Rand McNally Gps navigator Manual de usuario

Complete Personal Navigation System

GPS NAVIGATOR

Quick Start Guide

Rand McNally GPS Navigator Quick Start GuideHelp (866) 627-3526

Overview

Battery Charge Indicator

The indicator will shine orange during the

charging process. It will shine green when

the battery is completely charged.

Touch Screen

Hardware buttons

On-/Off button

Navigation Menu

Increases the volume

Reduces the volume

This Quick Start Guide provides a brief overview of

the Rand McNally GPS Navigator and its functions.

For more detailed information, see the User Guide.

The User Guide can be found on the supplied CD

or at www.randmcnally.com/gps.

Rand McNally GPS Navigator Quick Start Guide 1Help (866) 627-3526

On-/Off button

Navigation Menu

Increases the volume

Reduces the volume

Stylus

Memory Card Slot

External GPS antenna jack

Headphone jack

Speaker

Mount connector

Reset button

Mini-USB- Connector

Main POWER switch

Always leave the main switch

ON, unless you want to reinstall

software.

GPS antenna

This Quick Start Guide provides a brief overview of

the Rand McNally GPS Navigator and its functions.

For more detailed information, see the User Guide.

The User Guide can be found on the supplied CD

or at www.randmcnally.com/gps.

Rand McNally GPS Navigator Quick Start Guide2 Help (866) 627-3526

Powering On for the First Time

Insert the included memeory card in the top slot.•

NOTE: This process needs to be done only once,

prior to the initial use. After initial start, use

the power button on the top right hand side

of the GPS Navigator.

Using the device stylus (stored in the lower left corner of

the back side of the device), or a ballpoint pen, move the

switch on the bottom of the device to the “on” position

•

see page 1

Rand McNally GPS Navigator Quick Start Guide 3Help (866) 627-3526

Attaching the GPS Navigator to the Windshield

Insert 12v cable into USB port

Attach the device to the cradle of the

mounting holder

Place the suction cup ﬁrmly on the windshield

Switch lever to hold in place

Plug the 12v car charger into cigarette lighter

Rand McNally GPS Navigator Quick Start Guide4 Help (866) 627-3526

Getting Started

To turn the Rand McNally GPS Navigator on

push the button on top right side of unit.

Use touch-screen for all menu/screen selections.

Read and accept the safety message.

The ﬁrst use of the Rand McNally GPS Navigator

requires a few additional steps:

1After turning on your unit, you will be prompted to

select your language.

2Several startup screens will ﬂash. When asked

“Do you want to select the navigation map now?” tap .

3You will be taken to a screen that asks you to select a

geographic map area. Highlight the map that corresponds

to your current geographic region (this can be changed

later from the Settings screen).

•

NOTE: When the unit has been off for a few days

or more, it may take up to 10 minutes to

receive the GPS signal. With regular usage

it will acquire a signal in under 2 minutes.

For best results, keep unit standing still and

in a clear outdoor area during initial startup.

Rand McNally GPS Navigator Quick Start Guide 5Help (866) 627-3526

Selecting a Destination

Main menu

Navigation menu

Address screen

Keyboard screen

From the initial Main menu

tap to access the Navigation

menu .

At any time, press the button on

the right side of your GPS Navigator to

return to the navigation menu.

Tap to access the address

entry screen .

Enter destination information by

tapping on the address ﬁelds and

typing the information using the

on-screen keyboard .

Enter ZIP code (if known) or City

ﬁrst, then Street name, then

Address Number.

After entering three or more letters,

the GPS Navigator will provide you

with a list of possibilities. Continue

entering or scroll through the list to

select the name you want.

Tap to enter a space.

Tap to enter numbers.

Tap to delete or go back a space.

Tap to conﬁrm the entered data.

Once the address information is

completely entered, tap

The GPS Navigator will calculate

your route and then the navigation

map will appear and voice prompts

will begin.

•

Rand McNally GPS Navigator Quick Start Guide6 Help (866) 627-3526

Selecting a Destination continued

Navigation screen

Options screen

Follow the turn-by-turn voice prompts

and visual directions on the map.

The navigation arrow

shown on the Navigation screen

will show you your progress as you

move down the street.

The GPS Navigator will automatically

re-route you if you miss a turn.

At any time, you can tap the green

menu bar icon in the upper right

corner for more options to control

the map.

At any time, you can tap on the map

itself to be shown options for

detours, night mode, quit

navigation, etc.

•

Zoom out to view

entire route.

Zoom in/out

Main menu

Hide

menu bar

Switch between panning

and manual zoom modes

Freeze / unfreeze map while navigating

Repeat the

voice directions

Rand McNally GPS Navigator Quick Start Guide 7Help (866) 627-3526

Enter a Point of Interest

Main menu

Navigation menu

Point of Interest screen

From the Main menu tap

to access the Navigation menu .

Tap on the Navigation

menu to access the Point of

Interest entry screen .

On the Point of Interest screen ,

chose a point of interest near current

location or in a different city.

Enter City, Category, Subcategory

information on the Category screen .

Tap the Point of Interest ﬁeld to display

the list of choices.

Once the point of interest is selected,

tap , then tap

•

Category screen

Rand McNally GPS Navigator Quick Start Guide8 Help (866) 627-3526

Recent destinations are automatically

stored and can be permanently saved

in My Favorites.

To save any address to My Favorites:

After inputting an address or

selecting a Recent Destination,

tap .

A new screen will open. Type in a

name of your destination.

Any time you save a destination,

it will be stored in your My Favorites

folder as seen on the Navigation

menu .

To navigate to a recent or

favorite destination:

Tap Recent Destinations or

My Favorites on the

Navigation Menu .

Find destination by scrolling through

list .

Select destination by tapping .

Once the address information is

selected, tap

on the destination address screen .

•

Recent Destinations & My Favorites

Destination address screen

Navigation menu
