Rear view safety RVS-97QUAD Manual de usuario
Reverse With Condence ™ 1
9” TFT LCD Digital
Quad View Color Monitor
RVS-97QUAD
Instruction Manual
Please read this manual before using this monitor.
The product may be dierent from how it is described in the manual
depending on what software version you are using.
Rear View Safety
2
Introduction.............................. 03
SafetyInformation.............................. 04-06
BeforeBeginningInstallation ....................... 07
Precautions.......................... . . . . 08-09
Maintenance...............................10
Accessories.................................11
MonitorInstallation...............................12
Connections..................................13
Controls........................... . . . . . 14-15
Menu and Touch Screen Operations. . . . . . . . . . . . . . . . . . . . 16-24
Specication.......................... . . . . . . 25
Troubleshooting.......................... . . . . 26
Warranty............................. . . . . 27
Disclaimer............................. . . . . 28
TABLE OF CONTENTS
Reverse With Condence ™ 3
NOTE! Please read all of the installation instructions
carefully before installing the product. Improper
installation will void manufacturer’s warranty.
Congratulations on purchasing a RearView Backup
Camera System!
With this manual you will be able to properly install and
operate the unit.
The Backup Camera System is intended to be installed as a
supplement aid to your standard rear view mirror that already exists
in your vehicle. The Backup Camera System should not be used as a
substitute for the standard rear view mirror or for any other mirror
that exists in your vehicle.
In some jurisdictions, it is unlawful for a person to drive a
motor vehicle equipped with aTV viewer or screen located forward of
the back of the driver’s seat or in any location that is visible, directly
or indirectly, to the driver while operating the vehicle.
INTRODUCTION
Rear View Safety
4
Please read the entire manual and follow the instructions and
warnings carefully. Failure to do so can cause serious damage and/or
injury, including loss of life. Be sure to obey all applicable local
trac and motor vehicle regulations as it pertains to this product.
Improper installation will void manufacturer’s warranty.
• The Rear View Camera System is
designed to help the driver safe-
ly detect people and/or objects
helping to avoid damage or injury.
However, you the driver, must use it
properly. Use of this system is not a
substitute for safe, proper or legal
driving.
• Never back up while looking at the
monitor alone. You should always
check behind and around the vehi-
cle when backing up, in the same
way as you would if the vehicle did
not have the Rear View Camera
System.Ifyoubackupwhilelooking
only at the monitor, you may cause
damage or injury. Always back up
slowly.
•The Rear View Camera System is
not intended for use during exten-
sive back-up maneuvers or backing
into cross trac or pedestrian walk-
ways.
•Please, always remember, the area
displayed by the Rear View Camera
Systemis limited.Itdoes notdisplay
the entire panorama that is behind
you.
USAGE:
SAFETY INFORMATION
Reverse With Condence ™ 5
•Electric shock or product
malfunction may occur if this
product is installed
incorrectly.
• Use this product within
the voltage range specied. Failure
to do so can cause
electronic shock or product
malfunction.
• Take special care when
cleaning the monitor.
•Make sure to rmly ax the prod-
uct before use.
• If smoke or a burning smell
is detected, disconnect the
system immediately.
•Where the power cable may touch
a metal case, cover the cable with
friction tape. A short circuit
or disconnected wire may cause a
re.
• While installing the Rear View
System be careful with the wire
positioning in order to avoid wire
damage.
• The Rear View System should only
be used when the vehicle is in
reverse.
• Do not watch movies or
operate the monitor while driving;
as it may cause an
accident.
• Do not install the monitor
where it may obstruct drivers
view or obstruct an air bag
device.
• Dropping the unit may cause
possible mechanical failure.
INSTALLATION:
SAFETY INFORMATION
Rear View Safety
6
If you have questions about this product, contact:
Rear View Safety
1797 Atlantic Avenue
Brooklyn, NY 11233
Tel: 1.800.764.1028
IN NO EVENT SHALL SELLER OR MANUFACTURER BE
LIABLE FOR ANY DIRECT OR CONSEQUENTIAL DAMAGES OF
ANY NATURE, OR LOSSES OR EXPENSES RESULTING FROM
ANY DEFECTIVE PRODUCT OR THE USE OF ANY PRODUCT.
SAFETY INFORMATION
Reverse With Condence ™ 7
Before drilling please check that no cable or wiring is on the other side
of the wall. Please clamp all wires securely to reduce the possibility
of them being damaged while vehicle is in use. Keep all cables away
from hot or moving parts and electrical noisy components.
We recommend doing a benchmark test before installation
to insure that all components are working properly.
Step 1: Choose the monitor and camera locations.
Step 2: Install all cables in vehicle, when necessary a 0.8 (20mm)
hole should be drilled for passing camera cable through vehicles
walls. Install split grommets where applicable.
Step 3: Once all cables and wiring have been properly routed, perform
a system function test by temporarily connecting the system.
BEFORE YOU BEGIN
Rear View Safety
8
Precautions
Storage and Keeping
1. Do not expose the monitor to excessive heat or cold. The storage
temperature of this device is -30°C~+80°C, and the operating tem-
perature is -20°C~+70°C. Battery operating temperature is 0-70°C.
The humidity is Rh 90%.
2. Never use this device near water or damp locations.
3. Never use this device in environments with excessive moisture, dust
or smoke.
4. Avoid dropping or striking this device.
5. Avoid using this device in enclosed spaces, areas with excessive vi-
bration or areas subject to severe impacts.
6. Never puncture, scratch or use abrasive cleaning materials on this
device.
7. Do not place cables where they may be pinched or stepped on.
8. Leave at least a 2”space between the monitor and walls, cabinets or
other objects to allow adequate air circulation around the device.
9. The monitor is not designed to be waterproof.
PRECAUTIONS
Reverse With Condence ™ 9
Operating Precautions
1. The device may be powered by a 12 or 24 volt battery, as well as the
vehicle's electrical system.
2. Make sure all cables are connected properly. Improper cable con-
nections may damage the monitor. Remove the power cable connections
when not using the device.
3. The back-up battery can be recharged when the power is on.
4. When battery is fully charged, recharging will automatically stop.
5. If batteries are not used for a while, it may take longer to charge.
1. This monitor is high voltage. Only professionals should open the mon-
itor's case.
2. Do not watch the video while driving unless you are monitoring the
rear view camera display.
Special Note
Occasionally, a few highlights or dark spots may appear on the LCD screen. This
doesn’t necessarily indicate any monitor defects. Never try to repair this device
yourself. If any problems occur, immediately turn the display o and notify our
company or an authorized dealer. Any disassembly or modication may lead to
damage and will also void the warranty.
PRECAUTIONS
Warning!
Rear View Safety
10
Maintenance
1. Remove all cable connections from the monitor before cleaning the
device.
2. Use a mild household detergent and a slightly damp cloth to clean
the unit. Never use strong solvents such as thinner or benzine, as they
may damage the nish of the device.
MAINTENANCE
This symbol alerts the user to the presence of uninsulated“dangerous
voltage” inside the product. Never open the product case yourself, as
you may risk electric shock.
This symbol alerts the user to the presence of important operating
and maintenance instructions in the literature accompanying the
device.
This symbol reminds the user not to waste electronic equipment.
CAUTION
Any changes or modications not expressly approved in this manual could void
your warranty and lead to expensive repairs.
