Raypak AVIA 264 Manual de usuario

AVIA Pool & Spa Heater

Tool Box Quick Reference Guide

Water Chemistry

GENERAL

Recommended Levels Fiberglass Pools Fiberglass Spas Other Pool & Spa Types

Water Temp. 68 to 88°F (20 to 31°C) 89 to 104°F (31 to 40°C) 68 to 104°F (20 to 40°C)

pH 7.3 to 7.4 7.3 to 7.4 7.6 to 7.8

Total Alkalinity (PPM) 120 to 150 120 to 150 80 to 120

Calcium Hardness (PPM) 200 to 300 150 to 200 200 to 400

Salt (PPM) 4500 MAXIMUM 4500 MAXIMUM 4500 MAXIMUM

Free Chlorine (PPM)22 to 3 2 to 3 2 to 3

Total Dissolved Solids (PPM) 3000 MAXIMUM33000 MAXIMUM33000 MAXIMUM3

For your health and the protection of your pool equipment, it is essential that your water be chemically balanced1.

The following levels must be used as a guide for balanced water.

1 Damage from corrosive water is not covered under warranty. Consult your product manual for more information.

2 Free Chlorine MUST NOT EXCEED 5PPM.

3 In salt water chlorinated pools, the total TDS can be as high as 6000PPM.

• Occasional chemical shock dosing of the pool or spa water should not damage the heater providing the water is

balanced.

• Automaticchemicaldosingdevicesandsaltchlorinatorsareusuallymoreecientinheatedwater,unlesscontrolled,

they can lead to excessive chlorine level which can damage your heater.

• Check valve should be installed between the heater outlet and a chlorinator or other chemical dosing device.

• Further advice should be obtained from your pool or spa builder, accredited pool shop, or chemical supplier for the

correct levels for your water.

• Warning: Electrolytic Corrosion and pH instability may be present with salt chlorinated pools.

Model Number and Serial Number Location

Before you call Raypak service, make sure you have the MODEL NUMBER and SERIAL NUMBER.

Model & Serial

number can also

be found inside the

bezel above digital

display.

Model & Serial

number located

on rating plate.

Model & Serial number located on

carton label.

GENERAL

Minimum Clearances

CLEARANCES

FLOORING: THIS UNIT CAN BE INSTALLED ON COMBUSTIBLE FLOORING.

See product manual for more information.

Location Indoor Installation

Top Unobstructed

Front 0”

Floor 0”

Back 0”

Right Side 3” (76 mm) from Panel - Water Side

Left Side 3” (76 mm) from Panel - Vented Side

Location Outdoor Installation

Top Unobstructed

Front 0”

Floor 0”

Back 0”

Right Side 3” (76 mm) from Panel - Water Side

Left Side 6” (152 mm) from Vent Cap

Minimum Clearances* – Outdoor

DO NOT install near

sprinklers.

DO NOT install within

3 feet (0.9 m) of a heat

pump or an outdoor

condensing unit.

*Check state and local codes before

proceeding. The minimum clearances

providedaredenedbyNFGC

(National Fuel Gas Code).

CLEARANCES

Minimum Clearances – Indoor

CLEARANCES

The heater must have both combustion air and

ventilation air.

• Ventilation air opening 12”(305 mm) max from

the ceiling

• Combustion air opening 12”(305 mm) max

fromtheoor

All air from outdoors, each opening shall have a

net free area as shown in table.

Check state and local codes before proceeding. Some states do not recognize the NFGC and require larger openings.

Model

Unrestricted

Opening

Sq. In. (m2)

Typical

Screened or

Louvered

opening

Sq. In. (m2)

Typical

Screened and

Louvered

opening

Sq. In. (m2)

264 66 (0.04) 99 (0.06) 132 (0.09)

404 100 (0.06) 150 (0.1) 200 (0.13)

Gas Line Sizing

Maximum Equivalent Pipe Length ft (m)

Natural Gas 1000 BTU/FT3

0.60SpecicGravity@0.5in.WCPressureDrop

Propane Gas 2500 BTU/FT3

1.53SpecicGravity@0.5in.WCPressureDrop

Model No.

Size 3/4” Size 1” Size 1-1/4” Size 1-1/2”

NAT PRO NAT PRO NAT PRO NAT PRO

264 15

(4.6)

(10.7)

(12.2)

125

(38.1)

210

(64.0)

480

(146.3)

445

(135.6)

404 *15

(4.6)

(8.8)

(16.8)

(29.0)

225

(68.6)

215

(65.5)

280

(85.3)

GAS SUPPLY

EFFECTS OF LOW GAS PRESSURE

• Pulsatingburnerame/Flamelost

• DelayedIgnition/Hardlighto

• Exposure to condensation

• Emissions not at compliance levels

• Damage burner

• Sooting

• Ignition failure

*A3/4”gaslinecanbeusedforupto5’(1.5m)maximumlengthfromthegasvalveinadditiontothesedimenttrap.

Gas Pressure Test

Gas Required Pressure Manifold

Pressure

Min. Max.

Natural Gas 3.5”

(Dynamic)

10.5”

(Static) -0.3”

Propane Gas 8.0”

(Dynamic)

13.0”

(Static) -0.3”

GAS SUPPLY

• Propane requires an external “pounds

to inches” regulator

Inlet Gas Pressure

Gas Valve

Manifold

Gas Pressure

Gas Valve

Gas Line Sediment Trap

GAS SUPPLY

Check state and local codes before proceeding. Some states do not recognize the NFGC.

Sediment Trap should be located as close

to the inlet of the appliance as practical.

ELECTRICAL

Model 264

Model 404

Printed circuit board. Boards cannot be

interchanged.

Circuit Board
