Reed Instruments C-370 Manual de usuario

RTD

Thermometer

Instruction

Manual

C-370

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Table of Contents

Introduction .................................................................................................... 3

Product Quality............................................................................................... 3

Safety ............................................................................................................. 3

Features.......................................................................................................... 3

Specications..............................................................................................4-5

Range Speciﬁcations ................................................................................. 4

Temperature Coefﬁcient ............................................................................ 5

RTD Probe Accuracy Speciﬁcations.......................................................... 5

Instrument Description................................................................................... 6

Display Description ........................................................................................ 7

Operating Instructions...............................................................................8-13

Connecting the Pt100 RTD Probe (TP-R01).............................................. 8

Connector Conﬁguration ........................................................................... 8

Powering the Meter ................................................................................... 8

Selecting Temperature Units...................................................................... 9

Taking Measurements ................................................................................ 9

Data Hold................................................................................................... 9

Backlight .................................................................................................... 9

Relative Function ..................................................................................... 10

MAX/MIN/AVG Function.......................................................................... 10

Auto Power Off ...................................................................................10-11

Pt Type Selection..................................................................................... 11

0°C Calibration......................................................................................... 12

Reset Calibration Value to Factory Settings .......................................12-13

Battery Replacement.................................................................................... 13

Applications.................................................................................................. 14

Accessories and Replacement Parts ........................................................... 14

Product Care ................................................................................................ 14

Product Warranty ......................................................................................... 14

Product Disposal and Recycling .................................................................. 15

Product Support........................................................................................... 15

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Introduction

Thank you for purchasing your REED C-370 RTD Thermometer. Please

read the following instructions carefully before using your instrument. By

following the steps outlined in this manual your meter will provide years of

reliable service.

Product Quality

This product has been manufactured in an ISO9001 facility and has been

calibrated during the manufacturing process to meet the stated product

specications. If a certicate of calibration is required please contact the

nearest authorized REED distributor or authorized Service Center. Please

note an additional fee for this service will apply.

Safety

Never attempt to repair or modify your instrument. Dismantling your

product, other than for the purpose of replacing batteries, may cause

damage that will not be covered under the manufacturer's warranty.

Servicing should only be provided by an authorized service center.

Features

• Designedtomeetfoodservicestandards

• Quickresponding,highaccuracy

• Large,easy-to-readbacklitLCDdisplay

• Userselectable°C,°F

• Min/Max/Avgfunctions

• RelativemodeandDatahold

• IP67ratedwaterproofhousing

• Lowbatteryindicatorandautoshutoff

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Specifications

MeasuringRange: -148to572°F(-100to300°C)

Resolution: 0.1°F/°C

Type: SingleInput,RTD

ResponseTime: 2x/second

Display: 31/2-digitLCD

BacklitDisplay: Yes

DataHold: Yes

Min: Yes

Max: Yes

Average: Yes

RelativeMode: Yes

AutoShut-off: Yes(after30minutes/off)

LowBatteryIndicator: Yes

PowerSupply: 3xAAABatteries

BatteryLife: Approx100hours(Alkaline)

ProductCertications: IP67,CE

OperatingTemperature: 32to104°F(0to40°C)

StorageTemperature: 14to140°F(-10to60°C)

OperatingHumidityRange: 10to90%

Dimensions: 5.9x2.6x1.2"(150x66x31mm)

Weight: 6.2oz(175g)

Range Specifications

Range Accuracy

-100~300°C ±(0.1%reading+0.4°C)

-148~572°F ±(0.1%reading+0.8°C)

Note: The basic accuracy specications does not include the error of

the RTD probe, refer to the RTD probe accuracy specications below for

additional details.

continued...

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Temperature Coefficient

Forambienttemperaturesfrom0to18°Cand28to50°C,foreach

temperaturereadingbelow18°Corabove28°Caddthefollowing

toleranceintotheaccuracyspecication:

0.01%ofreading+0.03°C(0.01%ofreading+0.06°F)

RTD Probe Accuracy Specifications (TP-R01)

Sensor Type Platinum resistance thermometer sensor Pt 100

(4wires)

Accuracy IEC, class A

±0.15°C±0.002measurementtemperature

MeasurementRange -100to400°C

Temp. Sensor Dim. ApproximatelyØ3.2mm(Ø0.125")

Temp.SensorLength Approximately120mm(4.72")

CableLength Approximately1100mm(43.3")

Water-Resistant EN60529:1991,IP67

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Instrument Description

C-370

1. PT00 Input Jack

2. LCDDisplay

3. Power Button

4. HOLDButton

5. MAX/MIN/AVGButton

6. Backlight Button

7. Relative Function Button

8. °C/°FButton

9. Battery Cover

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Display Description

1. Battery Power Indicator

2. TemperatureReading

3. Platinum Type Indicator

4. MinimumValueIndicator

5. MIN/MAX/AVGTemperature

Reading

6. MaximumValueIndicator

7. AverageValueIndicator

8. TemperatureUnitofMeasure

Indicator

9. RelativeModeIndicator

10. Data Hold Indicator

11. Auto Power Off Indicator

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Operating Instructions

Connecting the Pt100 RTD Probe (TP-R01)

Connect the Pt100 probe to the input jacks located at the top of the meter

as indicated below.

C-370

Connector Configuration

Source - Source +

Sense + Sense -

Powering the Meter

To turn the meter on or off, press the POWER button.

continued...

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Selecting Temperature Unit of Measure

1. When the meter is rst powered on the default scale setting is set to

Celsius(°C).

2. Pressthe°C/°F button to toggle between Celsius and Fahrenheit.

Note: The meter will automatically save the selected unit when turned off

as the new default.

Taking Measurements

Once the meter has been setup

and the Pt100 probe has been

connected, place the temperature

probe in the area being tested.

Givethemeterseveralseconds

to stabilize. Read the temperature

measurementontheLCD.If"----"

appears on the display, either the

reading is out of range or the Pt100

probe is not connected or it may

be defective.

Note: The temperature sensor is

located at the tip of the Pt100

probe. To accurately test internal

temperatures, make sure the probe is inserted at a distance of at least 15

times the diameter of the metal sheath as indicated in the diagram.

Data Hold

1. Press the HOLD button to freeze the current reading on the display.

2. Pressthebuttonagaintoresumenormaloperation.

Note: When Data Hold is active the MAX/MIN/AVG, °C/°F and REL

buttons are disabled.

Backlight

PresstheBACKLIGHTbuttontoturntheLCDBacklightonandoff.

Note: The backlight will automatically turn off after 10 seconds.

continued...

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Relative Function

1. Press the REL button to store the current measurement.

2. Underthismode,themeterwilldisplaythedifferencebetweenany

new measurement and the stored measurement.

3. Press the RELbuttonagaintoexitRelativefunction.

MAX/MIN/AVG Function

When the buttonispressed,themeterwillentertheMAX/MIN/

AVGfunction.Underthisfunction,themaximumvalue,minimumvalue

and average values taken during the measurement process will appear on

the lower part of the display when selected.

Note: The average value is calculated using the last 8 readings in memory

and will update with every new reading.

1. The rst value to appear on the display in this function is the

Maximumvalueasindicatedbythe"MAX"symbolandisupdated

whenanewmaximumdatavaluehasbeentaken.

2. Pressthe buttonagainandtheMinimumvaluewillnow

appearonthedisplayasindicatedbythe"MIN"symbolandis

updated when a new minimum data value has been taken.

3. Press the button a third time and the Average value will now

appearonthedisplayasindicatedbythe"AVG"symbol.

4. Press the buttonafourthtimeandthe"MIN","MAX","AVG"

symbols will blink simultaneously while continuing to update the

readings in memory and can be viewed by returning to the appropriate

function. While in this function, the meter is displaying the current

measurement value only.

5. ToexittheMAX/MIN/AVGfunction,pressandholdthe button

for two seconds.

Note:WhenthemeterisinMAX/MIN/AVGfunction,the REL and °C/°F

buttons are disabled.

Auto Power Off

1. To preserve battery life, the meter is programmed to turn off after

30 minutes of inactivity.

continued...

www.GlobalTestSupply.com

Find Quality Products Online at: sales@GlobalTestSupply.com

Tabla de contenidos

Otros manuales de Termómetro de Reed Instruments

Reed Instruments

Reed Instruments R2450SD Manual de usuario

Reed Instruments

Reed Instruments R2400 Manual de usuario

Reed Instruments

Reed Instruments SMART Series Manual de usuario

Reed Instruments

Reed Instruments R2330-NIST Manual de usuario

Reed Instruments

Reed Instruments R2330 Manual de usuario

Reed Instruments

Reed Instruments R2000 Manual de usuario

Reed Instruments

Reed Instruments R2320 Manual de usuario

Reed Instruments

Reed Instruments R2340 Manual de usuario

Reed Instruments

Reed Instruments Smart Series Manual de usuario

Reed Instruments

Reed Instruments FS-200 Manual de usuario

Reed Instruments

Reed Instruments R2020 Manual de usuario

Manuales populares de Termómetro de otras marcas

Delton

Delton 981A Manual de usuario

Baker

Baker MM2P Manual de usuario

Tarmo

Tarmo 320281 Manual de usuario

Citizen

Citizen CTD 504 Manual de usuario

TFA

TFA 14.1500 Manual de usuario

Vive

Vive DMD1010 Manual de usuario

Gotemp

Gotemp THB4002 Manual de usuario

GREISINGER

GREISINGER G 1202 Manual de usuario

Amprobe

Amprobe TMD-53W Manual de usuario

Trotec

Trotec BP10 Manual de usuario

Radiance instruments

Radiance instruments RT616 Series Manual de usuario

Eurolec

Eurolec IR151 Manual de usuario

Scaneo

Scaneo TS42B Manual de usuario

Sper scientific

Sper scientific 800043 Manual de usuario

Microlife

Microlife NC 200 Manual de instrucciones

Motorola

Motorola MBP69SN Guía de configuración

The MeatStick

The MeatStick The MeatStick Manual de usuario

Hama

Hama TH35-A Manual de usuario
