DESKSIDE AND OFFICE

230V MACHINES

ILLUSTRATED PARTS LISTS

AND

SERVICE INSTRUCTIONS

Compiled by David Bird Issue No 7

Approved by Paul Aries (Technical Manager) Date

REXEL BUSINESS MACHINES, DROITWICH, WORCESTERSHIRE, WR9 9AP, ENGLAND

TELEPHONE +44 (0) 1905 771555 FAX +44 (0) 1905 823374

Deskside and Office 230vissue7 1 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230V

DESKSIDE AND OFFICE MODELS

TABLE OF CONTENTS

ILLUSTRATED PARTS MANUAL

DESKSIDE AND OFFICE

SERIES 7 SHREDDERS – 230 VOLTS

Contents Page 1 – 2

Preface Page 3

Illustrations and Parts Lists with

Recommended Spares Pages 4 - 28

CUTTING HEADS

Model 250 S2, Straight Cut Pages 4 – 5

Model 250 S3 and S4, Cross Cut Pages 6 – 8

Models 250 S5, Cross Cut Pages 9 - 10

Models 1150 S2 and 1250 S2,

Straight Cut Pages 11 – 13

Model 1150 S3 and 1250 S3 and S4,

Cross Cut Pages 14– 16

Model 1250 S5 Pages 17– 19

CABINETS

Models 250 Pages 20– 21

Models 1150 Pages 22 – 23

Models 1250 Pages 24 – 25

ELECTRICAL

Models 250 Page 26

Models 1150 Page 27

Models 1250 Page 28

Deskside and Office 230vissue7 2 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230V

DESKSIDE AND OFFICE MODELS

SERVICE INSTRUCTIONS Pages 29 – 64

Operational test procedures Page 29

Top Cover Pages 30 - 32

Cutting heads Page 33

Printed Circuit Boards Page 34

Optical Sensors Page 35

Electric Motors Page 36 – 37

Gears Page 38 – 39

Tie Bars, Cutting Shafts, Paper Feed Pages 40 – 46

LCD Operation Pages 47 – 49

WIRING DIAGRAM Pages 50 - 54

Model 250 S2 Page 50

Model 250 S3, S4, S5 Page 51

Model 1150 S2, 1150 S3 Page 52

Model 1250 S2,S3,S4 Page 53

Model 1250 S5 Page 54

SPECIFICATIONS Pages 55 – 64

Amendment Record Page 65

Deskside and Office 230vissue7 3 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230V

DESKSIDE AND OFFICE MODELS

PREFACE

This manual provides the instructions for the replacement of all the components that may become worn

or damaged. Details of replacement parts and ordering information are given in associated illustrated

parts list.

Illustrated Parts Lists

For each machine, these give full details of the replacement part numbers with supporting diagrams to

show the location of the components.

Service Instructions

For each machine, these give the recommended servicing procedure with supporting pictorial diagrams

for added clarity and applies from the following serial nos:-

250 S2 A629960 250 S3 A630080 250 S4 A630120

250 S5 A630130 1150 S2 A631455 1150 S3 A630180

1250 S2 A629166 1250 S3 A634672 1250 S4 A630205

1250 S5 A629281

WARNING

1. Check the machine RATING PLATE DETAILS are compatible with the electrical mains supply.

2. Disconnect the electrical mains supply before removing any covers.

3. After removing the cover on single phase machines, DISCHARGE the capacitor by shorting out its

connections. (BEWARE: PAPER DUST IS A POTENTIAL FIRE HAZARD).

4. The machine MUST have a sound Electrical Earth connection.

NOTE: THE ELECTRIC MOTOR IS PROTECTED BY AN AUTOMATIC THERMAL

OVERLOAD CUT-OUT.

Deskside and Office 230vissue7 4 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

MODEL 250 S2 CUTTING HEAD

No Description Part Qty COMMENTS

1 1:1 Gear 9709 2

2 ½” Circlip TRU95 2

3 Gear 56 Tooth A44259 1

4 Circlip, 10MM TRU66 1

5 Washer, M10 Flat PLN33 1

6 Compound Gear D44261M7 1

7 Screw, M5 x 16 SCM20 4

8 Washer, M5 Shakeproof SHK10 4

9 Screw, M6 x 12 SCM15 4

10 Washer, ¼” Shakeproof SHK4 12

11 Motor, 75W SL20-284 1

12 Cutter Shaft – Drive D53017 1

13 Pin, Gear Locating PM1 3

14 Tie Bar D53012 2

15 Stripper Plate (rear) D53008 1

16 Stripper Plate (front) D53009 1

17 Side Frame (Bearing) D53031 1

18 Grommet GRM20 1

19 Location Plate D53077 2

20 Grommet GRM22 1

21 Nut, M6 NM5 8

22 Vibration Isolator SL18-305 4

23 Nut Protection Cap SL18-325 2

24 Cutter Shaft – Driven D53016 1

25 Deflector Tab D53068 2

26 Bush D53511 4

27 Side Frame (Motor) D53015+ D53094 1 Includes gear shaft

Gear shaft D50083

28 Pop Rivet RTS68 4

CUTTING HEAD ASSEMBLY A53055SP 1 All except 1,3,6,11,12,19,21

SIDE FRAME ASSEMBLY (mtr) A53039SP 1 Comprises 20,27,28

SIDE FRAME ASSEMBLY (brg) A53038SP 1 Comprises 18,20,27

SHREDDER OIL, 500ML 40100 1

29 Motor Earth Wire D50105 1

skside and Office 230vissue7 5 01/02/02

ue 6

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

MODEL 250 S2 CUTTING HEAD

Deskside and Office 230vissue7 6 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

MODEL 250 S3 and S4 CUTTING HEAD

No Description Part S3 S4 Comments

1 Side Frame (Motor) D53014 1

1 Side Frame (Motor) D53058 1

2 1:1 Gear D53028 2 2

3 Circlip, 17MM TRU88 1 1

4 Lost Motion Collar D53790 1 1

5 Spur Gear Assembly A53650 1 1

6 Gearbox Spacer D53520 1 1

7Pin,Dowel PEG91 66

8 Plate, end closing D53065 1 1

9 Bolt, M5 x 70MM

Plated

SCM151 5 5

10 Ball bearing BR23 1 1

11 Ball bearing BR28 2 2

12 Compound Gear

Assembly

A53547 1

12 Compound Gear

Assembly

A53547 1

13 Screw, M5, CSK Nyloc SCM152 2 2

14 Screw, M5 x 10 SCM9 2 2

15 Washer, M5 Shakeproof SHK10 2 2

16 Deflector Tab D53067 2 2

17 Motor, 300W SL20-303 1

17 Motor, 150W SL20-301 1

18 Screw, M6 x 12 SCM15 12 12

19 Washer, ¼” Shakeproof SHK4 12 12

20 Tie bar, top motor D53032 1 1

22 Motor Fan Supplied with Motor

23 Tie Bar D53012 5 5

24 Infeed chute (rear) D53036 1 1

25 Bin Full Flap D53033 1

25 Bin Full Flap D53083 1

26 Grommet SL18-333 2 2

27 Bearing D53064 4 4

28 Grommet GRM22 1 1

29 Pop Rivet RTS68 4 4

30 Snap Bush SL18-369 1 1

31 Side Frame (Bearing) D53034 1

31 Side Frame (Bearing) D53059 1

32 Location Plate D53087 2

32 Location Plate D53057 2

33 Vibration Isolator SL18-305 4 4

34 Washer, plain PLN4L 8 8

35 Nut M6 NM5 8 8

Deskside and Office 230vissue7 7 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

No Description Part S3 S4 Comments

36 Nut protection cap SL18-325 2 2

37 Infeed Chute (front) D53035 1 1

38 Not used

39 Stripper Cross Cut D53010 144

39 Stripper Cross Cut D53086 138

40 Cutter shaft – Driven D53018 1

40 Cutter shaft – Driven D53020 1

41 Key 5X5X16 KEY32 2 2

42 Cutter Shaft – Drive D53019 1

42 Cutter Shaft – Drive D53021 1

43 Key, Woodruff KEY33 1 1

END PLATE

ASSEMBLY

A53526SP 1 1 Comprises 8,10,11

GEARBOX SPACER

ASSEMBLY

A53531SP 1 1 Comprises 6,7

SIDE FRAME ASS.

(BEARING)

A53041SP 1 Comprises 31,32,27

SIDE FRAME ASS

(MOTOR)

A53042SP 1 Comprises 1,11,32,27

CUTTING HEAD

ASSEMBLY

A53060SP 1 Comprises all except 17,21,22,28,30,13

CUTTING HEAD

ASSEMBLY

A53061SP 1 Comprises all except 17,21,22,28,30,13

SIDE FRAME ASS.

(MOTOR)

A53069SP 1 Comprises 31,32,27

SIDE FRAME ASS.

(BRG)

A53071SP 1 Comprises 31,32,27

SHREDDER OIL, 500

40100 1 1

skside and Office 230vissue7 8 01/02/02

ue 6

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

MODEL 250 S3 and S4 CUTTING HEAD

Deskside and Office 230vissue7 9 01/02/02

ILLUSTRATED PARTS MANUALS

SERIES 7 SHREDDERS – 230v

DESKSIDE AND OFFICE MODELS

MODEL 250 S5 CUTTING HEAD

No Description Part Qty Comments

1 Side Frame (Motor) D53141 1

2 1:1 Gear D53530 2

3 Circlip, 17mm TRU88 1

4 Lost Motion Collar D53790 1

5 Spur Gear Assembly A53650 1

6 Gearbox Spacer D53520 1

7Pin,dowel PEG91 6

8 End Closing Plate D53831 1

9 Bolt, M5 x 70MM, Plated SCM151 5

10 Ball Bearing BR23 5

11 Ball Bearing BR28 2

12 Compound gear assembly A53547 1

13 Screw, M5 x 12 CSK Nyloc SCM152 2

14 Screw M5 x 10 SCM9 2

15 Washer, M5 Shakeproof SHK10 2

16 Key, Woodruff KEY33 1

17 Deflector Tab D53067 2

18 Motor, 300W SL20-303 1

19 Screw, M6 x 12 SCM15 6

20 Washer, ¼” Shakeproof SHK4 12

21 Tie bar, top motor D53032 1

23 Motor fan Supplied with motor

24 Tie bar D53012 1

25 Infeed Chute (rear) D53036 1

26 Bin Full Flap D53033 1

27 Grommet SL18-333 2

28 Not used

29 Cutter Shaft – Drive D53005 1

30 Grommet GRM22 1

31 Pop Rivet RTS68 4

32 Snap Bush SL18-369 1

33 Side Frame (bearing) D53040 1

34 Location plate D53037 2

35 Vibration Isolator SL18-305 4

36 Washer, plain PLN4L 12

37 Nut, M6 NM5 8

38 Nut Protection Cap SL18-325 2

39 Infeed Chute (front) D53035 1

40 Lock-nut 9076BI 4

41 Collar, Cutter Shafts 44808 2

42 Stripper Bar (security) D53011 2

43 Screw, M6 x 16 CSK, Skt Hd SCM104 2

44 Cutter Shaft – Driven D53004 1

45 Stripper 44815 324

46 Spacer 9115B 324

47a Cutter 14737 162

47b Cutter, knurled 14738 162

48 Key 5x5x16 KEY32 2

SIDE FRAME ASS. (BEARING) A53043SP 1 Comprises 10, 33, 34

SIDE FRAME ASS. (MOTOR) A53147SP 1 Comprises 1, 10, 34

CUTTING HEAD ASS. A53062SP 1 Comprises All except 18, 23, 30, 22, 32, 13

END PLATE ASS. A53153 1 Comprises 8, 10, 11

GEARBOX SPACER ASS. A53531SP 1 Comprise 6, 7

SHREDDER OIL, 500ML 40100 1
