Инструкция для
Razer Star Wars The Old Republic
Перейти в карточку товара
8 800 775 98 98
Hear the ambient noises of an alien world, the chaotic explosions in battle on
Alderaan, or the iconic buzz of a lightsaber powering up behind you, thanks to the
Dolby® 7.1 surround sound power of the S W T O R Gaming
Headset by Razer. Get clear, precise three-dimensional audio for the tactical
advantage, preventing backstabs and pinpointing hotspots of action all around
you.
Included gold-backlit faction emblems of the Sith Empire and Galactic Republic
to the faction you choose. Then get a unique look on your headset with the
customizable multi-color lighting system a dazzling variety of colors that glow on
the underside of the headset like the aura of a Sith or Jedi Master ready for
battle.
TABLE OF CONTENTS
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS / REGISTRATION ............................................ 2
2. KEY FEATURES.............................................................................................................................. 3
3. TECHNICAL SPECIFICATIONS ....................................................................................................... 5
4. SETTING UP YOUR STAR WARS THE OLD REPUBLIC GAMING HEADSET.............................. 6
5. USING YOUR STAR WARS THE OLD REPUBLIC GAMING HEADSET....................................... 7
6. CONFIGURING YOUR STAR WARS THE OLD REPUBLIC GAMING HEADSET.......................... 9
7. SAFETY AND MAINTENANCE ..................................................................................................... 14
8. LEGALESE ................................................................................................................................... 15
1. PACKAGE CONTENTS / SYSTEM REQUIREMENTS / REGISTRATION
PACKAGE CONTENTS
S W T O R Gaming Headset by Razer
Galactic Republic Faction Symbols
Sith Empire Faction Symbols
Quick Start Guide
SYSTEM REQUIREMENTS
PC with USB port
Windows® 7 / Windows Vista® (Dolby®Pro Logic IIx, Dolby®Headphone)
Windows® XP 32-bit (Dolby®Pro Logic II, Dolby®Headphone)
Internet connection (for driver installation)
At least 100MB of free hard disk space
REGISTRATION
Please visit www.razerzone.com/registration/ for online product registration.
W
1 years
F www.razersupport.com.
2. KEY FEATURES
A Sith Empire Faction Symbols
B Galactic Republic Faction Symbols
C Dolby®7.1 Surround Sound
D Gold Plated USB Connector
E Adjustable Noise-filtering Microphone
F S W T O R Faction Slots
G Left Button 1 Microphone Volume Up
H Left Button 2 Microphone Volume Down
I Left Button 3 Microphone Mute
J Right Button 1 Speakers Volume Up
K Right Button 2 Speakers Volume Down
L Right Button 3 Speakers Mute
3. TECHNICAL SPECIFICATIONS
HEADPHONES
Dolby® Headphone / Dolby® Pro Logic® IIx
Drivers: 50mm Neodymium Magnets
Frequency Response: 20 - 20,000 Hz
Impedance: 32 H
Connector: Gold-plated USB Connector
MICROPHONE
Frequency Response: 50 - 16,000 Hz
Sensitivity: -37dB ± 4dB
Signal-to-Noise Ratio: 50dB
Pick-up Pattern: Unidirectional
4. SETTING UP YOUR STAR WARS THE OLD REPUBLIC GAMING
HEADSET
Step 1: Download the Razer Synapse 2.0 installer from
http://www.razersupport.com.
Step 2: Run the installer and follow the onscreen instructions.
Step 3: Register for a Razer Synapse 2.0 account and confirm your new account.
Step 4: Plug the S W T O R Gaming Headset into the USB
port of your computer.
Step 5: Open Razer Synapse 2.0 and login to your account.
Step 6: Wait until the software automatically downloads and installs.
5. USING YOUR STAR WARS THE OLD REPUBLIC GAMING HEADSET
EXTENDING YOUR HEADPHONES LIFESPAN
Before usage, we recommend gently stretching the headphones apart before
placing them over your head to minimize headband stress. However, do avoid
chnical limits.
MICROPHONE CONTROLS
On the Left Headphone, you can increase/decrease the microphone volume or
simply mute it.
G. Left Button 1 Microphone Volume Up
H. Left Button 2 Microphone Volume Down
I. Left Button 3 Microphone Mute
VOLUME CONTROLS
On the Right Headphone, you can increase/decrease the volume or
simply mute it.
J. Right Button 1 Speakers Volume Up
K. Right Button 2 Speakers Volume Down
L. Right Button 3 Speakers Mute
CHANGING THE STAR WARS THE OLD REPUBLIC FACTION SYMBOLS
You can swap the faction emblem as shown in the diagram above.
6. CONFIGURING YOUR STAR WARS THE OLD REPUBLIC GAMING
HEADSET
Disclaimer: The features listed here require the Razer Synapse 2.0 to be installed. These features are also
subject to change based on the current software version and your Operating System.
PROFILE
A Profile is a convenient way of saving all of the changes you have made on your
device. A single Profile can store all the settings you have made under the Volume
Tab, Equalizer Tab and Lighting Tab.
Profile 1 contains the default settings for your device. Any changes made on the
headset settings will be automatically saved. If you want to rename this profile,
you may do so by typing on the field below Profile Name. There are other options
available in the profile section such as creating a new profile by clicking the
button, deleting the current profile by clicking the button and
duplicating the current profile by clicking the button. You can even set a
profile to work with a specific program or application by using the Link Program
option and clicking the button to search for it.
