Razer PRO CLICK Manual de usuario
PRO CLICK
ProClick_IPIG_200520.indd 1 26/5/20 10:30 AM
GET HELP WITH
HUMANSCALE
SUPPORT
We’re here to assist you with your new device.
Find software downloads, register
your product, or contact us by phone,
if you have any questions.
humanscale.com
800 400-0625
ProClick_IPIG_200520.indd 2 26/5/20 10:30 AM
GET HELP WITH
RAZER SUPPORT
We’re here to assist you with your Razer device.
Find software downloads, register
your product, or contact us by phone,
chat or email if you have any questions.
support.razer.com
WHAT’S INSIDE
• Razer Pro Click
A B
C
D E
F
G
H
I
N
TOP
Q
R
J
K
L
M
O
P
K
2.4
OFF
ALeft mouse button L5G optical sensor
BRight mouse button MUSB dongle compartment
CScroll wheel NSlider switch
DLeft tilt-click • Bluetooth mode
ERight tilt-click • Power off mode
FCycle DPI stage up button • 2.4GHz mode
GStatus indicator OPairing indicator
HMouse button 5 PPair/switch button
IMouse button 4 Q2.4GHz Wireless USB dongle
JMicro-USB port RUSB Cable
KUltraslick mouse feet
DPI stages are as follows: 800, 1800 (default), 3200, 5000, and 10000. The DPI
stages can be customized using Razer Synapse 3.
GET HELP WITH
RAZER SUPPORT
We’re here to assist you with your Razer device.
ProClick_IPIG_200520.indd 3 26/5/20 10:30 AM
WHAT’S NEEDED
PRODUCT REQUIREMENTS
• PC with a free USB port or Bluetooth connectivity
RAZER SYNAPSE REQUIREMENTS
• Windows® 7 64-bit (or higher)
• Internet connection for software installation
LET’S GET YOU COVERED
You’ve got a great device in your hands, complete with a 2-year limited warranty
coverage. Now maximize its potential and score exclusive Razer benefits by registering
at razerid.razer.com
Your product’s serial
number can be
found here.
2.4
OFF
Got a question? Ask the Razer Support Team at support.razer.com
ProClick_IPIG_200520.indd 4 26/5/20 10:30 AM
GETTING STARTED
CHARGING YOUR RAZER PRO CLICK
Plug the charging cable from your computer’s USB port to your Razer Pro Click.
This connection also acts as the wired mode for your device
For best results, please fully charge your Razer Pro Click before using it for the first
time. A depleted battery will be fully charged in approximately 4 hours. If the Razer
Pro Click has not been used for an extended period, you may need to recharge it
before use.
The Razer Pro Click requires a USB connection that can supply sufficient power
to charge the battery. The battery charging process of the Razer Pro Click may be
affected if connected to a non-powered USB hub or non-powered USB ports found on
certain keyboards and other peripherals. When in doubt, it’s preferable to connect the
Razer Pro Click directly to the USB port of your computer.
ProClick_IPIG_200520.indd 5 26/5/20 10:30 AM
CHARGING INDICATOR
While plugged in, the Razer Pro Click’s status indicator will display its current battery
level (as shown below).
<25% Red
Battery level Color
Breathing
Effect
26-50% Yellow Breathing
51-75% Orange Breathing
76-99% Green Breathing
100% Green Static
LOW POWER INDICATOR
The Razer Pro Click ’s status indicator will blink red twice in repeated intervals to
indicate that the battery’s power is less than 5%. This lighting sequence will repeat
until the battery is drained or the mouse is connected to the PC via the charging cable.
The indicator percentage can be customized using Razer software.
You can also check the Razer Pro Click’s battery level by moving the slider switch from
power off to either Bluetooth or 2.4Ghz mode. The status indicator will light up in the
color according to the mouse’s current power level (as shown below).
<25% Red
Battery level Color
26-50% Orange
51-75% Yellow
76-100% Green
ProClick_IPIG_200520.indd 6 26/5/20 10:30 AM
CONNECTING THE RAZER PRO CLICK VIA 2.4 GHZ MODE
1. Remove the compartment cover of the Razer Pro Click and pull out the
wireless USB dongle.
2. Close the compartment cover and connect the wireless USB dongle to the USB port
of your computer.
3. Switch the slider to 2.4 GHz mode. The pairing indicator will start blinking rapidly.
2.4
OFF
ProClick_IPIG_200520.indd 7 26/5/20 10:30 AM
4. Wait until the mouse automatically pairs with the wireless USB dongle. When
paired, the pairing indicator will change to static white for 3 seconds before turning
off.
2.4
OFF
PairedPairing
Keep the pairing devices within close proximity of each other for a faster and more
stable connection.
Congratulations, your Razer Pro Click is now ready to use in 2.4 GHz mode.
CONNECTING THE RAZER PRO CLICK VIA BLUETOOTH MODE
1. Switch the slider to Bluetooth mode ( ).
2.4
OFF
Paired
ProClick_IPIG_200520.indd 8 26/5/20 10:30 AM
2. Select a slot for your Bluetooth device by tapping the pair/switch button. You can
pair up to 3 Bluetooth devices on your Razer Pro Click.
1 (Default) Blue
Slot Color
2 Green
3 Yellow
Pairing
2.4
OFF
3. Press and hold the pair/switch button for 3 seconds. The pairing indicator will
blink twice in repeated intervals to show that the device is in pairing mode.
Pairing
2.4
OFF
4. Activate Bluetooth on your device and search for “Razer Pro Click” from the list
of devices found.
Searching for accessories...
Before pairing your Bluetooth devices,
make sure they’re in pairing mode
ProClick_IPIG_200520.indd 9 26/5/20 10:30 AM
5. Wait until both devices are paired. When paired, the pairing indicator will change
to static for 3 seconds before turning off.
2.4
OFF
Paired
Keep the pairing devices within close proximity of each other for faster and more
stable connection.
Once both devices have been paired, your Razer Pro Click will automatically reconnect
to the device whenever it is in Bluetooth mode and the device is within range.
Download the Razer Synapse installer from razer.com/synapse or find out more
about your brand-new mouse at support.razer.com
FRANÇAIS
CE QUI VOUS ATTEND
Les niveaux de sensibilité sont les suivants : 800,
1800 (par défaut), 3200, 5000 et 10 000. Les
niveaux de sensibilité peuvent être personnalisés
grâce à Razer Synapse 3.
CE DONT VOUS AVEZ BESOIN
NOUS SOMMES LA POUR VOUS
razerid.razer.com
support.razer.com
POUR COMMENCER
ProClick_IPIG_200520.indd 10 26/5/20 10:30 AM
