Renogy LYCAN 5000 Manual de usuario
COMMUNICATION
AC INPUT
20A
AC OUTPUT
20A
AC/INV
SET
UP
DOWN
ENT
CHARGE
FAULT
SOLAR INPUT 1
SOLAR INPUT 1
+
+
AC OUTPUT
30A
SOLAR 1
SOLAR 2
BATTERY
SURCE
AC OUTPUT 20A
AC OUTPUT 30A
AC OUTPUT 30A
PROTECTION
BLUETOOTH
POWER
LINK
BT-2
Bluetooth Module
VERSION A0
Power Box
LYCAN 5000
RPB4835OA-48LFPA12S
USER MANUAL
02
Applicability
The User Manual applies to the following product:
zLYCAN 5000 Power Box (RPB4835OA-48LFPA12S)
Disclaimer
zRenogy makes no warranty as to the accuracy, sufficiency, or suitability of information in
the User Manual because continuous product improvements are going to be made.
zRenogy assumes no responsibility or liability for losses or damages, whether direct, in-
direct, consequential, or incidental, which might arise out of the use of information in the
User Manual.
zRenogy is not responsible or liable for the failures, damages, or injuries resulting from
repair attempted by unqualified personnel or improper installation and operation.
zThe illustrations in the User Manual are for demonstration purposes only. Details may ap-
pear slightly different depending on product revision and market region.
zRenogy reserves the right to change the information in the User Manual without notice.
Copyright
LYCAN 5000 Power Box User Manual © 2022 Renogy. All rights reserved.
All information in the User Manual is subject to copyright and other intellectual property rights
of Renogy and its licensors. The User Manual may not be modified, reproduced, or copied, in
whole or in part, without the prior written permissions of Renogy and its licensors.
Trademarks
The following are trademarks or registered trademarks of Renogy in the United States and
other countries:
RENOGY
All other trademarks in the User Manual are the property of their respective owners and their
use herein does not imply sponsorship or endorsement of their products or services. The
unauthorized use of any trademark displayed in the User Manual or on the product is strictly
prohibited.
Date and Revision
January 2022, Revision A0
03
Table of Contents
Important Safety Information ..................................................................................................05
Symbols Used ....................................................................................................................05
General Safety Information ................................................................................................05
Introduction .............................................................................................................................07
Introduction ........................................................................................................................07
Key Features ......................................................................................................................07
Package Contents ..................................................................................................................09
Product Overview ...................................................................................................................10
Wiring Diagram .......................................................................................................................12
Installation ..............................................................................................................................13
Preparation .........................................................................................................................13
Installation ..........................................................................................................................14
Environment Requirements ................................................................................................17
Turning On ..............................................................................................................................18
Charging .................................................................................................................................20
AC Charging .......................................................................................................................20
Solar Charging ...................................................................................................................21
Powering Appliances ..............................................................................................................23
Temporary Power Supply ...................................................................................................23
Off-Grid Living ....................................................................................................................25
Emergency Backup ............................................................................................................29
Bluetooth Pairing ....................................................................................................................35
Checking Operation Status.....................................................................................................38
Checking Solar Inverter Charger Operation Status ............................................................38
Checking Battery Operation Status ....................................................................................43
04
Parameter Settings .................................................................................................................45
Operations ..........................................................................................................................45
Setting Menu ......................................................................................................................47
Turning Off ..............................................................................................................................49
Capacity Expansion ................................................................................................................51
Temperature Conditioning ......................................................................................................54
Cooling Fan ........................................................................................................................54
Built-In Heater ....................................................................................................................54
Maintenance ...........................................................................................................................55
Inspection ...........................................................................................................................55
Cleaning .............................................................................................................................55
Storage ...............................................................................................................................55
Emergency Responses ..........................................................................................................57
Fire .....................................................................................................................................57
Flooding .............................................................................................................................57
Usual Smell ........................................................................................................................57
Usual Noise ........................................................................................................................57
Technical Support ...................................................................................................................58
Technical Specifications .........................................................................................................59
Dimensions .............................................................................................................................61
Product Schematic .................................................................................................................62
Serviceable Parts ...................................................................................................................63
05
Important Safety Information
The User Manual provides important installation, operation, and maintenance instructions
for LYCAN 5000 Power Box. Please read the User Manual carefully before installation and
operation and save it for future reference. Failure to observe the instructions or precautions
in the User Manual can result in electrical shock, serious injury, or death, or can damage
LYCAN, potentially rendering it inoperable. The installation and service of LYCAN might
require knowledge of high voltage electricity and is recommended to be carried out by
qualified personnel.
Symbols Used
The following symbols are used throughout the User Manual to highlight important
information:
WARNIN
G
Indicates a potentially dangerous condition which could result in
injury or death.
CAUTIO
N
Indicates a critical procedure for safe and proper installation and
operation.
NOT
E
Indicates an important step or tip for optimal performance.
INFO
Indicates that more information is available in other documents
relating to the subject.
General Safety Information
WARNIN
G
zDO NOT puncture, drop, crush, penetrate, shake, strike, or step on LYCAN.
zDO NOT open, dismantle, repair, tamper with, or modify the components in LYCAN.
zDO NOT touch the connector contacts and electrical outlets on LYCAN.
zDO NOT insert foreign objects into LYCAN.
zPlease remove all connections and turn LYCAN off before maintenance or cleaning.
zPlease install LYCAN in accordance with the regulations at the site of installation.
zDO NOT expose LYCAN to direct flame.
zPlease keep LYCAN away from heating equipment.
zPlease adhere to the requirements of cable size, outlet rating, and device rating in the
User Manual.
zDO NOT touch the exposed electrolyte or powder if the batteries inside LYCAN are dam-
aged.
zDO NOT use LYCAN with life support equipment or other medical equipment.
zDO NOT connect the AC output of LYCAN to the grid.
Important Safety Information
06
Important Safety Information
zPlease keep LYCAN out of the reach of young children.
zPlease use insulated tools when working on or around LYCAN.
zDO NOT wear jewelry or other metal objects when working on or around LYCAN.
zPlease wear proper protective equipment when working on or around LYCAN.
zDO NOT dispose of LYCAN as household waste. Please use recycling channels in ac-
cordance with local, state, and federal regulations.
CAUTIO
N
zPlease use suitable handling equipment for safe transportation of LYCAN.
zDO NOT expose LYCAN to flammable or harsh chemicals or vapors.
zEnsure that no water sources are above or near LYCAN, including downspouts, sprin-
klers, or faucets.
zEnsure that snow does not accumulate around LYCAN.
zDO NOT lean on, stack anything on top of, or hang anything from LYCAN or from cables
leading to LYCAN.
07
Introduction
Introduction
LYCAN 5000 Power Box is an all-in-one energy storage system specially designed to
supply power during emergencies, power outages, or to provide power for off-grid homes.
With a 4.8KWh capacity and a 3500W pure sine wave AC output, the LYCAN can deliver
reliable power to most home appliances. It has a 4400W solar input capability and an
intelligent maximum power point tracking (MPPT) algorithm, allowing maximized solar energy
generation at any time of the day and full charge in as short as 2.5 hours. Fast AC charging,
means that the LYCAN fully charges with AC power from a wall outlet or a generator in as
short as 3 hours. Simultaneously connecting the LYCAN to both solar panels and AC outlets
can further shorten the charging time to 1 hour from 0% to 80%. The pass-through function
allows the LYCAN to bypass AC power to run home appliances while keeping its batteries
topped off. Thanks to the pre-wired design and plug-n-play connectors, the LYCAN can
be easily integrated into existing electric power systems, greatly reducing installation time
and labor cost. The built-in circuit breakers protect the LYCAN from damage caused by
unexpected system faults. Equipped with a Bluetooth module, the LYCAN provides access
to real-time monitoring on the Renogy DC Home app. It can also be easily expanded to up
to 19.2KWh with Renogy 48V 50Ah Smart Lithium Iron Phosphate Batteries, covering any
applications from short term blackout protection to long term off-grid living. The LYCAN
features a rain cap, rubber seals, and rugged enclosure, protecting against harsh outdoor
environments. Built with easily-replaceable components, the LYCAN makes simple repair and
maintenance possible.
Key Features
zMassive Capacity
Delivers long lasting power to home appliances with the 4.8KWh battery capacity.
zReliable Battery
Brings incredible safety and an exceptional life span of more than 4,500 cycles with state-of-
the-art lithium iron phosphate batteries.
zPowerful Output
Runs most heavy-duty appliances with the 3500W pure sine wave AC output.
zRecord-Breaking Charging Speed
Full charge in 2.5 hours with solar panels, in 3 hours with AC outlets, and in 1.3 hours with
both solar and AC.
zPass-Through Charging
Bypasses AC power to home appliances while keeping the battery fully charged and ready for
power outages.
zBorn For Integration
Integrates to existing electric power systems easily with the pre-wired design and plug-n-play
connectors.
Introduction
08
Introduction
zBuilt-In Protection
Provides reliable protections and quick disconnect.
zSeamless Expansion
Expansion capability of up to 19.2KWh capacity.
zBluetooth Embedded
Comes with Bluetooth module for real-time operation status monitoring via the Renogy DC
Home App.
zDesigned For Outdoor
Can withstand harsh outdoor environments with rain cap, rubber seals, and rugged enclosure.
zExcellent Serviceability
Makes repair and maintenance simple with replaceable components.
09
Package Contents
LYCAN 5000 Power Box × 1 Quick Guide × 1
COMMUNICATION
AC INPUT
20A
AC OUTPUT
20A
AC/INV
SET
UP
DOWN
ENT
CHARGE
FAULT
SOLAR INPUT 1
SOLAR INPUT 1
+
+
AC OUTPUT
30A
SOLAR1
SOLAR2
BATTERY
SURCE
ACOUTPUT 20A
ACOUTPUT 30A
ACOUTPUT 30A
PROTECTION
BLUETOOTH
POWER
LINK
BT-2
BluetoothModule
VERSION A1
Power Box
LYCAN 5000
RPB4835OA-48LFPA12S
QUICK GUIDE
COMMUNICATION
ACINPUT
20A
ACOUTPUT
20A
AC/INV
SET
UP
DOWN
ENT
CHARGE
FAULT
SOLARINPUT1
SOLARINPUT1
+
+
ACOUTPUT
30A
SOLAR1
SOLAR2
BATTERY
SURCE
ACOUTPUT20A
ACOUTPUT30A
ACOUTPUT30A
PROTECTION
BLUETOOTH
POWER
LINK
BT-2
BluetoothModule
Keys × 2 RJ45 Plug Waterproof Housing× 1
Handle Bar × 1 Handle Bar Screws × 4
M8x1.25x20mm
IEC C19 to NEMA 5-20P Power Cable × 1
Package Contents
10
Product Overview
COMMUNICATION
AC INPUT
20A
AC OUTPUT
20A
AC/INV
SET
UP
DOWN
ENT
CHARGE
FAULT
SOLAR INPUT 1
SOLAR INPUT 1
+
+
AC OUTPUT
30A
SOLAR 1
SOLAR 2
BATTERY
SURCE
AC OUTPUT 20A
AC OUTPUT 30A
AC OUTPUT 30A
PROTECTION
BLUETOOTH
POWER
LINK
BT-2
Bluetooth Module
1 2 3 4 5 6 7
8 9 10 11 6 12 13 14
No. Part No. Part
1Solar Inverter Charger Display
(Including Indicators and Buttons) 8 Viewing Window
2 Solar Input Circuit Breaker 1 9 Bluetooth Module
3 Solar Input Circuit Breaker 2 10 AC Output Circuit Breaker (20A)
4 Battery Circuit Breaker 11 AC Output Circuit Breaker (30A)
5 Surge Protection Device 12 AC Input Circuit Breaker (20A)
6 Front Door Locks 13 AC Outlet (30A)
7 AC Inlet (20A) 14 AC Outlet (20A)
Product Overview
Otros manuales para LYCAN 5000
1
Este manual sirve para los siguientes modelos
2
Tabla de contenidos
Otros manuales de Generador portátil de Renogy
Renogy
Renogy PHOENIX 500 Manual de usuario
Renogy
Renogy LYCAN 5000 Manual de usuario
Renogy
Renogy PHOENIX 300 Manual de usuario
Renogy
Renogy LYCAN 5000 Power Box Manual de usuario
Renogy
Renogy PHOENIX 1000 Manual de usuario
Renogy
Renogy RSA30SGPK Manual de usuario
Renogy
Renogy PHOENIX 200 Manual de usuario
Renogy
Renogy PHOENIX ELITE R300PHXE Manual de usuario
