Reveal PRO3 Manual de usuario
INSTRUCTION MANUAL
REVEALCELLCAM.COM
TACTACAM.COM
DEER MANAGEMENT SYSTEMS, LLC
INSTRUCTION MANUAL
PRO3
2
REVEAL APP DOWNLOAD
V I S I T Y O U R A P P S T ORE T O DOWNL O A D
DOWN L O A D T H E
TACTACAM REVEAL APP
TACTACAM.COM
3
TABLE OF CONTENTS
INTRODUCTION
What is in the Box?
What you will need
QUICK START GUIDE
Setting Up Your Account
Downloading the App
Add Camera to the App
Sending a Test Picture
Leaving Your Camera in the Field
SETTINGS & SPECIFICATIONS
BEST PRACTICES
Proper Camera Placement
Batteries and Cellular Trail Camera Performance
TROUBLESHOOTING
Camera Sends Pictures of Nothing
Night Vision Flash Range Doesn’t Meet Expectations
Camera Stops Taking Images or Won’t Take Images
WARRANTY
3
4
4
4
6
6
6
7
8
9
10
12
12
13
14
14
14
15
16
TABLE OF CONTENTS
4
• (1) Trail Camera
• (1) Instruction Manual
• (1) Mounting Strap
• (1) Antenna
• (1) Verizon & AT&TSIM Card
• Full-size SD Card - Class 10, U3,
• 16GB-32GB
• Recommended Brands: Tactacam,
Lexar, SanDisk
(Other brands of lower end SD cards are
incompatible with the Reveal X-Pro and will
yield unexpected results)
• 12 AA Batteries Required -
Lithium Batteries recommended
in colder temperatures
INTRODUCTION
WHAT IS IN THE BOX? WHAT YOU WILL NEED
RECOMMENDED CAMERA ACCESSORIES (NOT INCLUDED)
SD Card Solar Panel
T-Post MountLockable Security Box
VIEW AND PURCHASE ALL ACCESSORIES AT REVEALCELLCAM.COM
Adjustable Camera Stake
Reveal Pro 3.0 and will
TACTACAM.COM
5
1
5
2
6
10
14
3
7
11
15
4
8
12
9
13
INTRODUCTION
Lens
Antenna
Camera Working Status Indicator
Microphone
SIM Slot (do not mix SIM’s with other cameras)
Display
PIR Motion Sensor
IR LEDs
Navigation Arrows
SD Card Slot
Power/Enter
Battery Eject Button
External Battery In/DC Port
USB-C Port
Tripod/Mount Attachment
9
4 10
7
12
1
2 8
3
5 11
6
13 14
15
6
QUICK START GUIDE
In your Apple orGoogle Play Store, download the
Tactacam Reveal app and sign inusing the same
email and password you created on the website.
https://account.revealcellcam.com
DOWNLOADING THE APP
please visit the Reveal Web Portal at
https://account.revealcellcam.com/activation
to set up your account. You can also access the
Web Portal directly from your app, by clicking
My Reveal on the account page in the app.
If you already have a Reveal account with
ACTIVE cameras, you can simply log in to
your app and add your camera following the
instructions on page 8.
SETTING UP YOUR ACCOUNT
TACTACAM.COM
7
QUICK START GUIDE
ADD CAMERA TO THE APP
1. Navigate to your Reveal app and login
using your Revealaccount credentials.
Click the home icon.
2. Click the camera icon at the top.
3. From the camera page click the (+) in the
bottom right hand corner.
4. Select Reveal X-Pro and continue.
5. Follow the in-app prompts to activate
your Reveal. Ensure the SIM selected
(Verizon or AT&T) mirrors (or is the same
as) the SIM card already inserted in the
camera.
6. The app will prompt you to scan the QR
code located on the display screen.
1
2
3
4
6
Select the Reveal Pro3 and continue.
8
QUICK START GUIDE
From the camera page click the tool icon to make
changes to the cameras settings. Make sure to
select “Apply Settings” when done to save your
changes.
Note: In cameras SETTINGS > Settings Check,
Daily mode will check settings every 24 hours.
Hybrid mode combines the battery saving
will receive settings instantly but will consume
more battery.
X-Pro allows you to fully control your camera settings directly on-screen. Use the
keypad to navigate (left, right, up, down, enter) to adjust camera settings. For best
results, we recommend leaving the camera settings in the factory programmed
SMS CONTROLS/ON-SCREEN SETTINGS
1. Allow the camera to connect to 4G signal.
Your signal strength will be displayed on
the screen.
SENDING A TEST PICTURE
REMOTELY CHANGE THE CAMERA SETTINGS FROM THE APP.
• After your camera is activated, you will see
the signal status indicator searching, and
then connect showing the signal strength.
• After the camera has connected, push the
power/enter button to send a photograph.
Pro 3.0 allows you to fully control your camera settings directly on-screen. Use the
TACTACAM.COM
9
1. Using the display screen on the Reveal, position the camera to your
desired focal point.
2. Ensure the antenna is securely tightened.
3. Wipe down the seal, removing any dirt or debris.
4. Hit the left navigation arrow to enter work mode (work mode means
the camera is on and will function correctly). From there, your camera
will begin sending you photos.
5. As long as your phone picks up a signal, be sure a motion detected
picture is sent to your phone via the app. This may take a few minutes.
LEAVING YOUR CAMERA IN THE FIELD
START USING THE REVEAL X-PRO
SENDING A TEST PICTURE (CONTINUED)
• When your test picture has been sent successfully, a message is
displayed on the screen notifying you.
• If your test picture does not send, a send failure message will display
on the screen.
2. As long as your phone picks up a signal, be sure a motion detected
picture is sent to your phone via the app. This may take a few
minutes.
START USING THE REVEAL PRO3
10
SETTINGS / SPECIFICATIONS
Camera Mode Photo; Photo+Video
Day/Night Mode Daytime: Color, Nighttime: B+W
IR Range 80+ Feet
PIR Angle 45*
Flash No Glow IR Technology effectively eliminates all
Operating Keys (2) 1x Power button; Navigation arrows
Lens F=6mm; F/No=2.0;
FOV=60* Auto IR-Cut-Remove (at night)
SD Card Class 10, U3, 16GB-32GB, minimum 90MB/Sec
Status Indicator 1 LED
Picture Format JPEG
Video Optional
Trigger Speed 0.5 seconds
SD Card Loop Optional
Operation Power 9-12V
Battery X = 12xAA Cartridge
Optional external power source (12V external
battery pack or solar panel)
- Barrel plug reducer size 4x1.7mm
External DC 12V-2A
TACTACAM.COM
