Rently Access Panel 3 Manual de usuario
Access Panel 3
Installation Manual
INDEX 2
Smart Access Control System
Introduction 3
Access Panel Installation
Prior to Installation 4
ÆÆÐĮĮqĊÐăwĨÐÆðťÆĴðďĊĮ Ǥ
Access Panel Installation 6
Exit Button Installation 7
Power Supply Installation 8
Lock Type Installation
Metal Lock Bracket 9
Electromagnetic Lock 11
Electric Strike 14
Wiring Diagrams
Electromagnetic Lock 16
Electric Strike 17
24V Lock 18
Support
19
Outside View Inside View
SMART ACCESS CONTROL SYSTEM 3
Introduction
The Rently Access Panel 3 is a cloud-based access panel that can
be used to easily track, change, and manage FOB and door code
credentials. The Access Panel 3 can be used to control any access
device that is operated by a normally open or normally closed signal
as long as the voltage requirements are met. NOTE: this system
only supports Mifare FOBs and does not integrate with HID FOBS.
The Rently Access Panel 3 stores all valid credentials within the
device. It contains a Bluetooth antenna that connects to a
cloud-enabled hub installed nearby. This allows you to place secure
access points all over a building without having to wire a central
control system.
General Install Location
Prior to Installation
• Check that all components are available
• Rently Access Panel 3
• Screw on co-ax antenna (4 in and 6 ft antennas provided)
• Exit Button
• Power Supply Controller
• Rently Hub
• Wall anchors or other mounting hardware
• Your preferred lock type including but not limited to:
• Electromagnetic Lock and lock bracket
• Electric Strike Lock
• Electric Bolt Lock
• Electric Cabinet Lock
• NOTE: This is a kit, and not all components will be used. Please
recycle parts that are not necessary for your application.
• Prepare the following tools. NOTE: additional tools may be
īÐĪķðīÐÌåďīřďķīĮĨÐÆðťÆĨĨăðÆĴðďĊȚ
• Hammer
• Drill
• Drill Bit Set
• Screwdriver Set
• Identify the door type and verify that you have the correct
mounting bracket and hardware for the install.
• Locate the power source for the power supply controller.
UZ}'ȚďķĉřĊÐÐÌĴďìŒÐÆÐīĴðťÐÌÐăÐÆĴīðÆðĊīķĊĨďœÐīĴď
the install location.
• To ensure the best performance, check to make sure your Rently
Hub is installed in an optimal location within 10 feet of your
Access Panel with minimal obstructions.
• ADA considerations:
• The Exit Button and the Rently Access Panel 3 should be
installed in accordance with your local ADA requirements.
Recommended height does NOT guarantee ADA compliance.
ACCESS PANEL INSTALLATION
4
#ðĉÐĊĮðďĊĮ ǧǟŘǠǤǟŘǡǧĉĉȧǢȘǠŘǤȘǨŘǠȘǠðĊȨ
ÐðæìĴ ǦǢǧȘǤæȧǠȘǥǢăÅȨ
Power Supply 12V/24V AC, 12V/24V DC
Output Mode Normally Open/Normally Closed
sķðÐĮÆÐĊĴķīīÐĊĴ ɗǡǤĉ
U9AĊÌķÆĴðďĊ#ðĮĴĊÆÐ ɗǠȘǤĉĉȧǟȘǟǥðĊȨ
Maximum Current 300mA
Wireless Connections Bluetooth 4.0, NFC
Code and FOB Capacity 2000
ZĨÐīĴðĊæĴÐĉĨÐīĴķīÐ ȭǢǟĴďǦǟɰȧȭǡǡĴďǠǤǧɰ9Ȩ
Card Type CPU Card, IC Card
ZĨÐīĴðĊæ>ķĉðÌðĴř ǟĴďǨǤɦȧt>Ȩ
ÆÆÐĮĮqĊÐăwĨÐÆðťÆĴðďĊĮ
ACCESS PANEL INSTALLATION
5
Access Panel Installation
1. Run a power cable to the location where the Rently Access Panel 3
will be mounted. Remove the security screw from bottom of
Access Panel 3 with the wrench that is provided and take off the
mounting plate. Apply a bead of silicone around the area shown
before mounting the plate to the wall.
2. Insert the power and control cables through the mounting plate.
ǢȘqīÐĮĮĴìÐĉďķĊĴðĊæĨăĴÐťīĉăřæðĊĮĴĴìÐĉďķĊĴðĊæĮķīåÆÐĊÌ
secure with screws.
4. Connect the power and control cables from the Access Panel 3
according to the appropriate wiring diagram (see page 16).
ǤȘďĊĊÐÆĴĴìÐĊĴÐĊĊÅřĮÆīÐœðĊæďĊĴìÐÆďȭŘÆÅăÐȘAåĴìÐìķÅðĮ
nearby, you may use the 4 in antenna and tuck it into the wall. If a
stronger signal is required, the 6 ft antenna should be mounted in
a location free from large metal obstructions , including wire mesh
used for stucco.
6. Hook the top edge of the Access Panel 3 on the mounting plate
and swing the panel in until fully seated. Secure in place with the
security screw and provided wrench.
NOTE: Stow the provided security tool in an accessible location for
future service. A 6-lobe with center pin tamper resistant screw
driver may be used if needed.
ACCESS PANEL INSTALLATION 6
Size 86 x 86 x 40mm (3.4 x 3.4 x 1.6in)
Weight 180g (0.4lb)
TÐÆìĊðÆăOðåÐ ǤǟǟșǟǟǟĨīÐĮĮÐĮ
Install Location Hollow wall or door
ZĨÐīĴðĊæ}ÐĉĨÐīĴķīÐ ȭǢǟɰĴďǦǟɰȧȭǡǡɰ9ĴďǠǤǧɰ9Ȩ
ZĨÐīĴðĊæ>ķĉðÌðĴř ǟɛǨǤɦȧīÐăĴðŒÐìķĉðÌðĴřȨ
Panel Material PC
ķīīÐĊĴtĴðĊæ ǠǥɩǡǤǟ
Output Contact NO/COM
'ŘðĴķĴĴďĊwĨÐÆðťÆĴðďĊĮ
Exit Button Installation
1. Connect the wires per the wiring diagram section.
2. Pry the plastic faceplate away from the switch body.
3. Tuck the wires into the wall to sit behind the switch.
4. Secure the switch to the desired location using two screws.
ǤȘwĊĨĴìÐåÆÐĨăĴÐÅÆāðĊĴďĨďĮðĴðďĊœðĴìťīĉĨīÐĮĮȘÐĮķīÐ
all the corners snap back into place.
ACCESS PANEL INSTALLATION 7
TÐĴăOďÆāīÆāÐĴwĨÐÆðťÆĴðďĊĮ
Several brackets are available to accommodate many different
types of doors. See diagrams for additional details.
LOCK TYPE INSTALLATION 9
Glass Door
Bottom Bracket
Rubber Blanket
Rubber Blanket
Screw Adjusting Paper
Lock Plate
Top Bracket
Top Glass
Iron Mounting Plate
Chart 1
Screw
Screw
Adjusting Paper
Glass Door
Iron Mounting Plate
Bottom Bracket
Rubber Blanket
Rubber Blanket
Lock Plate
Top Bracket
Lock Plate
Top Glass
Chart 2
Metal Lock Bracket Installation
1. Measure the gap between the door leaf and door frame.
2. Install the top bracket according to the diagram. Set the screw,
keeping the screw head inside the U-shaped slot.
3. Put the rubber mounting plate and iron mounting plate into the
U-shaped slot. For easier installation, you may use double-
sided adhesive between the rubber mounting plate and the
U-shaped slot.
4. Secure the top bracket in the correct position with 4 screws.
ǤȘAĊĮĴăăĴìÐĉæĊÐĴðÆăďÆāÆÆďīÌðĊæĴďĴìÐÌðæīĉȘ
6. Put the bottom bracket on the glass door.
7. If the door gap is too big, put the paper shim inside, adjust the
æĨĴďǡĉĉÅÐĴœÐÐĊĴìÐÅīÆāÐĴĮșĴìÐĊťŘœðĴìǣĮÆīÐœĮȘ
8. Install the lock plate. Make sure the back of the lock plate is
installed with a rubber gasket to absorb the impact of opening
and closing the door.
9. Turn on the power and test the locks to ensure that they are
working properly.
LOCK TYPE INSTALLATION 10
