RGBlink Q16pro Manual de usuario
Q16pro
User Manual
Article No: RGB-RD-UM-Q16pro E000
Revision No: V1.0
Q16pro User Manual
1
Content
Declarations ............................................................................................................................................................. 2
FCC/Warranty ..................................................................................................................................................2
Operators Safety Summary ...........................................................................................................................3
Installation Safety Summary ......................................................................................................................... 3
Chapter 1 Your Product ....................................................................................................................................... 5
1.1 In the Box ...................................................................................................................................................5
1.2 Product Overview .....................................................................................................................................6
1.2.1 Rear Panel ..................................................................................................................................... 7
1.2.2 Front Panel .................................................................................................................................... 8
1.2.3 Dimension ...................................................................................................................................... 9
Chapter 2 Install Your Product ............................................................................................................................10
2.1 Plug in Signals ........................................................................................................................................ 10
2.2 Plug in Main Power ................................................................................................................................10
2.3 Turn on Your Product .............................................................................................................................10
Chapter 3 Use Your Product ............................................................................................................................... 11
3.1 Use the Menu Button .............................................................................................................................11
3.2 Menu Structure ....................................................................................................................................... 11
3.3 Use the Menu ..........................................................................................................................................12
3.3.1 Presentation .................................................................................................................................12
3.3.2 Split ............................................................................................................................................... 14
3.3.3 Advanced ......................................................................................................................................16
3.3.4 System ..........................................................................................................................................18
3.3.5 Scene Management ................................................................................................................... 19
3.4 Button ....................................................................................................................................................... 20
3.5 XPOSE 2.0 .............................................................................................................................................. 20
Chapter 4 Order Codes ........................................................................................................................................22
4.1 Product Codes ........................................................................................................................................ 22
4.2 Module Codes .........................................................................................................................................22
4.2.1 Input Modules ..............................................................................................................................22
4.2.2 Output Modules ...........................................................................................................................22
Chapter 5 Support .................................................................................................................................................23
5.1 Contact US .............................................................................................................................................. 23
Chapter 6 Appendix .............................................................................................................................................. 24
6.1 Specification ............................................................................................................................................24
6.2 Terms & Definitions ................................................................................................................................ 25
6.3 Revision History ......................................................................................................................................31
Q16pro User Manual
2
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and make use of all the
features. Please read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to
Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this equipment in a residential area
may cause harmful interference, in which case the user will be responsible for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of
guarantee. On receipt, the purchaser must immediately inspect all delivered goods for damage incurred
during transport, as well as for material and manufacturing faults. RGBlink must be informed immediately
in writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on
the date of commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of
compliant, RGBlink can repair the fault or provide a replacement at its own discretion within an appropriate
period. If this measure proves to be impossible or unsuccessful, the purchaser can demand a reduction in the
purchase price or cancellation of the contract. All other claims, in particular those relating to compensation for
direct or indirect damage, and also damage attributed to the operation of software as well as to other service
provided by RGBlink, being a component of the system or independent service, will be deemed invalid provided
the damage is not proven to be attributed to the absence of properties guaranteed in writing or due to the
intent or gross negligence or part of RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the
goods are handled incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the
transfer of risks, the goods are subject to influences not agreed upon in the contract, all guarantee claims of
the purchaser will be rendered invalid. Not included in the guarantee coverage are system failures which are
attributed to programs or special electronic circuitry provided by the purchaser, e.g. interfaces. Normal wear as
well as normal maintenance are not subject to the guarantee provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual
must be complied with by the customer.
Q16pro User Manual
3
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages.
To avoid personal injury, do not remove the top cover. Do not operate the unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts rms between
the supply conductors or between both supply conductor and ground. A protective ground connection by way
of grounding conductor in the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock, plug
the power cord into a properly wired receptacle before connecting to the product input or output terminals. A
protective-ground connection by way of the grounding conductor in the power cord is essential for safe
operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is in good
condition. Refer cord and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating characteristics.
Refer fuse replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all device installation procedures, please observe the following important safety and handling rules to
avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in
the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.
Q16pro User Manual
4
Unpacking and Inspection
Before opening device shipping box, inspect it for damage. If you find any damage, notify the shipping carrier
immediately for all claims adjustments. As you open the box, compare its contents against the packing slip. If
you find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed components
are present, visually inspect the system to ensure there was no damage during shipping. If there is damage,
notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your device should be clean, properly lit, free from static, and have
adequate power, ventilation, and space for all components.
Q16pro User Manual
5
Chapter 1 Your Product
1.1 In the Box
1x AC Power
Cord
2 x HDMI Cable
1 x Network
Cable
1 x Anti-static
Bag
1 x DB9-RJ11
Cable
1 x USB Disk
Note: AC Power Cable supplied as standard according to destination market.
Upgrading tool package and user manual are stored in the U disk, please keep it.
Q16pro User Manual
6
1.2 Product Overview
Q16pro edition supports up to 8 inputs, including HDMI 1.3, SD/HD/3G SDI (to be published), HDMI2.0,
H.264/265 for 2K and 4K signals. The standard unit comes with 4 HDMI 1.3 outputs and builds with local front
control panel and remote control interfaces with RS 232 and ethernet ports. Q16pro is available to be remote
controlled by XPOSE or 3rd party APP / controller by open API.
Q16pro combine rugged design, class-leading video processing and image quality, ultra-low latency, versatile 4K
connectivity, live streaming capabilities, and unmatched ease of use to meet the requirement of the modern
commercial display systems application, including live corporate meetings, hybrid events, worship productions,
or large-scale LED video wall installations.
Its outputs supports up to 4 independent displays, and 8 layers with arbitrary roaming capacity and
each layer can cross over each output without layer counting up.
Q16pro System Connection Diagram
Q16pro User Manual
7
1.2.1 Rear Panel
Input Connectors
1
Optional slots
2
Standard：
4×HDMI-IN, resolutions up to 1920*1080@60, support EDID
Output Connectors
3
Standard：
4×HDMI-OUT, resolutions up to 1920*1080@60, support EDID
Control Connectors
4
LAN RJ45 / RS232 RJ11
Use for system upgrade and remote control via APP
Power Socket
5
1×IEC power socket
3
5
4
1
2
Q16pro User Manual
8
1.2.2 Front Panel
Button Instruction
MENU and EXIT
SAVE SCENE
Adjust size and position of layers
Enter SPLIT menu
LOAD SCENE
Enter Layout Select menu
IN1-IN8 input signal selection
buttons and 1, 2, 3, 4, 6, 7, 8, 9
digital button
Layer 1-8 and 0, 5 digital button
Sleep Button
LCD Panel. Display current status of
the product, and for feature
selections,provides interactive
choices in conjunction with buttons
on the front panel.
Confirm by pushing, selecting
items by rotating
Q16pro User Manual
9
1.2.3 Dimension
Following is the dimension of Q16pro for your reference:
Dimension: 490mm x 343mm x 55mm
