Renishaw UCC MMI-2 Manual de usuario
General information
© 2019 ‐ 2020 Renishaw plc. All rights reserved.
This document may not be copied or reproduced in whole or in part, or transferred to any other media or language by any means, without the
prior written permission of Renishaw.
Disclaimer
WHILE CONSIDERABLE EFFORT WAS MADE TO VERIFY THE ACCURACY OF THIS DOCUMENT AT PUBLICATION, ALL WARRANTIES,
CONDITIONS, REPRESENTATIONS AND LIABILITY, HOWSOEVER ARISING, ARE EXCLUDED TO THE EXTENT PERMITTED BY LAW.
RENISHAW RESERVES THE RIGHT TO MAKE CHANGES TO THIS DOCUMENT AND TO THE EQUIPMENT, AND/OR SOFTWARE AND THE
SPECIFICATION DESCRIBED HEREIN WITHOUT OBLIGATION TO PROVIDE NOTICE OF SUCH CHANGES.
Trade marks
RENISHAW®, the probe symbol and REVO®are registered trade marks of Renishaw plc.
Renishaw product names, designations and the mark ‘apply innovation' are trade marks of Renishaw plc or its subsidiaries.
Other brand, product or company names are trade marks of their respective owners.
WEEE
The use of this symbol on Renishaw products and / or accompanying documentation indicates that the product should not be mixed with
general household waste upon disposal. It is the responsibility of the end user to dispose of this product at a designated collection point for
waste electrical and electronic equipment (WEEE) to enable reuse or recycling. Correct disposal of this product will help to save valuable
resources and prevent potential negative effects on the environment. For more information, please contact your local waste disposal service
or Renishaw distributor.
Warranty
Unless you and Renishaw have agreed and signed a separate written agreement, the equipment and/or software are sold subject to the
Renishaw Standard Terms and Conditions supplied with such equipment and/or software, or available on request from your local Renishaw
office.
Renishaw warrants its equipment and software for a limited period (as set out in the Standard Terms and Conditions), provided that they are
installed and used exactly as defined in associated Renishaw documentation. You should consult these Standard Terms and Conditions to find
out the full details of your warranty.
Equipment and/or software purchased by you from a third-party supplier is subject to separate terms and conditions supplied with such
equipment and/or software. You should contact your third-party supplier for details.
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
2
Care of equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with
care.
Changes to Renishaw products
Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to
Renishaw equipment previously sold.
Company registration details
Renishaw plc. Registered in England and Wales. Company no: 1106260. Registered office: New Mills, Wotton-under-Edge, Gloucestershire,
GL12 8JR, UK.
Packaging
To aid end user recycling and disposal the materials used in the different components of the packaging are stated here:
Packaging component Material 94/62/EC code 94/62/EC number
Outer box Cardboard - 70% recycled
content PAP 20
Packing foam Polyurethane PU 7
Packing foam Cross-linked polyethylene LDPE 4
Plastic bags Low density polyethylene bag LDPE 4
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
3
Product compliance
EU declaration of conformity
Contact Renishaw plc or visit www.renishaw.com/EUCMM for the full EU declaration.
EMC conformity
This equipment must be installed and used in accordance with this installation guide. This product is intended for industrial use only and
should not be used in a residential area or connected to a low voltage power supply network which supplies buildings used for residential
purposes.
FCC (USA only)
Information to user (47 CFR 15.105)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to
cause harmful interference, in which case you will be required to correct the interference at your own expense.
Information to user (47 CFR 15.21)
The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or authorised representative could void the
user's authority to operate the equipment.
Equipment label (47 CFR 15.19)
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause undesired operation.
REACH regulation
Information required by Article 33﴾1﴿ of Regulation ﴾EC﴿ No. 1907/2006 ﴾“REACH”﴿ relating to products containing substances of very high
concern (SVHCs) is available at:
www.renishaw.com/REACH
China RoHS
Contact Renishaw plc or visit www.renishaw.com/ChinaRoHSCMM for the full China RoHS tabulation.
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
4
Safety
If the equipment is used in a manner not specified by Renishaw, the protection provided by the equipment may be impaired.
There are no user serviceable parts inside the equipment.
The UCC MMI-2 controller is only warranted and approved for use with the provided PSU.
The UCC MMI-2 is isolated from ac power by disconnection of the IEC mains connector from the supplied PSU. If any additional means of
isolation is required, it must be specified and fitted by the machine manufacturer or installer of the product. The isolator / disconnection
device must be sited within easy reach of the operator and comply with IEC61010 and any applicable national wiring regulations for the
country of installation.
WARNING: Earthing of the UCC MMI-2 is required. It is the responsibility of the OEM or installer to apply the earth bonding
scheme provided by Renishaw in this installation guide.
WARNING: UCC MMI-2 is isolated from ac power by disconnection of the IEC mains connector from the supplied PSU.
Installation requirements
Prior to installation the installer must ensure that the requirements of the machinery directive are achieved by risk assessment and use of the
appropriate harmonised standards (see External Documents for reference).
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
6
Environmental conditions
Indoor use IP30 (BS EN60529:1992)
Altitude Up to 2000 m
Operating temperature +5 °C to +50 °C
Storage temperature ‐25 °C to +70 °C
Relative humidity for storage 90% maximum ﴾non‐condensing﴿ for temperatures up to +40 °C,
linearly derating to 50% at +50 °C
Pollution degree 2
NOTE: If the UCC MMI-2 is to be used in an environment where a higher IP rating is required, then the UCC MMI-2 will need to be
housed in a suitable enclosure.
NOTE: The electrical input requirements to the provided PSU can be found on the PSU label.
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
7
References and associated documents
It is recommended that the following documentation is referenced when installing the UCC MMI-2:
Renishaw documents
Title Document number
Guide: Product interconnection system (PICS) H-1000-5000
UCCassist-2 help Found within UCCassist-2
External documents
National and international standards including the following may be applicable to the finished machine or installation:
BS EN 60204-1:2018 (Safety of machinery - Electrical equipment of machines - Part 1: General requirements)
BS EN 61010-1:2010+A1:2019 (Safety requirements for electrical equipment for measurement, control and laboratory use. General
requirements)
BS EN ISO 13849-1:2015 and BS EN ISO 13849-2:2012 (Safety of machinery. Safety-related parts of control systems)
BS EN ISO 12100:2010 (Safety of machinery - General principles for design - Risk assessment and risk reduction)
It is the responsibility of the OEM or installer to ensure that the finished installation complies with applicable national regulations for the
country of installation.
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
8
Introduction
The UCC MMI-2 controller provides a USB based interface for manual CMMs. The UCC MMI-2 interfaces to the Renishaw digital range of scale
readheads, or electrically compatible OEM versions, and to TP20 or similar touch-trigger probes. The UCC MMI-2 controls the collection of
scales data, and latches the scales positions when a touch-trigger event is detected. The UCC MMI-2 also supports limited 24 V machine IO
signalling, and can interface to a manual head if required.
Key Description Key Description
1Scale 0 interface (15W HDD
socket) 5PICS (9W D socket)
2Scale 1 interface (15W HDD
socket) 6PC connection (USB type B)
3Scale 2 interface (15W HDD
socket) 7Earth terminal
4Machine I/O (44W HDD socket) 8UCC MMI-2 power jack (6.3 mm
socket)
UCC MMI-2 installation guide
www.renishaw.com
Issued 08 2020
9
UCC MMI-2 features
Supports manual CMM data collection
Three CMM axes can be interfaced by the UCC MMI-2
Supports incremental encoders
The UCC MMI-2 can automatically adjust the supply voltage to encoder readheads (to compensate for cable losses)
Probe interface (PICS)
Supports manual heads
Connection for the TP20, TP1, TP2 and TP6 touch-trigger probes
CMM machine input / output, including:
Air solenoid
Air status
13 uncommitted I/O (6 input and 7 output) that can be customised by the user
Status indicating LEDs
Rear panel connectors for the external interface cables to and from the CMM
Rear panel USB connection for the two-way communication link to the CMM host computer
UCC MMI-2 installation guide
