline

GPS-22

GPS Receiver Module

Positioning Accuracy:

3m CEP (50%) or <5m CEP ((90%)

Low Power:

17mA typical -- tracking at 3.3 Volts, full power

Rikaline

International Corp.

14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R.O.C

Phone: +886-2-8973-1899 Fax: +886-2-8973-1896

E-Mail: [email protected] Web: www.rikaline.com.tw

User’s Guide

FirstGPS V1.0 Jun 28, 2003

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

TABLE OF CONTENTS

1. Introduction ………………………………………………………………………….………… 3

1.1 Overview ………………………………………………………………………………………. 3

1.2 Features ……………………………………………………………………………….………. 3

1.3 FirstGPS Architecture Highlights …………………………………………………………… 3

1.4 Application …………………………………………………………………………………….. 3

1.3 Technology specifications ………………………………………………………………….… 3

2. Operational Characteristic ………………………………………………………………. 5

2.1 Initialization …………………………………………………………………………………… 5

2.2 Navigation …………………………………………………………………………………….. 5

3. Hardware Interface …….……………………………………………………………………. 6

3.1 Physical Characters ………………………………………………………………………… 6

3.2 Pin Definition ………………………………………………………………………………… 6

4. Software Interface ……………..…………………………………………………….………. 8

4.1 NMEA Transmitted Message ……………………………………………………….………. 8

4.2 RTCM Received Data ………………..…………………………………………………….. 11

4.3 Syntax Setting ………………………………………………………………………………… 11

4.4 Default Setting Details ………………………………………………………………………… 14

4.5 Application Information ……………………………………………………………………… 15

5. Earth Datums ………………………………………………………………………………….. 16

5.1 Earth Datums ………………………………………………………………………………… 16

6. Ordering Information ………………………………………………………………………. 16

6.1 Products Options ……………………………………………………………………..……… 16

6.2 Accessories ……………………………………………………………………..…………….. 16

7. Warranty …………………………………………………………………………..…………….. 16

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

1. Introduction

1.1 Overview

The Rikaline GPS-22 GPS Receiver is a GPS receiver featuring the revolutionary FirstGPS™

architecture. This complete enabled GPS receiver module provides high position and speed accuracy

performances as well as high sensitivity and tracking capabilities in urban canyon conditions. The solution

enables small form factor package. The GPS-22 delivers major advancements in GPS performances,

accuracy, integration, computing power and flexibility. It is designed to simplify the embedded system

integration process.

This positioning application meets strict needs such as car navigation, mapping, surveying, agriculture and

so on. Only clear view of sky and certain power supply are necessary to the unit. GPS-22 communicates

with other electronic utilities via compatible dual-channel through TTL and saves critical satellite data in

built–in memory backup. With low power consumption, the GPS-22 tracks up to 8 satellites at a time,

re-acquires satellite signals in 100 ms and updates position data every second.

1.2 Features

The GPS-22 provides a host of features that make it easy for integration and use.

1. Position accuracy in < 3m CEP (50%) or <5m CEP ((90%) without SA (horizontal)

2. Ultra low power: 17mA typical -- tracking at 3.3 Volts, full power

3. High sensitivity: to -143 dBm tracking, superior urban canyon performances

4. Small form factor and low cost solution

5. Ready-to-plug solution. Easily integrated into existing systems

6. On-board RAM for GPS navigation data

7. PPS output (User may have different interval setting from 1 second to 1 minute.

8. Differential capability utilizes real-time RTCM corrections producing < 1 meter position accuracy.

9. FLASH based program memory: New setting is stored permanently.

1.3 FirstGPS Architecture Highlights

1.3.1 Industry Leading GPS Performance

-Builds on high performance FirstGPSTM

core

-Satellite signal tracking engine to perform GPS acquisition and tracking functions without CPU

intervention

-High sensitivity: to -143 dBm tracking, superior urban canyon performances

-Position accuracy: < 3m CEP (50%) without SA (horizontal)

-Warm Start is under 42 seconds (90%)

-Hot Start is under 10 seconds (90%)

1.3.2 Low Power

-Ultra low power integrated circuit design, optimized RF and DSP architectures

-Further power saving thanks to 4 different power down mode

1.4 Application

1. Car Navigation

2. Mapping

3. Surveying

4. Agriculture

5. Palmtop, Laptop, PDA

6. Location Based Services enabled devices

7. Asset management/tracking

8. Handheld receivers

1.5 Technology specifications

1.5.1 Physical Dimension

1. Size: 31.59(W) x 26.59(D) x 11.20(H) (mm)

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

1.24”(W) x 1.05”(D) x 0.44”(H)

2. Weight: 25 g

1.5.2 Environmental Characteristics

1) Operating temperature: -40oC to +85oC (internal temperature)

2) Storage temperature: -55oC to +100oC

1.5.3 Electrical Characteristics

1) Input voltage: +3.0 ~ 3.65 VDC.

2) HFL antenna connector: Active or patch (3.0V antenna is recommended).

1.5.4 Functional Block Diagram

1.5.5 Performance

1) Tracks up to 8 satellites.

2) Update rate: 1 second.

3) Acquisition time:

Reacquisition 0.1 sec. (90%)

Hot start 10 sec. (90%)

Warm start 42 sec. (90%)

Cold start 120 sec. (90%)

4) Position accuracy:

Non DGPS (Differential GPS)

Position <3m CEP (50%) or <5 m CEP (90%)

Velocity 0.1 meters/second.

Time 1 microsecond synchronized GPS time

DGPS (Differential GPS)

Position <1 m, typical

Velocity 0.05 meters/second, typical

5) Dynamic Conditions:

Altitude 18,000 meters(60,000 feet) max

Velocity 515 meters/second (1000 knots) max

Acceleration 4 G, max

Jerk 20 meters/second³, max

1.5.6 Interfaces

1) Dual communication channel through TTL, with user selectable baud rate (2400, 4800-Default, 9600,

19200, 38400, 57600, 115200).

2) NMEA 0183 Version 2.1 ASCII output (GGA, GLL, GSV, GSA, RMC, VTG, ZDA).

3) Real-time Differential Correction input (RTCM SC-104 message types 1, 2 and 9).

Remark: FirstGPS™is the trademark from Trimble

ANT

LNA

GPS

BASEBAND

PROCESSOR

DOWN -

CONVERTER

FILTER

TCXO

I LPF

LPF

MCLKI

SCLK

RF+

RF -

FILTER RX

RTOS

FirstGPS

SOFTWARE

API

XE1610 -OEMPVT

APPLICATION PVT

BOARD

INTERFACE

Active Antenna

ANT

LNA

GPS

BASEBAND

PROCESSOR

DOWN -

CONVERTER

FILTER

TCXO

I LPF

LPF

MCLKI

SCLK

RF+

RF -

FILTER RX

RTOS

FirstGPS

SOFTWARE

API

APPLICATION PVT

BOARD

INTERFACE

Active Antenna

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

2. Operational characteristics

2.1 Initialization

As soon as the initial self-test is complete, the GPS-22 begins the process of satellite acquisition and

tracking automatically. Under normal circumstances, it takes approximately 120 seconds to achieve a

position fix, 42 seconds if ephemeris data is known. After a position fix has been calculated, information

about valid position, velocity and time is transmitted over the output channel.

The GPS-22 utilizes initial data, such as last stored position, date, time and satellite orbital data, to achieve

maximum acquisition performance. If significant inaccuracy exists in the initial data, or the orbital data is

obsolete, it may take more time to achieve a navigation solution. The FirstGPS™ architecture provides

superior performance. However, acquisition performance can be improved as the host system initializes the

GPS-22 in the following situation:

1. Moving further than 1,500 kilometers.

2. Failure of Data storage due to the inactive memory power back up.

2.2 Navigation

After the acquisition process is complete, the GPS-22 sends valid navigation information over output

channels. These data include:

1) Latitude/longitude/altitude

2) Velocity

3) Date/time

4) Error estimates

5) Satellite and receiver status

The GPS-22 sets the default of auto-searching for real-time differential corrections in RTCM SC-104

standard format, with the message types 1, 2, or 9. It accomplishes the satellite data to generate a

differential (DGPS) solution. The host system, at its option, may also command the GPS-22 to output a

position whenever a differential solution is available.

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

3. Hardware interface

3.1 Physical Characters

1. Size: 31.59(W) x 26.59(D) x 11.20(H) (mm)

1.24”(W) x 1.05”(D) x 0.44”(H)

2. Weight: 25 g

3.1.1 Details Drawing

3.2 Pin Definition

PIN NAME TYPE DESCRIPTION

1 GND Power and Signal Ground

2 ON/OFF I ON / Off command line

3 VCC 3.0 to 3.6 Volts DC Input Power Supply

4 USPED I 9600/4800 Bd UART Speed

5 RXA I Serial Receive Data, Port A, GPS NMEA Data

6 VRTCBK Back-up supply for the RTC

7 TXA O Serial Transmit Data, Port A, GPS NMEA Data

8 PPS O One Pulse Per Second timing output

9 GND Power and Signal Ground

10 RESETN Manual Reset, Active low

11 ALMRDY 1(high): almanac valid; 0 (low): almanac not valid

12 STY1 I Blinking function, when position fix, output “low”. When

tracking, output the interval signal “high/low”.

13 N.C.

14 STY0 For customer specific version

15 N.C.

16 OSCSTOPN Stand-by active “low”

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

1) All I/Os on the Data Interface are related to VCC (3 to 3.6 Volts) and GND levels.

2) ON/OFF: control the GPS engine “ON” or “OFF”. If this pin is pulled “HIGH” whenever a reset

condition occurs or if it is turned “HIGH” during operating, the GPS engine is turned “ON”. If this pin is

pulled “LOW” whenever a reset condition occurs, the GPS engine is not started. If this pin is turned

“LOW” when in operating, the GPS engine is turned “OFF”. When ON/OFF is “LOW”, the on/off state can

be superseded with the PXEMaRT manufacturer specific NMEA sentence on RXA, as defined below.

3) RXA and TXA: The Serial NMEA data port (RXA and TXA) is an asynchronous serial port (UART).

4) USPED: USPED “HIGH”: 9600 Baud rate, 8 bit data, no parity check, 1 stop bit and no flow control.

USPED “LOW”: 4800 Baud rate, 8 bit data, no parity check, 1 stop bit and no flow control .

This setting can be modified with the PXEMaPT manufacturer specific NMEA sentence defined later.

5) PPS: This is Pulse Per Second highly accurate timing signal generated by the on-board GPS base

band processor at 83ms duration. After a reset condition, the default setting for this port is inactive. This

setting can be modified with the PXEMaPS manufacturer specific NMEA sentence defined below.

6) RESETN: The receiver has 2 reset conditions: first, on power-on, thanks to an on-board Power On Reset

circuitry; and second an external reset when the RESETN pin is “LOW”.

7) VCC: Main power supply.

8) VRTCBK: This is the back-up supply for the on-board real time clock.

9) ALMRDY: When in active mode, this indicates the on-board almanac status. Upon start up and

whenever the almanac data are tested invalid or not up-to-date, the output level is “low”. If tested valid or

up-to-date, the output level is “high”

10) STANDBYIN: This input sets the receiver in stand-by mode when its level is “low”. Otherwise, the

receiver is either in active or power save mode. See below under operating modes for details.

3.3 Operating Modes

Mode Description VCC pin On\Off Pin Standby

pin Current

cons. Type.

Active

Mode Receiver is running, doing

acquisition, tracking, position fixes Powered High High 17mA

Power

Save

Mode

GPS receiver functions are turned

OFF, MCU in idle mode, MCU clock

is running, RTC is running

Powered Low (or thru

NMEA

command)

High 2.2mA

Stand-

Mode

GPS receiver functions are turned

OFF, MCU clock is stopped, RTC is

running on the Back-up supply

No power low low 300μA

Power

Down

Mode

GPS receiver functions are turned

OFF, MCU clock is stopped, RTC is

running on the Back-up supply

No power low low 1μA

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

4. Software Interface

The GPS-22 interface protocol is based on the National Marine Electronics Association's NMEA 0183 ASC

Ⅱinterface specification, which is defined in NMEA 0183, Version 2.1 and the Radio Technical Commission

for Maritime Services (RTCM Recommended Standards For Differential Navstar GPS Service, Version 2.1,

RTCM Special Committee No.104).

4.1 NMEA Transmitted Messages

The GPS-22 outputs data in NMEA-0183 format as defined by the National Marine Electronics Association

(NMEA), Standard.

The default communication parameters for NMEA output are 9600/4800 baud, 8 data bits, stop bit, and no

parity.

Table 4-1 NMEA-0183 Output Messages

NMEA Record Description

GPGGA Global positioning system fixed data

GPGLL Geographic position- latitude/longitude

GPGSA GNSS DOP and active satellites

GPGSV GNSS satellites in view

GPRMC Recommended minimum specific GNSS data

GPVTG Course over ground and ground speed

GPZDA Date & Time

4.1.1 Global Positioning System Fix Data (GGA)

$GPGGA,161229.487,3723.2475,N,12158.3416,W,1,07,1.0,9.0,M, , , ,0000*18

Table 4-2 GGA Data Format

Name Example Units Description

Message ID $GPGGA GGA protocol header

UTC Time 161229.487 Hhmmss.sss

Latitude 3723.2475 Ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

Position Fix Indicator 1 See Table 5-3

Satellites Used 07 Range 0 to 12

HDOP 1.0 Horizontal Dilution of Precision

MSL Altitude 9.0 Meters

Units M Meters

Geoid Separation Meters

Units M Meters

Age of Diff. Corr. second Null fields when DGPS is not used

Diff. Ref. Station ID 0000

Checksum *18

<CR> <LF> End of message termination

Table 4-3 Position Fix Indicator

Value Description

0 0 Fix not available or invalid

1 GPS SPS Mode, fix valid

2 Differential GPS, SPS Mode, fix valid

3 GPS PPS Mode, fix valid

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

4.1.2 Geographic Position with Latitude/Longitude (GLL)

Table 4-4 contains the values for the following example:

$GPGLL,3723.2475,N,12158.3416,W,161229.487,A*2C

Table 4-4 GLL Data Format

Name Example Units Description

Message ID $GPGLL GLL protocol header

Latitude 3723.2475 ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

UTC Position 161229.487 hhmmss.sss

Status A A=data valid or V=data not valid

Checksum *2C

<CR> <LF> End of message termination

4.1.3 GNSS DOP and Active Satellites (GSA)

Table 4-5 contains the values for the following example:

$GPGSA,A,3,07,02,26,27,09,04,15, , , , , ,1.8,1.0,1.5*33

Table 4-5 GSA Data Format

Name Example Units Description

Message ID $GPGSA GSA protocol header

Mode 1 A See Table 5-6

Mode 2 3 See Table 5-7

Satellite Used (1) 07 Sv on Channel 1

Satellite Used (1) 02 Sv on Channel 2

…… ….

Satellite Used Sv on Channel 12

PDOP 1.8 Position Dilution of Precision

HDOP 1.0 Horizontal Dilution of Precision

VDOP 1.5 Vertical Dilution of Precision

Checksum *33

<CR> <LF> End of message termination

(1) Satellite used in solution.

Table 4-6 Mode 1

Value Description

M Manual—forced to operate in 2D or 3D mode

A2D Automatic—allowed to automatically switch 2D/3D

Table 4-7 Mode 2

Value Description

1 Fix Not Available

2 2D

3 3D

4.1.4 GNSS Satellites in View (GSV)

Table 4-8 contains the values for the following example:

$GPGSV,2,1,07,07,79,048,42,02,51,062,43,26,36,256,42,27,27,138,42*71

$GPGSV,2,2,07,09,23,313,42,04,19,159,41,15,12,041,42*41

Table 4-8 GSV Data Format

GPS-22 Operating Manual

Rikaline

Specifications subject to change without prior notice

Rikaline International Corp. 14F, 171, ChengGong Rd., Sanchong City, Taipei 241, Taiwan, R. O.C

Tel: ++886 2 8973-1899 Fax: ++886 2 8973-1896 E-Mail: [email protected] web: www.rikaline.com.tw

Name Example Units Description

Message ID $GPGSV GSV protocol header

Number of Messages 2 Range 1 to 3

Message Number 1 Range 1 to 3

Satellites in View 07 Range 1 to 12

Satellite ID 07 Channel 1 (Range 1 to 32)

Elevation 79 degrees Channel 1 (Maximum 90)

Azimuth 048 degrees Channel 1 (True, Range 0 to 359)

SNR (C/No) 42 dBHz Range 0 to 99, null when not tracking

.... ....

Satellite ID 27 Channel 4 (Range 1 to 32)

Elevation 27 degrees Channel 4 (Maximum 90)

Azimuth 138 degrees Channel 4 (True, Range 0 to 359)

SNR (C/No) 42 dBHz Range 0 to 99, null when not tracking

Checksum *71

<CR> <LF> End of message termination

NOTE: Items <4>,<5>,<6> and <7> repeat for each satellite in view to a maximum of four (4) satellites per

sentence. Additional satellites in view information must be sent in subsequent sentences. These fields will

be null if unused.

4.1.5 Recommended Minimum Specific GNSS Data (RMC)

Table 4-9 contains the values for the following example:

$GPRMC,161229.487,A,3723.2475,N,12158.3416,W,0.13,309.62,120598, ,*10

Table 4-9 RMC Data Format

Name Example Units Description

Message ID $GPRMC RMC protocol header

UTC Time 161229.487 hhmmss.sss

Status A A=data valid or V=data not valid

Latitude 3723.2475 ddmm.mmmm

N/S Indicator N N=north or S=south

Longitude 12158.3416 dddmm.mmmm

E/W Indicator W E=east or W=west

Speed Over Ground 0.13 Knots

Course Over Ground 309.62 Degrees True

Date 120598 ddmmyy

Magnetic Variation Degrees E=east or W=west

Checksum *10

<CR> <LF> End of message termination

4.1.6 Course Over Ground and Ground Speed (VTG)

Table 4-10 contains the values for the following example:

$GPVTG,309.62,T, ,M,0.13,N,0.2,K*6E

Table 4-10 VTG Data Format

Name Example Units Description

Message ID $GPVTG VTG protocol header

Course 309.62 Degrees Measured heading

Reference T True

Course Degrees Measured heading

Reference M Magnetic (1)

Speed 0.13 Knots Measured horizontal speed

Units N Knots

Speed 0.2 Km/hr Measured horizontal speed

Units K Kilometers per hour

Tabla de contenidos

Otros manuales de GPS de Rikaline

Rikaline

Rikaline GPS-6010-X5 Manual de usuario

Rikaline

Rikaline GPS-24/24A Manual de usuario

Rikaline

Rikaline GPS-6010 Manual de usuario

Rikaline

Rikaline GPS-6033 Manual de usuario

Rikaline

Rikaline GPS-6021-X6 Manual de usuario

Rikaline

Rikaline GPS-6033 Manual de usuario

Rikaline

Rikaline CF GPS GPS-6020 Manual de usuario

Rikaline

Rikaline E-705 Manual de usuario

Rikaline

Rikaline GPS-6030 Manual de usuario

Rikaline

Rikaline GPS-6031-X7 Manual de usuario

Rikaline

Rikaline GPS-20 Manual de usuario

Rikaline

Rikaline GPS-300 Manual de usuario

Rikaline

Rikaline GPS-6017 Manual de usuario

Rikaline

Rikaline GPS-6010 Manual de usuario

Rikaline

Rikaline CF GPS Receiver Manual de usuario

Rikaline

Rikaline GpsLogistic Pro Manual de usuario

Rikaline

Rikaline GPS-6033 Manual de usuario

Rikaline

Rikaline CF GPS GPS-6020 Manual de usuario

Rikaline

Rikaline GPS Kit Manual de usuario

Rikaline

Rikaline 24A Manual de usuario

Rikaline

Rikaline GPS-6036 Manual de usuario

Rikaline

Rikaline GPS-6011 Manual de usuario

Rikaline

Rikaline GPS-6012 Manual de usuario

Rikaline

Rikaline GPS-6010-X5 Manual de usuario

Manuales populares de GPS de otras marcas

Raven

Raven Cruizer II Manual

Hama

Hama 53118 Manual de usuario

Garmin

Garmin SOUNDER 125 Manual de usuario

Garmin

Garmin DEZL 580 Manual de usuario

Jigabot

Jigabot EX Manual de usuario

Pointer

Pointer Cellocator CelloTrack XT LTE Guía de instalación

Queclink

Queclink GV55LITE Manual de usuario

Voxson

Voxson Voxtrack GPS500 Manual de instrucciones

Garmin

Garmin ECHOMAP PLUS Manual de usuario

Starcom Systems

Starcom Systems Kylos Compact Manual de usuario

Garmin

Garmin 15 H Series Manual de usuario

Cobra

Cobra Marine MC 600Ci Manual de usuario

Cellocator

Cellocator CelloTrack T Manual de usuario

Enfora

Enfora Mini-MT GSM2228UG001 Manual de usuario

Magellan

Magellan eXplorist 100 Manual de usuario

LTE

LTE G50B Manual de usuario

Garmin

Garmin DEZL OTR500 Manual de usuario

SkyGolf

SkyGolf SkyCaddie SG1 Manual de usuario
