Rega Cursa 3 Manual de usuario
Contents
Introduction.............................................................................1
Design Innovation...................................................................2
Installation...............................................................................3
DC Protection..........................................................................4
Pre-Amp Outputs....................................................................5
Input Connection..................................................................6-8
In Use................................................................................9-10
Input Selection.......................................................................11
Output Level and Gain change..............................................12
Power Amp Connections......................................................13
Specifications.......................................................................14
Troubleshooting...........................................................15-19
Owners Log......................................................................20
Cursa 3 manual.qxd 10/12/2002 15:23 Page 1
Introduction
Your Rega pre-amplifier has been designed to reproduce music
effectively and easily. The Cursa 3has been built to Rega’s
discriminating standards of reliability and quality to ensure many
years of musical enjoyment.
A pre-amplifier's function is to act as a control and switching unit for
a variety of sources, and to boost the tiny signal generated by a
cartridge, CD player, or other source to a level suitable for input into
a power amplifier; which in turn boosts it to a higher level to drive the
loudspeakers. It is vital that the amplifier achieves this without
changing the signal, as this would distort the music. We have avoided
superfluous gadgets such as tone controls or a headphone socket as
they obstruct the signal path and degrade the produced sound
quality.
The Rega amplifiers incorporate remarkable and innovative design
ideas. For those interested in the technical details, these innovations
are described more fully in this manual. Alternatively, you can simply
switch on, sit back, and let your amplifier speak for itself...
Mission Statement
Rega’s philosophy is to make high quality products at sensible prices, as a means
of reproducing music as faithfully as possible. Rega is committed to the design
and development of new and existing products, both in hi-fi and other areas, that
will perpetuate Rega’s values of quality and value for money.
1
Cursa 3 manual.qxd 10/12/2002 15:23 Page 2
2
Design Innovation
In common with all Rega products, the Cursa 3 pre-amplifier has
been designed without compromise. Our time and money has been
spent on developing the unique circuit design and sourcing unusually
high quality components. However, we have included useful features
to further enhance your listening pleasure.
The Cursa 3 amplifier has digitally controlled analog switched
resistor network volume control.
The Cursa 3 is a programmable gain pre-amplifier
The Cursa 3 amplifier features REGA designed circuitry, developed
in-house with the aid of CAD circuit simulation, computer modeling
and extensive listening.
The Cursa 3 amplifier includes extremely high quality components
not normally found in a pre-amplifier of this price. These include high
tolerance polypropylene capacitors, and a toroidal transformer.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 3
3
Installation
The amplifier will work well on most surfaces, such as a shelf or a
table, provided there is sufficient air around it to prevent overheating.
To avoid magnetic interference, site the amplifier as far away from the
turntable as the tonearm lead will allow. If possible, place it to the left
of the turntable.
Keep other equipment, such as tuners, cassette decks or CD players
away from the amplifier. Never stack other hi-fi components on top of
the amplifier.
Due to the layout of Rega’s amplifier circuit designs, they are virtually
insusceptible to electro magnetic interference, and by virtue of the
extruded aluminium case, emit practically no electro magnetic
radiation. However, placing any electronic equipment close together
may impair the performance of one or both items.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 4
4
DC Protection
The amplifier has a circuit which protects the power amplifier
connected to the pre-amplifier output, from direct current in the event
of a major failure of the system.
The use of this sophisticated DC protection circuit in conjunction with
a servo correction stage, (on all line inputs) allows the amount of
capacitors in the signal path to be kept at a minimum. This prevents
unnecessary sound degradation at this crucial line level stage,
providing true musical accuracy and the flexibility to drive up to 5
power amplifiers.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 5
5
Pre-Amp Outputs
The pre-amplifier can drive at least 5 power amplifiers, sub bass units
etc.
The 2 parallel pre-amp outputs use RCA type (phono) connectors.
The output is at standard line level of 0.83V, but your Rega dealer will
be able to modify the output level to accomodate a range of power
amplifiers. See specifications on page 13 for further details.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 6
6
Input Connections
All inputs and outputs are made via RCA (phono) type connectors.
The sockets on the Rega amplifiers are clearly marked red and white.
Right: always the lower row and marked in RED.
Left: always the upper row and marked in WHITE.
Rear Panel Connections
Rega Research Ltd., England
POWER IN
Phono CD Tuner Line1 Line2 Tape
In 1 Tape
Out 1 Tape
In 2 Tape
Out 2
Pre
Amp
Out 1
Ground Screw
Pre
Amp
Out 2
Cursa 3 manual.qxd 10/12/2002 15:23 Page 7
7
Phono Input
The Phono Input uses a plug-in card aIlowing you to use either
moving magnet (MM), moving coil (MC), or if you do not use a
turntable there is a line level card option allowing you to have an
additional line level input. These cards must be pre-specified on
purchase, or can be changed by your Rega dealer. For input
sensitivities of the different cards see the specifications on page 15.
Earthing of Tonearm
Earthing is done via the Phono socket ground for Rega turntables so
a separate earth is not necessary. In the unlikely event that your
tonearm needs to be earthed to the amplifier, the grounding tag may
be connected to the case grounding screw above the input sockets.
See Rear Panel Connections drawing (page 6).
Compact Disc Input
The Compact Disc input is suitable for use with any CD source.
Tuner Input
The tuner input is suitable for use with most types of AM/FM tuners.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 8
8
Line Inputs
The line inputs enable the connection of additional sources, such as
a second tape machine, tuner, or video recorder for use with an Audio
Visual system.
Tape Input/Output
Almost any tape machine can be used with your amplifier, including
compact cassette, video cassette, reel to reel, DAT, and DCC.
NOTE: All inputs, (other than the moving magnet or moving coil
PHONO input options), are at standard "line level" and can
therefore be used for any line level input.
Cursa 3 manual.qxd 10/12/2002 15:23 Page 9
9
In Use
Switching On
The amplifier is turned on by depressing the power switch to the left
of the control panel. The LED in the power switch will glow red.
After several seconds you may hear a gentle click. This indicates that
the switch-on relay has been released and the amplifier is ready for
use.
Volume control
The volume of the amplifier can be adjusted using the volume knob
on the amplifier and via the remote handset as described below.
Line2
Line1
Tuner
CD
Phono
Tape
Mute
Mira
Volume Control/Input selector
Power switch &
power LED Volume Indicator LED’s
Remote sensor Heatsink
Tape switches Mute switch/
Dimmer function
Cursa
Tape 2
1
