Ricoh BL-P1 Series Manual

RicohCo.Ltd.http://www.ricoh.com/

Model BL-P1

(M087/M088)

Service Training

Draft started: 9 November 2010

Final: 10 December 2010

Corrections applied to slide 17: 6 January 2011

RicohCo.Ltd.http://www.ricoh.com/

Course Contents

1. Product Outline

2. Specifications

3. Installation

4. Machine Overview

5. Service Maintenance

6. Mechanical Operation

7. Print Processes

8. Toner Cartridge

9. Replacement and Adjustment

10. Troubleshooting

11. Environmental Conservation

- A note to the training supervisor -

This course was written assuming the following requirements. Modify as

necessary depending on your situation.

Preparation

-Prior to starting this course, prepare the following items. -

¾Training machines – M088 (BL-P1a) and M087 (BL-P1b) in the shipping

boxes

¾A set of service tools

¾The BL-F1 Field Service Manual

¾The M088 (BL-P1a) and M087 (BL-P1b) User's Manuals

Requirements for trainees

¾Prior to starting this course, the following training or equivalent should be

completed.

Fax basics course

Copier basics course

¾The trainee should also be familiar with the Core Technology Manual and

be able to reference it during training.

Time required to complete this course: 6 hours or less.

RicohCo.Ltd.http://www.ricoh.com/

Model BL-P1

(M087/M088)

Service Training

1. Product Outline

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Appearance

This is the machine you will study in this training course.

The two models are externally the same.

BL-P1

(M087/M088)

The BL-P1b (M087) has NIC and USB2.0 interfaces but the BL-P1a (M088) does

not.

The BL-P1a (M088) will be marketed in China only.

The BL-P1b (M087) will be marketed in the Americas, Europe, and Asia/Oceania

(but not China).

RicohCo.Ltd.http://www.ricoh.com/

External Components – Front

See the Quick Start Guide for a list of components in the shipping carton.

6. Manual feed slot cover

11. Face down output tray5. Manual feed slot

10. Ventilation grid4. Manual feed paper guide

9. Power switch3. Control panel

8. Front cover2. Face-down output tray support flap 1

7. Paper tray1. Face-down output tray support flap 2

Refer to the operating instructions for more details.

RicohCo.Ltd.http://www.ricoh.com/

External Components – Rear

*BL-P1b (M087) only

3. Network status LEDs*

5. USB connector2. AC power connector

4. 10/100BASE-TX port*1. Back cover (back output tray)

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Control Panel

1. Toner LED

The Toner LED indicates when the

Toner is low or at the end of its

life.

2. Drum LED

The Drum LED indicates when the

Drum is nearing the end of its life.

3. Error LED

The Error LED indicates when the

printer is in one of the following

states:

No paper / Paper jam / Cover

open

4. Ready LED

The Ready LED will flash

depending on the printer status.

Go button

Wake-up / Error recovery / Form

feed / Job Cancel / Reprint

Refer to the User's Guide for

details of how these LEDs and

the Go button are used.

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Market Positioning and Concept

Main Objective

Maintain and expand MIF in the low end market

Target Users

Business personal (1 to 4 users)

Small office (5 to 29 users)

Can double as a small office printer/copier

Key sales points

Small, stable, and convenient laser printer

Low TCO*

Low environmental impact (ECO friendly)

Features

Easy management (uses universal driver)

Integrated PCL/PS

Small size (especially low height)

*TCO = Total cost of ownership

RicohCo.Ltd.http://www.ricoh.com/

Reliability Targets

Toner yield

Starter toner: Approximately 1,000 sheets

Toner: Approximately 2,600 sheets

(Approximate toner yield calculations based on the ISO/IEC

19752 standard.)

Drum yield: Approximately 12,000 sheets

Expected product life: 5 years or 50K prints

No additional notes.

RicohCo.Ltd.http://www.ricoh.com/

Model BL-P1

(M087/M088)

Service Training

2. Specifications

No additional notes.
