Reliable F1 Res 30 LL Manual

Features

• cULus Listed Residential Sprinklers

• Available in pendent and horizontal sidewall orientations

• Decorative finishes available, including recessed

escutcheons and conical concealed cover plates

Product Description

Model F1Res Series sprinklers are residential sprinklers with a

3 mm glass bulb operating element. A variety of K-Factors as

well as recessed and conical concealed options are available

as detailed in this Bulletin.

The F1Res Series sprinklers are specially engineered for fast

thermal response to meet the requirements of UL 1626. They

are intended for installation in accordance with NFPA 13, 13R,

and 13D.

Application

The Model F1Res Series sprinklers cULus Listed Residential

sprinklers are intended for use in accordance with NFPA

13, NFPA 13R, or NFPA 13D. The Model F1Res residential

sprinklers are cULus Listed for use in residential occupancies

and residential portions of any occupancy, where permitted

by NFPA 13, NFPA 13R, or NFPA 13D. For NFPA 13R and

NFPA 13D applications, the design flow and pressure shall

not be less than the minimum flow and pressure specified

www.reliablesprinkler.com

Residential Sprinkler Summary

Sprinkler

Model

Sprinkler

Identification

Number (SIN)

Orientation

K-Factor

gpm/psi1/2

(lpm/bar1/2)

Thread Size

NPT or ISO7-1 Installation Options Max. Coverage Area

ft x ft (m x m)

F1Res30 R3511 Pendent 3.0 (43) 1/2 Pendent or Recessed 16 x16 (4.9 x 4.9)

F1Res49 R3516 Pendent 4.9 (71) 1/2 Pendent or Recessed 20 x 20 (6.1 x 6.1)

F1Res58 R3513 Pendent 5.8 (84) 1/2 Pendent or Recessed 20 x 20 (6.1 x 6.1)

F1Res76 R7618 Pendent 7.6 (109) 3/4 Pendent or Recessed 20 x 20 (6.1 x 6.1)

F1Res30 CCP R3511 Pendent 3.0 (43) 1/2 Conical Concealed or

Recessed 14 x 14 (4.3 x 4.3)

F1Res49 CCP R3516 Pendent 4.9 (71) 1/2 Conical Concealed or

Recessed 20 x 20 (6.1 x 6.1)

F1Res58 CCP R3513 Pendent 5.8 (84) 1/2 Conical Concealed or

Recessed 20 x 20 (6.1 x 6.1)

F1Res76 CCP R7618 Pendent 7.6 (109) 3/4 Conical Concealed or

Recessed 20 x 20 (6.1 x 6.1)

F1Res44 HSW R3531 Horizontal Sidewall 4.4 (63) 1/2 Recessed 16 x 20 (4.9 x 6.1)

F1Res44 SWC R3531 Horizontal Sidewall 4.4 (63) 1/2 Conical Concealed 16 x 20 (4.9 x 6.1)

F1Res58 HSW R3533 Horizontal Sidewall 5.8 (84) 1/2 Recessed 16 x 20 (4.9 x 6.1)

F1Res 58

HSWX RA3533 Horizontal Sidewall 5.8 (84) 1/2 Recessed 14 x 26 (4.3 x 7.9)

Table A

in the Listed Design Criteria tables in this Bulletin. For NFPA

13 applications, the design density shall be a minimum

of 0.1 gpm/sf (4.1 mm/min), but in no case shall the flow

and pressure be less than the minimum flow and pressure

specified in the Listed Design Criteria tables in this bulletin.

Model F1Res Series sprinklers are listed for use in wet

systems only.

cULus Listed

Model F1Res Series Glass Bulb

Residential Sprinklers

Bulletin 135 February 2020

Model F1Res30 Residential Pendent Sprinkler Components and Installation Dimensions Figure 1

* Model FV escutcheons are not for use in positively pressurized ceiling plenums.

Technical Specifications

Style: Pendent and Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 3.0 (43 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

175°F (79°C)

Recessed Escutcheons

F2 Recessed

FV Recessed*

Sprinkler Wrenches

Model W2

Model W4 (Recessed)

Model F1Res30 Residential Pendent Sprinkler & Models F2 & FV Escutcheon SIN R3511

Bulletin 135

February 2020

Page 2 of 15

www.reliablesprinkler.com

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum

Coverage Area(2)

ft. x ft.(m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

Deflector to

Ceiling Distance

12 x 12 (3.7 x 3.7) 8 (30) 7.0 (0.48)

1 to 4 inches

(25 to 100 mm)

14 x 14 (4.3 x 4.3) 10 (38) 11.0 (0.76)

15 x 15 (4.6 x 4.6) 12 (45) 16.0 (1.1)

16 x 16 (4.9 x 4.9) 13 (49) 18.8 (1.3)

Table B

Model F1Res30 Residential Pendent Sprinkler Hydraulic Design Criteria

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res49 Residential Pendent Sprinkler Components and Installation Dimensions Figure 2

Model F1Res49 Residential Sprinkler & Models F1, F2, & FV Escutcheons SIN R3516

Technical Specifications

Style: Pendent and Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 4.9 (71 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass-bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

175°F (79°C)

Recessed Escutcheons

F1 Recessed

F2 Recessed

FV Recessed*

Sprinkler Wrenches

Model W2

Model W4 (Recessed)

Bulletin 135

February 2020

Page 3 of 15

www.reliablesprinkler.com

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

Deflector to

Ceiling Distance

12 x 12 (3.7 x 3.7) 13 (49) 7.0 (0.48)

1 to 4 inches

(25 to 100 mm)

14 x 14 (4.3 x 4.3) 13 (49) 7.0 (0.48)

16 x 16 (4.9 x 4.9) 13 (49) 7.0 (0.48)

18 x 18 (5.5 x 5.5) 17 (64) 12.0 (0.83)

20 x 20 (6.1 x 6.1) 20 (76) 16.7 (1.15)

12 x 12 (3.7 x 3.7) 15 (57) 9.4 (0.65)

4 to 8 inches

(100 to 200 mm)

14 x 14 (4.3 x 4.3) 16 (61) 10.7 (0.74)

16 x 16 (4.9 x 4.9) 17 (64) 12.0 (0.83)

18 x 18 (5.5 x 5.5) 19 (72) 15.0 (1.03)

20 x 20 (6.1 x 6.1) 22 (83) 20.2 (1.39)

Model F1Res49 Residential Pendent Sprinkler Hydraulic Design Criteria Table C

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

* Model FV escutcheons are not for use in positively pressurized ceiling plenums.

Model F1Res58 Residential Pendent Sprinkler & F1, F2, & FV Recessed Escutcheons SIN R3513

Technical Specifications

Style: Pendent and Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 5.8 (84 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

175°F (79°C)

Recessed Escutcheons

F1 Recessed

F2 Recessed

FV Recessed*

Sprinkler Wrenches

Model W2

Model W4 (Recessed)

* Model FV escutcheons are not for use in positively pressurized ceiling plenums.

Model F1Res58 Residential Pendent Sprinkler Components and Installation Dimensions Figure 3

Bulletin 135

February 2020

Page 4 of 15

www.reliablesprinkler.com

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

Deflector to

Ceiling Distance

16 x 16 (4.9 x 4.9) 16 (61) 7.6 (0.52)

1 to 4 inches

(25 to 100 mm)

18 x 18 (5.5 x 5.5) 19 (72) 10.8 (0.75)

20 x 20 (6.1 x 6.1) 22 (83) 14.4 (1.0)

Model F1Res58 Residential Pendent Sprinkler Hydraulic Design Criteria Table D

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res76 Residential Pendent Sprinkler & F1, F2, & FV Escutcheons SIN R7618

Technical Specifications

Style: Pendent and Recessed Pendent

Threads: 3/4” NPT or ISO7-1R3/4

Nominal K-Factor: 7.6 (109 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

175°F (79°C)

Recessed Escutcheons

F1 Recessed

F2 Recessed

FV Recessed*

Sprinkler Wrenches

Model W2

Model W4 (Recessed)

Model F1Res76 Residential Pendent Sprinkler Components and Installation Dimensions Figure 4

* Model FV escutcheons are not for use in positively pressurized ceiling plenums.

Bulletin 135

February 2020

Page 5 of 15

www.reliablesprinkler.com

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

Deflector to

Ceiling Distance

18 x 18 (5.5 x 5.5) 21 (80) 7.6 (0.52)

1 to 4 inches

(25 to 100 mm)

20 x 20 (6.1 x 6.1) 23 (87) 9.2 (0.63)

Model F1Res76 Residential Pendent Sprinkler Hydraulic Design Criteria Table E

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res30 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent

Sprinkler SIN R3511

Technical Specifications

Style: Conical Concealed Pendent and

Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 3.0 (43 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

Recessed Escutcheons/Cover Plates

CCP Conical Concealed Plate 135°F (57°C)*

FP Recessed*

Sprinkler Wrenches

Model W4

Model F1Res30 CCP and FP Recessed Pendent Sprinkler Installation Dimensions Figure 5

*Note: Model FP escutcheons and CCP cover plates are not listed for use in positively pressurized ceiling plenums.

Bulletin 135

February 2020

Page 6 of 15

www.reliablesprinkler.com

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar) Deflector to Ceiling Distance

12 x 12 (3.7 x 3.7) 8 (30) 7.0 (0.48) 1/2 to 1 inch

(13 to 25 mm)

14 x 14 (4.3 x 4.3) 11 (38) 13.4 (0.92)

Model F1Res30 CCP Pendent & FP Recessed Pendent Sprinkler Hydraulic Design Criteria Table F

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

3. The sprinkler must be installed into a ceiling with the listed cover plate installed.

Model F1Res49 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent Sprinkler SIN R3516

Technical Specifications

Style: Conical Concealed Pendent and

Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 4.9 (71 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

Recessed Escutcheons/Cover Plates

CCP Conical Concealed Plate 135°F (57°C)*

FP Recessed*

Sprinkler Wrenches

Model W4

Model F1Res49 CCP & FP Recessed Pendent Sprinkler Installation Dimensions Figure 6

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar) Deflector to Ceiling Distance

14 x 14 (4.3 x 4.3) 13 (49) 7.0 (0.48)

1/2 to 1 inch

(13 to 25 mm)

16 x 16 (4.9 x 4.9) 14 (53) 8.2 (0.57)

18 x 18 (5.5 x 5.5) 18 (68) 13.5 (0.93)

20 x 20 (6.1 x 6.1) 20 (76) 16.7 (1.15)

Model F1Res49 CCP Pendent and FP Recessed Pendent Hydraulic Design Criteria Table G

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

3. The sprinkler must be installed into a ceiling with the listed cover plate installed.

*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.

Bulletin 135

February 2020

Page 7 of 15

www.reliablesprinkler.com

Model F1Res58 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent Sprinkler SIN R3513

Technical Specifications

Style: Conical Concealed Pendent and

Recessed Pendent

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 5.8 (84 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

Recessed Escutcheons/Cover Plates

CCP Conical Concealed Plate 135°F (57°C)*

FP Recessed*

Sprinkler Wrenches

Model W4

Figure 7

Model F1Res58 CCP and FP Recessed Pendent Sprinkler Installation Dimensions

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow gpm

(l/min)

Pressure psi

(bar) Deflector to Ceiling

Distance

16 x 16 (4.9 x 4.9) 16 (61) 7.6 (0.52)

1/2 to 1 inch

(13 to 25 mm)

18 x 18 (5.5 x 5.5) 19 (72) 10.8 (0.75)

20 x 20 (6.1 x 6.1) 22 (83) 14.4 (1.0)

Model F1Res58 CCP Pendent & FP Recessed Pendent Hydraulic Design Criteria Table H

*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

3. The sprinkler must be installed into a ceiling with the listed cover plate installed.

Bulletin 135

February 2020

Page 8 of 15

www.reliablesprinkler.com

Figure 8

Model F1Res76 CCP and FP Recessed Pendent Sprinkler Installation Dimensions

Model F1Res76 CCP Conical Concealed Pendent and Model FP Recessed Escutcheon Pendent Sprinkler SIN R7618

Technical Specifications

Style: Conical Concealed Pendent and

Recessed Pendent

Threads: 3/4” NPT or ISO7-1R3/4

Nominal K-Factor: 7.6 (109 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

Recessed Escutcheons/Cover Plates

CCP Conical Concealed Plate 135°F (57°C)*

FP Recessed*

Sprinkler Wrenches

Model W4

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar) Deflector to Ceiling Distance

16 x 16 (4.9 x 4.9) 21 (80) 7.6 (0.52)

1/2 to 1 inch

(13 to 25 mm)

18 x 18 (5.5 x 5.5) 22 (83) 8.4 (0.58)

20 x 20 (6.1 x 6.1) 25 (95) 10.8 (0.75)

Model F1Res76 CCP Pendent & FP Recessed Pendent Hydraulic Design Criteria Table I

*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

3. The sprinkler must be installed into a ceiling with the listed cover plate installed.

Bulletin 135

February 2020

Page 9 of 15

www.reliablesprinkler.com

Model F1Res44 Horizontal Sidewall Sprinkler & Models FV & F2 Recessed Escutcheon SIN R3531

Technical Specifications

Style: Sidewall and Recessed Sidewall

Threads: 1/2” NPT or ISO7-1R1/2

Nominal K-Factor: 4.4 (63 metric)

Max. Working Pressure: 175 psi (12 bar)

Material Specifications

Thermal Sensor: 3 mm glass bulb

Sprinkler Frame: Brass Alloy

Button: Copper Alloy

Sealing Assembly: Nickel Alloy with PTFE

Load Screw: Bronze Alloy

Deflector: Bronze Alloy

Finishes

(See Table N)

Sensitivity

Fast-response

Temperature Ratings

155°F (68°C)

175°F (79°C)

Recessed Escutcheons

F2 Recessed

FV Recessed

Sprinkler Wrenches

Model W2

Model W4 (Recessed)

Minimum Flow and Residual Pressure in Wet Pipe Systems(1)

Maximum Coverage Area(2)

ft. x ft. (m x m)

Flow

gpm (l/min)

Pressure

psi (bar)

Deflector to

Ceiling Distance

12 x 12 (3.7 x 3.7) 12 (45) 7.5 (0.52)

4 to 6 inches

(100 to 150 mm)

14 x 14 (4.3 x 4.3) 14 (53) 10.2 (0.70)

15 x 15 (4.6 x 4.6) 15 (57) 11.6 (0.80)

16 x 16 (4.9 x 4.9) 16 (61) 13.3 (0.92)

16 x 18 (4.9 x 5.5) 18 (68) 16.8 (1.16)

16 x 20 (4.9 x 6.1) 23 (87) 27.4 (1.89)

18 x 18 (5.5 x 5.5) 19 (72) 18.7 (1.29)

12 x 12 (3.7 x 3.7) 14 (53) 10.2 (0.7)

6 to 12 inches

(150 to 300 mm)

14 x 14 (4.3 x 4.3) 16 (61) 13.2 (0.91)

15 x 15 (4.6 x 4.6) 16 (61) 13.2 (0.91)

16 x 16 (4.9 x 4.9) 17 (64) 15.0 (1.03)

16 x 18 (4.9 x 5.5) 20 (76) 20.7 (1.43)

16 x 20 (4.9 x 6.1) 23 (87) 27.4 (1.89)

Model F1Res44 Horizontal Sidewall Sprinkler Hydraulic Design Criteria Table J

Notes:

1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to

achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.

2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res44 Horizontal Sidewall Sprinkler Installation Dimensions Figure 9

Bulletin 135

February 2020

Page 10 of 15

www.reliablesprinkler.com

Otros manuales para F1 Res 30 LL

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de riego de Reliable

Reliable

Reliable G5-56 Manual

Reliable

Reliable N252 EC Manual de usuario

Reliable

Reliable F1-SS Series Manual de usuario

Reliable

Reliable F156 Series Manual

Reliable

Reliable G6-80 Manual de usuario

Reliable

Reliable DH56 HSW-PL Manual de usuario

Reliable

Reliable HL22 Manual de usuario

Reliable

Reliable N252 EC Manual de usuario

Reliable

Reliable N25 Manual de usuario

Reliable

Reliable N25 ESFR Manual de usuario

Reliable

Reliable F1FR80VdS Series Manual

Reliable

Reliable F3QR80 Dry Pendent Manual del operador

Reliable

Reliable RFC43 LL Guía del usuario

Reliable

Reliable The Non-Ferrous Concealer F4FR-NF Manual de usuario

Reliable

Reliable F1-SS Series Manual de usuario

Reliable

Reliable F1FR-SS Series Manual de usuario

Reliable

Reliable F1FR80 Series Manual de usuario

Reliable

Reliable G6-80 Manual

Reliable

Reliable F1FR-FS LO Manual de usuario

Reliable

Reliable F3QR56 Manual de usuario

Reliable

Reliable F1FR 300 QREC Manual

Reliable

Reliable F3QR80 Series Manual de usuario

Reliable

Reliable G6-56 Manual de usuario

Reliable

Reliable KFR56 Series Manual de usuario

Manuales populares de Sistema de riego de otras marcas

Hunter

Hunter Institutional Series Manual de usuario

Cellfast

Cellfast 52-305 Manual de usuario

Tyco Fire Product

Tyco Fire Product Star Galaxy SGQR Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL A Manual de usuario

Oral Care Technologies

Oral Care Technologies Hydro Floss Manual de usuario

Tyco Fire Product

Tyco Fire Product Gem F892 Manual de usuario

Netafim

Netafim NETBEAT Manual de usuario

Irrigation-Mart

Irrigation-Mart KIT-GK100-RV-B Manual de usuario

Tyco

Tyco CC3 Manual de usuario

OpenSprinkler

OpenSprinkler OSPi Manual de usuario

EINHELL

EINHELL GE-WW 5537 E Manual de usuario

Valley

Valley Bender160 Manual de usuario

Toro

Toro 730 Series Guía rápida

Eden

Eden 97063-EDAMZ Manual de usuario

Tyco

Tyco TY-L Series Manual de usuario

Tyco Fire Product

Tyco Fire Product CENTRAL ELO-231 Manual de usuario

Johnson Controls

Johnson Controls tyco ESFR-17 Manual de usuario

Victaulic

Victaulic VicFlex I-VICFLEX.AQC-U Manual de usuario
