CAUTIONS

KEEP HANDS AWAY FROM MECHANICAL DRIVE COMPONENTS WHEN THE COPIER IS WARM-

ING UP.

This is to avoid possible injury when the copier starts idling at the end of warm up.

ALWAYS REINSTALL THE FUSING UNIT COVER AFTER SERVICING.

This is to prevent the operator from accidentally touching the hot unit, or the fusing lamp terminal.

RICOH

FT3020/FT3050/FT3060

FIELD SERVICE MANUAL

RICOH COMPANY, LTD.

SECTION

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

INSTALLATION

UNPACKING

INSTALLATION

REQUIREMENTS

PREPARATIONS FOR TRANSPORTING THE

COPIER

REMARKS

REPLACEMENT AND ADJUSTMENT

SERVICE TABLES

P.M. TABLE

SPECIAL TOOLS AND JIGS

TROUBLESHOOTING

ELECTRICAL DATA

SECTION 1

INSTALLATION

REQUIREMENTS

INSTALLATION REQUIREMENTS

1A.

1B.

1C.

1D.

Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1

Machine Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2

Minimum Space Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3

Power Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4

1A.

10.

11.

Environment

Temperature Range :

Humidity Range :

Ambient Illumination :

Ventilation

Ambient Dust

Room Size

10°C to 30°C (50°F to 86°F)

15% to 90% RH

Less than 1,500 Iuxs (Do not expose to direct sunlight)

Room air should turn over at least 3 times/hour.

Less than 0.15 mg/m3 (4 x 100¯³ Oz/yd³)

More than 10m³ (13.4 yd3)

If the installation place is air-conditioned or heated, place the machine:

a. Where it will not be subjected to sudden temperature changes from low to high, or vice versa.

b. Where it will not be directly exposed to cool air from an air conditioner in the summer.

c. Where it will not be directly exposed to reflected heat from a space heater in winter.

Avoid placing the copier in an area filled with corrosive gas.

Avoid any area higher than 2,000m (6,500 feet) above sea level.

Place the copier on a strong and level base.

Avoid any area where the copier may be subjected to frequent strong vibration.

1-1

1B. Machine Level

1. Front to Back:

Within 5mm (0.2”) of level

2. Right to Left:

Within 5 mm (0.2”) of level

(Legs may be screwed up or down to level the

machine. Set a carpenter’s level on the

exposure glass.)

1-2

July 1, ’85

1C. Minimum Space Requirements

1. Front : 70 cm (27-1/2”)

2. Back : 10 cm (4“)

3. Right : 70 cm (27-1/2”)

4. Left : 70 cm (27-1/2”)

1Ocm (4”)

1-3

1 D.

Power Source

Input Voltage Level

110V/60Hz : More than 12A

115V/60Hz : More than 12A

220V/50Hz :More than 7A

240V/50Hz :More than 7A

Permissible Voltage Fluctuation : ± 10%

Permissible Extension Cord:

At least 300V, 30A capacity and less than 5

m (16.4”) long.

NOTE: 1.

Be sure to ground the machine. (Do

not connect the grounding wire to a gas

pipe.)

Make sure the plug is firmly inserted in

the outlet.

Avoid multi-wiring.

Do not set anything on the power cord.

1-4

SECTION 2

UNPACKING
