RF-Star RF-SM-1077B2 Manual de usuario

RF-SM-1077B2 Ultra-Low-Power

433 MHz & 470 MHz Wireless Module

Version 2.1

Shenzhen RF-star Technology Co., Ltd.

Apr. 09th, 2020

RF-SM-1077B2

www.szrfstar.com V2.1- Apr., 2020

Shenzhen RF-star Technology Co., Ltd. Page 1 of 30

TI CC131X Sub-1 GHz Module List

Chipset

Core

FLASH

(KB)

RAM

(KB)

Model

Antenna

Freq.

(MHz)

Dimension

(mm)

Power

(dBm)

Range

(M)


CC1310

F128RGZ

128

RF-SM-1077B1

IPEX

868

915

18  26

2500

RF-SM-1077B2

IPEX

433

470

18  26

2500

CC1310

F128RSM

128

RF-SM-1044B1

PCB

868

915

14  22

2500

RF-SM-1044B2

PCB

868

915

9  12.5

2500

RF-SM-1044B4

Half-

hole

868

915

14  22

2500

Contact

CC1352R

M4F

352

RF-TI1352B1

IPEX

868

915

16.8  26.5

BLE:

500

ZigBee:

300

868 MHz:

1500

Note:

1. The communication distance is the longest distance obtained by testing the module's maximum transmission power

in an open and interference-free environment in sunny weather.

2. Click the picture to buy modules.

RF-SM-1077B2

www.szrfstar.com V2.1- Apr., 2020

Shenzhen RF-star Technology Co., Ltd. Page 2 of 30

1 Device Overview

1.1 Description

RF-SM-1077B2 Sub-1 GHz module is based on TI CC1310, which combines a flexible, very low-power RF transceiver

with a powerful 48 MHz ARM® Cortex®-M3 microcontroller supporting multiple physical layers and RF standards and a

dedicated radio controller Cortex®-M0 handling RF protocol commands that are stored in ROM or RAM. RF-SM-1077B2

integrates a 24.0 MHz crystal, a balun, a band pass filter, an antenna matching and an IPEX antenna matching which

make the module low cost, low power consumption and long wireless communication in Sub-1 GHz.

RF-SM-1077B2 is flashed transparent transmission firmware with AT commands by default. The default values are as

follows: 115200 baud rate, 8 data bit, no parity check bit,1 stop bit, 433 MHz operating frequency, 15 dBm TX power.

When the module starts to work, the serial port will print “Application Start\r\n”, and start transparent transmission mode

by default, serial port will transmit all the data except “+++”, please refer to the AT command in detail.

1.2 Key Features

•Microcontroller

- Powerful ARM® Cortex®-M3 processor

- EEMBC CoreMark® Score: 142

- EEMBC ULPBench™ score: 158

- Clock speed up to 48 MHz

- 128 KB of in-system programmable flash

- 8 KB of SRAM for Cache (or as general-purpose

RAM)

- 20 KB of ultra-low-leakage SRAM

- 2-pin cJTAG and JTAG debugging

- Supports over-the-air (OTA) update

•On-Chip Internal DC/DC Converter

•Ultra-Low-Power Sensor Controller

- Can run autonomously from the rest of the

- System

- 16-bit architecture

- 2 KB of ultra-low-leakage SRAM for code and data

•RF-Section

- Excellent receiver sensitivity: –124 dBm @ long-

range mode, –110 dBm @ 50 kbps

- Excellent selectivity (±100 kHz): 56 dB

- Excellent blocking performance (±10 MHz): 90 dB

- Programmable output power up to +15 dBm

- Differential RF interface

- Suitable for systems targeting compliance with

worldwide radio frequency regulations

➢ETSI EN 300 220, EN 303 204 (Europe)

➢FCC CFR47 Part 15 (US)

➢ARIB STD-T108 (Japan)

- Wireless M-Bus (EN 13757-4) and IEEE®

802.15.4g PHY

•Peripherals

- All digital peripheral pins can be routed to any

GPIO

- Four general-purpose timer modules (eight 16-bit

or four 32-bit timers, PWM each)

- 12-bit ADC, 200 ksamples/s, 8-channel analog

MUX

- Continuous time comparator

- Ultra-low-power clocked comparator

- Programmable current source

- UART

- 2× SSI (SPI, MICROWIRE, TI)

- I2C, I2S

- Real-time clock (RTC)

- AES-128 security module

RF-SM-1077B2

www.szrfstar.com V2.1- Apr., 2020

Shenzhen RF-star Technology Co., Ltd. Page 3 of 30

- True random number generator (TRNG)

- Support for eight capacitive sensing buttons

- Integrated temperature sensor

•Low Power

- Wide supply voltage range: 1.8 V to 3.8 V

- RX: 5.4 mA

- TX at +10 dBm: 13.4 mA

- Active-mode MCU 48 MHz running Coremark: 2.5

mA (51 μA/MHz)

- Active-mode MCU: 48.5 CoreMark/mA

- Active-mode sensor controller at 24 MHz: 0.4 mA

+ 8.2 μA/MHz

- Sensor controller, one wake-up every second

performing one 12-bit ADC sampling: 0.95 μA

- Standby: 0.7 μA (RTC running and RAM and CPU

retention)

- Shutdown: 185 nA (wakeup on external events)

1.3 Applications

•433-, 470-MHz ISM and SRD systems

•Low-power wireless systems with 50-kHz to 5-MHz

channel spacing

•Home and building automation

•Wireless alarm and security systems

•Industrial Monitoring and Control

•Smart grid and automatic meter reading

•Wireless healthcare applications

•Wireless sensor networks

•Active RFID

•IEEE 802.15.4g, IP-enabled smart objects

(6LoWPAN), wireless M-Bus, KNX systems,

Wi-SUN™, and proprietary systems

•Energy-harvesting applications

•Electronic shelf label (ESL)

•Long-range sensor applications

•Heat-cost allocators

1.4 Functional Block Diagram

Figure 1. Functional Block Diagram of RF-SM-1077B2

CC1310

RGZ

GPIOs

Reset

IPEX

Interface

Band Pass

Filter

Power Supply

1.8 V ~ 3.8 V

Antenna

Matching

24.0 MHz

Balun

32.768 kHz

RF-SM-1077B2

www.szrfstar.com V2.1- Apr., 2020

Shenzhen RF-star Technology Co., Ltd. Page 4 of 30

1.5 Working Mode

Figure 2. Working Mode of RF-SM-1077B2

1.6 Part Number Conventions

The part numbers are of the form of RF-SM-1077B2 where the fields are defined as follows:

Figure 3. Part Number Conventions of RF-SM-1077B2

1077

RF-STAR

Company Name

Sub-1 GHz Module

Wireless Type

Chipset Manufacturer

TI CC1310F128RGZ

Module Version

The Second Version

                RF-SM-1077B2
www.szrfstar.com                                                                           V2.1- Apr., 2020
Shenzhen RF-star Technology Co., Ltd.                                                                                                                    Page  5  of  30
