Ricoh PRO C7200 Instrucciones de uso

Adjustment Settings

for Operators

CIP Training

Pro C7200 series

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

This section explains Adjustment Settings for Operators and how to specify them.

How to Use the [Adjustment Settings for

Operators] Screen

This section explains how to use the Adjustment Settings for Operators.

DWP560

To Print Screen

1. [-]

Press this key to collapse the hierarchical display of the adjustment items and display the group names of those

items.

2. [Reset]

Press this key to reset the settings/modifications currently configured. You cannot reset he settings/

modifications after pressing [Apply].

3. [Apply]

Press this key to apply the settings/modifications.

4. [To Print Screen]

Press this key to display the print screen. You can use this screen to view the changes you have made.

5. Adjustment items

Adjustment items are displayed in this area. When you select an item, its configuration screen will then open.

6. Configuration screen

Configure or modify the settings of the adjustment item you select.

209

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

Accessing the Adjustment Settings for

Operators

1. Press [Adjustment Settings for Operators] at the upper left of the screen.

2. Select and change adjustment settings.

The method for changing the selected adjustment setting depends on the setting that you want to

change. For details, see page 210 "Features of the Displayed Items and Setting Operations".

3. Press [Apply].

4. Press [Home] ( ) at the bottom of the screen in the center.

Features of the Displayed Items and Setting Operations

The following operations are available for each adjustment item:

• Value setting

• Item setting

• Executing

• Display only

Value setting

Press [ ] or [ ] to increase or decrease the value respectively, or use the numeric keypad to enter

the value.

For some settings, move the slider right or left to increase or decrease the setting value.

6. Adjustment Settings for Operators

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

A numeric keypad appears to the left when you press the input box. Use the keypad to enter a

value.

• [×]: Press to delete the entered value character by character.

• [Clear]: Clear the entered value.

•[+/-]: Change the sign of the entered value from + (positive) to - (negative) and vice versa.

• [Enter]: Confirm the entered value.

For some items, you can select a value from the pull-down list that appears when you press the

input box. Select a value from the list.

Item setting

Select the item you require.

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

Executing

Press [Execute] to perform a selected function.

Display Only

You can check the setting of the selected item.

Printing with Adjusted Settings

To print with the settings you have adjusted, be sure to select the paper tray and paper size to which the

settings apply.

• Settings adjustable for each paper tray

• Settings adjustable for each paper size

Settings adjustable for each paper tray

These are settings adjustable for each paper tray.

Print jobs are processed with the adjusted settings when printing from a tray with the applied

settings.

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

Settings adjustable for each paper size

These are settings adjustable for each paper size.

Print jobs are processed with the adjusted settings when printing with a paper size that has the

applied settings.

• For details about selecting the paper tray and paper size for printing, see the manuals for the

related functions.

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

Menu Items and Functions

Machine: Image Position

For details about the following items, see page 222 "Machine: Image Position".

No. Item Description

0101 Image Position: Across

Feed: Side 1

Adjust the image position (up and down) on side 1

across the feeding direction.

0102 Image Position: Across

Feed: Side 2

Adjust the image position (up and down) on side 2

across the feeding direction.

0103 Image Position: With Feed:

Side 1

Adjust the image position (left and right) on side 1 along

the feeding direction.

0104 Image Position: With Feed:

Side 2

Adjust the image position (left and right) on side 2 along

the feeding direction.

0105 Perpendicularity

Adjustment

Adjust the image skew (perpendicularity) across the

feeding direction.

0106 Switch Paper Edge

Detection Sensor

Specify the level for detecting the paper edge for

correcting the image position along the feeding

direction.

Machine: Image Quality

For details about the following items, see page 229 "Machine: Image Quality".

No. Item Description

0201 Execute Image Quality

Adjustment

Execute image control or color registration adjustment

manually.

0202 Maximum Image Density Adjust the toner adhesion amount to the intermediate

transfer belt during the image density adjustment.

0203 Line Width Adjust the intensity of the laser for rasterizing the image

data.

0204 Density Difference: Across

Feed

Adjust the vertical density deviation of images in the

direction perpendicular to the paper feed direction.

Machine: Paper Feed/ Output

For details about the following items, see page 231 "Machine: Paper Feed/ Output".

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

No. Item Description

0301 3-Tray LCIT: Fan Setting Specify the fan operation of the 3-Tray LCIT.

0302 3-Tray LCIT: Fan Volume

Setting

Adjust the fan volume for the 3-Tray LCIT to separate

sheets of paper in close contact.

0303 Pickup Assist Setting Specify the operation of the Paper Feed Roller in the

trays of the main unit, bypass tray, and 3-tray LCIT.

0304 Correct Output Paper Curl Specify the method for straightening curled sheets.

Select the method according to the direction and degree

of curl.

0305 Detect JAM099 Specify whether or not to detect double feed (multi-sheet

feeding). This setting is invalid when you are printing

from the tray for which custom paper is allocated.

0306 Detect JAM080 Specify whether or not to detect error as a paper jam

when the image deviation in the feeding direction

exceeds a certain degree.

0307 Detect/Control

JAM097/098

Specify whether or not to correct the image position and

skew in the vertical direction when a deviation in the

direction is detected.

0308 Detect JAM048 Specify whether or not to detect an error as a paper jam

when a problem is detected while the registration mark

is checked for image position correction.

0311 Buffer Pass Unit Fan

Activation Setting

Select the condition for activating the fan in the Cool

Feeding Unit. When the fan stops, the mechanical noise

is lower.

Machine: Maintenance

For details about the following items, see page 236 "Machine: Maintenance".

No. Item Description

0501 Execute Process

Adjustment

Execute the following adjustments for printing at once:

•image density, color deviation, charge roller

cleaning, charge bias, and transfer current

correction

CIP Training Pro C7200 series

Adjustment Settings for Operators

CIP Training C7200 series

Adjustment Settings for Operators

No. Item Description

0502 Screw-on Cap to Replace Close the Toner Bottle Cap.

Open the toner bottle cover (the cover of the toner

dispensing section) before executing this function.

Afterward, remove the toner bottle by pushing the knob

below the bottle.

0503 Execute Charge Roller

Cleaning

Cleans the Charge Roller.

0507 Execute Developer

Refreshing

Replace some of the liquid developer in the development

unit.

0509 Smooth Fusing Belt Smooth the Fuser Belt to remove vertical and horizontal

lines from the printouts.

0510 Fusing Belt Smoothing

Setting

Specify the condition to execute Fuser Belt smoothing.

0511 Fuser Unit Speed

Adjustment

Correct the deviation in the rotation speed of the Fuser

Unit.

0514 Temperature / Humidity

Inside

Display the internal temperature and humidity.

0515 Temperature / Humidity

Outside

Display the external temperature and humidity.

0519 Display Parts Life Counter Display the usage rate of the spare parts.

Finishing: Finisher

For details about the following items, see page 240 "Finishing: Finisher".

No. Item Description

0601 Staple Position: Across

Feed 1

Adjust the vertical position of the staple (applied at an

edge) when using Finisher SR5050 or Booklet Finisher

SR5060.

0602 Staple Position: Across

Feed 2

Adjust the vertical distance (up and down) between the

staples (dual) when using Finisher SR5050 or Booklet

Finisher SR5060.
