Renesas R0E53036ACFK40 Manual de usuario

R0E53036ACFK40

Converter Board for Connecting R8C/36E, R8C/36F, R8C/36G and R8C/36H Groups

64-pin 0.5mm pitch LQFP

User’s Manual

* NQPACK, YQPACK, YQSOCKET, YQ-GUIDE, HQPACK, TQPACK, TQSOCKET, CSSOCKET, CSPLUG/W and LSPACK are

trademarks of Tokyo Eletech Corporation.

CAUTION If the requirements shown in the "CAUTION" sentences are ignored,

the equipment may cause personal injury or damage to the products.

Renesas Tools Homepage http://www.renesas.com/tools

Rev.1.00

Jun. 16, 2008

REJ10J1873-0100 (1/4)

1. Outline

The R0E53036ACFK40 is a converter board for connecting the

signals of the MCU unit R0E521300MCU00 for R8C/Tiny

Series to a foot pattern for 64-pin 0.5mm pitch LQFP of

R8C/36E, R8C/36F, R8C/36G and R8C/36H groups.

2. Package Components (See Figure 1)

Check to see if the R0E53036ACFK40 package has all the

following contents before using this product.

(1) R0E53036ACFK40 converter board........................... 1 pc.

(2) YQPACK064SD (made by Tokyo Eletech Corporation).......... 1 pc.

(3) NQPACK064SD-ND (made by Tokyo Eletech Corporation) . 1 pc.

(4) YQ-GUIDE (made by Tokyo Eletech Corporation) ...............4 pcs.

(5) R0E53036ACFK40 User's Manual (this manual)

3. Specifications

Table 1 Specifications

Applicable package PLQP0064KB-A:

formerly 64P6Q-A

(64-pin 0.5mm pitch LQFP)

Insertion/removal

iterations of connector 50 times guaranteed

4. Usage (See Figure 2)

The R0E53036ACFK40 can be used for debugging and

on-board evaluation in common by mounting the

NQPACK064SD-ND on the user system.

(1) For debugging

Mount the NQPACK064SD-ND on the foot pattern of the

user system and attach the YQPACK064SD on it. In

addition, connect the R0E53036ACFK40 to the

YQPACK064SD, and then connect the flexible cable

R0E001000FLX10 of the emulator to the upper connector

of the R0E53036ACFK40.

(2) For on-board evaluation

Mount an MCU with on-chip flash memory or one-time

PROM and the HQPACK064SD (not included) in order

on the NQPACK064SD-ND on the user system.

Before using the R0E53036ACFK40, be sure to read "7.

Precautions" on page 4.

R053036ACFK40

YQ-GUIDE (×4)

YQPACK064SD

NQPACK064SD-ND

Figure 1 Package components of the R0E53036ACFK40

Figure 2 Usage of the R0E53036ACFK40

(2/4)

(3/4)

5. Connection Procedure (See Figure 3)

The procedure for connecting the R0E53036ACFK40 is shown

below.

(1) Mount the NQPACK064SD-ND on the user system.

(2) Attach the YQPACK064SD on the NQPACK064SD-ND.

(3) Secure the four corners of the YQPACK064SD with the

YQ-GUIDEs.

●Do not use the screws included with the

YQPACK064SD for fixing the YQPACK064SD.

●Do NOT use the screwdriver included with the

NQPACK064SD-ND for fixing the YQ-GUIDEs. That

is used only for the HQPACK064SD.

(4) Mount the R0E53036ACFK40 on the YQPACK064SD.

(5) Connect the flexible cable R0E001000FLX10 of the

emulator to the R0E53036ACFK40.

Figure 3 Connection procedure of the R0E53036ACFK40

6. External Dimensions and a Sample Foot Pattern

10.00

14.00

10.00

14.00

0.50

0.25

Unit: mm

16.50

CN1

50 51

100

24.00

38.00

TP1

TP2

R0E53036ACFK40

REV.A

MADEINJAPAN

Pb Free

2.50

9.50

2.50

9.50

Figure 4 External dimensions and a sample foot pattern of the R0E53036ACFK40

(4/4)

7. Precautions

CAUTION

Cautions to Be Taken for This Product:

zWhen connecting the YQPACK064SD, be sure to use the included YQ-GUIDEs.

zDo NOT use the screws included with the YQPACK064SD for connecting the YQPACK064SD.

IMPORTANT

Notes on This Product:

zWe cannot accept any request for repair.

zFor purchasing the NQPACK064SD-ND, YQPACK064SD, HQPACK064SD, contact the following:

Tokyo Eletech Corporation http://www.tetc.co.jp/e_index.htm

zFor inquiries about the product or the contents of this manual, contact your local distributor.

Renesas Tools Homepage http://www.renesas.com/tools

8. Correspondence of Connectors CN1

Table 2 Correspondence of the connectors

CN1 Pin No. IC1 CN1 Pin No. IC1

1 - 100 -

2 - 99 -

3 - 98 -

4 - 97 -

5 43 96 42

6 44 95 41

7 45 94 40

8 46 93 39

9 47 92 38

10 48 91 37

11 - 90 36

12 - 89 35

13 - 88 34

14 - 87 33

15 - 86 -

16 - 85 32

17 - 84 31

18 - 83 30

19 - 82 -

20 49 81 29

21 50 80 28

22 51 79 -

23 52 78 -

24 53 77 -

25 54 76 -

26 - 75 -

27 55 74 27

28 56 73 26

29 57 72 25

30 58 71 24

31 59 70 23

32 60 69 22

33 61 68 21

34 - 67 20

35 - 66 19

36 62 65 18

37 - 64 -

38 63 63 17

39 - 62 16

40 64 61 15

41 1 60 14

42 2 59 13

43 3 58 12

44 4 57 11

45 5 56 10

46 6 55 9

47 7 54 8

48 - 53 -

49 - 52 -

50 - 51 -

(-: No connection or signals in the emulator)
