Reiner P1-MP2-RD Manual de usuario

P1-MP2-RD

Operating Manual

Weld seam

Zip fastening

Clip

Print head

Clip arms

Print head nozzles

Print head contacts

For your safety

DANGER Warnings about risks where non-observance

of the measures may directly cause death or

serious injury.

WARNING Warnings about risks where non-observance

of the measures may cause death or serious

injury.

CAUTION Warnings about risks where non-observance of

the measures may cause injury.

PLEASE NOTE Warnings about risks where non-observance of

the measures may cause material damage.

Instructions and tips

Safety instructions for MP ink

WARNING

Special ink is highly flammable. Risk of burns!

„Store at 10 °C - 20 °C.

„Do not expose to direct sunlight.

WARNING

If in eyes.

„Rinse cautiously with water for several minutes.

„Remove contact lenses, if present and easy to do.

„Continue rinsing. Immediately call a POISON CENTER

or doctor/physician.

1. Making the print head ready for use

1.1. Opening the pack _Fig. A

The aluminium pouch has a resealable zip fastening

„With scissors, cut open the top of the pack between

the weld seam

and the zip fastening

„Unzip

the pack.

„Take out the print head

1.2. Releasing the clip _Fig. B+ C

The print head

is supplied with a reusable clip

„Place the print head

on a firm surface at an angle

of about 45° as shown in figure C.

„Hold the red clip

by the point with one hand.

„With the other hand, press the print head

down firmly. The

clip arms

will spring out and the print head

will slide

away from the clip

2. Printing material

For the best results, use material that is clean, non-greasy, dry

and at the same temperature as the print head.

Before carrying out a large print job, perform a test print.

3. Storage _Fig. A+ D

MP ink is fast-drying. The time it takes the print head

nozzles

to dry up depends on the ambient temperature

and the humidity.

- If the printing break will probably take more than 5 minutes,

the print head

should be protected with the clip

- If the printing break will probably take more than 2 hours,

the print head

with the clip

should be stored in the

air-tight aluminium pouch.

„Remove the print head

out of the device.

„Place the print head

with the clip

on a smooth and solid

surface as shown in figure D.

„Press the print head

down until it snaps in the clip

„Place the print head

into the aluminium pouch and close

the zip fastening completely.

Use the print head within four weeks after opening.

4. Environmental Conditions

Temperature for storage 10°C to +20°C

Temperature for transport -20 °C to +40 °C (up to 24 hours)

5. Troubleshooting

Dried ink on the print head nozzles

may result in streaks

or reduced print quality.

5.1. Automatic cleaning

„Read the information about the cleaning of the print head

nozzles

in the manual for the electronic stamp.

5.2. Cleaning the print head nozzles manually

If the automatic cleaning of the nozzles

does not produce the

desired result, we recommend proceeding as follows:

„To remove dried ink, press a soft cloth, if necessary lightly

soaked in ethanol (spirits), against the print head nozzles

for about 3 seconds.

„Dab off the dissolved ink and wipe the nozzles dry.

5.3. Reactivating the print head

If ink has dried inside the print head

it may be necessary

to reactivate it.

„Lay the print head down on a firm surface protected by

a lint-free cloth or piece of material.

„Place the syringe supplied firmly against the opening on top

of the print head

and carefully inject a small amount of air

(approx. 0.5 ml).

PLEASE NOTE

Risk of staining from discharged ink.

„Wipe up discharged ink with a lint-free cloth or piece of

material.

5.4. Cleaning the print head contacts

In rare cases, dirt on the print head contacts

may result in

inferior printing results.

„Clean the contacts on the print head

and in the device with

a soft cloth or cotton bud, if necessary lightly soaked

in ethanol (spirits).

Disposal

Directive 2002/96/EC (WEEE)

Electrical and electronic equipment and batteries

should not be disposed of along with domestic

or general waste. Dispose of equipment in an

environmentally friendly way.

Notes

Ernst Reiner GmbH & Co. KG

Baumannstr. 16

78120 Furtwangen

Phone +49(0)7723 657-0

Fax +49(0)7723 657-200

reiner@reiner.de

www.reiner.de

Award for

Operational

Excellence

|ZN-791061-001 F|02-2014

Danger

REINER MP2 RD

4 ml

Flammable liquid and vapour.

Causes serious eye damage.

H318H226

Acid Red 52Ethanol
