PHOENIX 300
POWER STATION
User Guide
Model: R300PHX
- 01 -
TABLE OF CONTENTS
- 02 -
IMPORTANT SAFETY INSTRUCTIONS 03
PACKAGE CONTENTS 04
FEATURES 04
RECHARGING YOUR PHOENIX 300 07
BATTERY LEVEL LED INDICATORS 07
PRODUCT OVERVIEW 05
SPECIFICATIONS 06
TROUBLESHOOTING 13
FREQUENTLY ASKED QUESTIONS 16
WARRANTY 17
OPERATING YOUR PHOENIX 300 10
MAINTENANCE 12
Please read the User Guide carefully before recharging or operating your Phoenix 300.
IMPORTANT SYMBOLS
Indicates potentially dangerous conditions that could result in personal injury
Indicates conditions or practices that could result in damages to the unit or other
equipment
Indicates procedures or functions that are important for proper and safe operation
of the unit and/or other equipment
CAUTION
WARNING
NOTE
DO NOT drop or strike the unit. Doing so may cause circuit failures and cracks in the casing.
DO NOT dismantle or modify the unit. Doing so may cause irreversible damages to the unit and
void warranty.
Please turn off the output ports when no devices are connected to the unit to prevent electric
shocks.
Please dispose of the product according to the local recycling and environmental regulations.
DO NOT overload the AC or DC outputs. Please check the specifications of output ports and
devices before operation.
DO NOT submerge the unit in water or operate the unit in the rain. Doing so may cause
short-circuits, electric shocks, and/or fire.
DO NOT place the unit near fire and/or heat the unit. Doing so may cause irreversible damages
to the unit and/or battery explosion.
Please check the unit before each use. Stop using the unit if you notice unusual smells, heating,
distortion, or any other abnormalities.
DO NOT expose the unit to strong electrostatic fields, strong magnetic fields, and/or radiation.
DO NOT place the unit under direct sunlight or place in high-temperature situations. Doing so
may cause unit malfunction or component degradation.
Keep the unit out of the reach of young children.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
WARNING
WARNING
WARNING
WARNING
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
CAUTION
- 03 -
FEATURES
PACKAGE CONTENTS
REVOLUTIONARY SPEED
The PHOENIX 300’s USB-C port features Power Delivery (PD) technology that can pump out up to 60W power
to compatible devices. Quick Charge (QC) technology allows for up to 18W of output power from the USB-A
port.
VERSATILE POWERING OPTIONS
The PHOENIX 300 is equipped with multiple commonly used output ports to power essential gadgets and small
appliances, while a D-Tap port is at the ready for your photography and videography equipment.
PURE SINE WAVE
Produce clean, silent, and stable AC power up to 200W with the pure sine wave inverter to power delicate
electronic devices efficiently and safely.
ULTIMATE SAFETY
The battery management system (BMS) commands voltage control, temperature control, short circuit
protection, and overcurrent protection to keep both the power station and your devices safe from damage.
1 x Renogy PHOENIX 300 Power Station
1 x User Guide
1 x AC/DC Adapter
1 x Solar Panel Connectors to 5.5mm DC Adapter Cable
1 x USB-C to USB-C Cable
1 x USB-A to USB-C Cable
- 04 -
PRODUCT OVERVIEW
D-TAP/CIG
USB
AC LIGHT
IN/OUT
TYPE-C 60W PD
DC IN
D-TAP
USB
43
12
11
10
6
5
2
13
9
8
7
1
14
16
15
- 05 -
SPECIFICATIONS
Port On/Off Buttons
Flashlight On/Off Button
Main Power Button
AC Outlets
DC Input Port
Folding Carrying Handle
LED Flashlight
Air Vent
16
15
14
13
12
11
10
9
Battery Level LED Indicators
Port Status LED Indicators
Flashlight Status LED Indicators
CIG Port
QC USB-A Port
USB-A Ports
USB-C PD Port
D-Tap Port
8
7
6
5
4
3
2
1
Output
3.6-6V / 3A, 6.5-9V / 2A, 9-12V / 1.5A, 18W Max
5V / 2.4A Each, 3.4A Total Max
5-20V, 60W Max
QC USB-A Port
USB-A Port (2)
USB-C PD Port
Input
12-25V, 50W Max
5-20V, 60W Max
110W Max
DC Input Port
USB-C PD Port
Total
Battery
General
Lithium-ion Battery
14.4V
23400mAh / 337Wh
1000 Cycles to 80% Capacity
Type
Voltage
Capacity
Cycle Life
181 x 155 x 143 mm / 7.1 x 6.1 x 5.6 in.
2.9 kg / 6.4 lb.
PC + ABS
2 x 1.6W LED
0-40 ℃/ 32-104 ℉
0-45 ℃/ 32-113 ℃
45-95%
FCC, CE, PSE, RoSH
Dimension
Weight
Material
Flashlight
Normal Operating Temperature
Storage Temperature
Operating / Storage Humidity
Certifications
- 06 -
BATTERY LEVEL LED INDICATORS
RECHARGING YOUR PHOENIX 300
AC Outlet (2)
Total Continuous Output
110V / 60Hz (US, JP, CA)
220V / 50Hz (AU, EU, CN)
200W Rated, 350W Surge
Pure Sine Wave
300W Max
CIG Port
D-Tap Port
11-17V / 10A Max
11-17V / 10A Max
When recharging your PHOENIX 300, one of the Battery Level LED Indicators will flash. The flashing LED
indicates the unit’s current battery level. Once your PHOENIX 300 is fully recharged, all Battery Level LED
Indicators will be lit and remain solid.
When the battery level of PHOENIX 300 is lower than 15%, the last Battery Level LED Indicator will flash twice
per second.
As you use your PHOENIX 300 to power other devices, the Battery Level LED Indicators will go out one by
one to indicate the remaining battery capacity.
Four Battery Level LED Indicators indicate the battery level of the PHOENIX 300, approximating 25% - 50%
- 75% - 100% capacity.
To shorten the recharge time of PHOENIX 300, it is recommended to disconnect all loads while
recharging the unit.
NOTE
To maximize battery life, be sure to fully recharge your PHOENIX 300 before operating or
storing.
If the Battery Level LED Indicators flash in an unusual way, your PHOENIX 300 may need
special attention. Please refer to the TROUBLESHOOTING section for help.
Recharge Time
Recharge via USB-C PD Wall Charger: 6 Hours
Recharge via both AC/DC Adapter and USB-C PD Wall Charger: 3.5 Hours
Recharge via AC/DC Adapter: 8 Hours
Recharge via Solar: 8 Hours
CAUTION
CAUTION
- 07 -
The above recharge times are based on conditions when the PHOENIX 300 is recharged at full
speed with no loads connected to it.
NOTE
Recharging via Solar
The PHOENIX 300 will begin to recharge automatically and one of the Battery Level LED Indicators will flash.
The flashing LED indicates the unit’s current battery level.
Use the included Solar Panle Connectors to DC Adapter Cable to connect the solar panel to the DC Input Port
of your PHOENIX 300 and place your PHOENIX 300 in the shade to prevent it from overheating.
Place the solar panel under direct sunlight. Steer clear of trees or branches that can shade the solar panel
and slow down the recharging process.
For optimal recharging performance, it is strongly recommended to recharge your PHOENIX 300 using a
compatible solar panel (not included) on bright sunny days free of scattered clouds.
D-TAP/CIG
USB
AC LIGHT
IN/OUT
TYPE-C 60W PD
DC IN
D-TAP
USB
Compatible Solar Panels:
Renogy E.FLEX Series Portable Solar Panel: 50W
Renogy Flexible Solar Panel: 50W, 100W
Renogy ECLIPSE Series Foldable Solar Suitcase w/o Controller: 100W
Renogy Monocrystalline Foldable Solar Suitcase w/o Controller: 100W
Renogy ECLIPSE Series Solar Panel: 100W
Renogy Polycrystalline Solar Panel: 50W, 100W
Renogy Monocrystalline Solar Panel: 50W, 80W, 100W
- 08 -
Make sure the open circuit voltage of the solar panel does not exceed 25V or fall short of 12V.
CAUTION
The solar recharge time is highly dependent on solar irradiance and ambient temperature.
NOTE
Recharging via AC/DC Adapter
The PHOENIX 300 will begin to recharge automatically and one of the Battery Level LED Indicators will flash.
The flashing LED indicates the unit’s current battery level.
Plug your PHOENIX 300 into a wall outlet through the DC Input Port using the included AC/DC Adapter.
Electrical shock can occur if the Solar Panle Connectors to DC Adapter Cable is damaged or
frayed. DO NOT use a damaged or frayed cable to recharge your PHOENIX 300.
Recharging via USB-C PD Wall Charger
The PHOENIX 300 is designed to be recharged via either a USB-C wall charger or a USB-A wall charger.
However, for optimal recharging performance, it is highly recommended to recharge your PHOENIX 300 using
a USB-C PD wall charger (not included) with a high power rating.
The PHOENIX 300 will begin to recharge automatically and one of the Battery Level LED Indicators will flash.
The flashing LED indicates the unit’s current battery level.
Connect the USB-C PD Port of your PHOENIX 300 to a USB wall charger (not included) using the included
USB-A to USB-C Cable or USB-C to USB-C Cable and plug the USB wall charger into a wall outlet.
Electrical shock can occur if the power supply cable of AC/DC Adapter is damaged or frayed.
DO NOT use a damaged or frayed cable to recharge your PHOENIX 300.
WARNING
D-TAP/CIG
USB
AC LIGHT
IN/OUT
TYPE-C 60W PD
DC IN
D-TAP
USB
WARNING
- 09 -
