RAMSET HD22 Especificaciones

THISTOOLISFORUSEONLYBYLICENSEDOPERATORS.

YOU MUST OBTAIN A LICENSE BEFORE USING IT. A

TOOL OPERATOR'S CARD WILL BE ISSUED TO YOU

AFTER SUCCESSFULLY COMPLETING THE ENCLOSED

EXAM AND RETURNING IT TO RECEIVE YOUR CARD

AND ACTIVATE YOUR WARRANTY. OPERATOR'S

LICENSE CAN ALSO BE OBTAINED AT: www.ramset.com

MODEL HD22

LOW VELOCITY POWDER ACTUATED TOOL

Operator's Instruction & Training Manual

• The Ramset HD22 is a light duty tool designed for applications such as small

room additions and basement remodels. Tool life will vary depending on work site

conditions and application.

• The model HD22 is a low velocity piston type fastening tool. It is designed for

use with Ramset .22 caliber CW powder loads and Ramset fasteners.

• Do not operate the Model HD22 before studying this manual carefully and

thoroughly understanding the material contained herein.

IMPORTANT: The tool warranty is only activated upon receipt by ITW Brands of the

completed Operator's Exam.

Part #00022

Rev. 8/07

RD v001MA

WARRANTY

ALL WARRANTIES OF THE PRODUCTS DESCRIBED HEREIN, EXPRESSED OR

IMPLIED, INCLUDING THE WARRANTY OF MERCHANTABILITY AND FITNESS

FOR PARTICULAR PURPOSES ARE SPECIFICALLY EXCLUDED, EXCEPT FOR THE

FOLLOWING: ITW BRANDS WILL REPAIR OR REPLACE AT ITS SOLE OPTION

ANY TOOL PART OR FASTENER WHICH WITHIN 90 DAYS AFTER SALE BY

ITW BRANDS IS FOUND BY ITW BRANDS TO BE DEFECTIVE IN MATERIAL OR

WORKMANSHIP, NORMAL WEAR AND TEAR EXCLUDED. THIS IS THE SOLE

WARRANTY OF ITW BRANDS AND THE SOLE REMEDY AVAILABLE TO THE BUYER.

NOTE: It is very important that the operator of this tool completely reads and under-

stands the entire tool manual and completes the Operator's Exam on the last page.

The warranty will not be valid until the test is received, along with a copy of your

sales receipt, and reviewed by ITW Brands. Operator's license can also be obtained

at: www.ramset.com

TO AVOID SERIOUS INJURY OR DEATH

Operators and bystanders

must wear eye and hearing

protection.

Never close tool with hand over fastener loading end of the tool.

A serious hand injury from penetration by the piston or a

discharged fastener could result.

Read manual before

operating tool.

WARRANTY

SAFETY PRECAUTIONS

1 SAFETY PRECAUTIONS

WARNING!

The following pages contain detailed warnings,

cautions, and rules of safe operation with which the

operator must be familiar and follow to avoid serious injury or death. After thorough-

ly reviewing this manual, complete the Operator's Exam and return to ITW Brands for

your Operator's Card and to activate your warranty.

BEFORE LOADING AND FIRING PROTECT YOURSELF AND OTHERS

1. Never place your hand or fingers over the

front muzzle of the tool - the fastener or

piston can seriously injure your hand in

the event of an accidental discharge.

2. Always use only Ramset fasteners and

loads at all times for consistent tool

functioning.

3. Operators and bystanders must wear

eye and hearing protection at all times.

Serious eye injury and hearing loss can

result if proper gear is not worn.

4. Keep work area clear and where required

always post warning signs when using

the tool. Sign should state, "Powder

Actuated Tool in Use" and can be obtained

by contacting Technical Services at

1-877-ITW-BRANDS (1-877-489-2726).

IMPORTANT: In order to activate your warranty, you must read this

manual thoroughly, complete the exam and return to the address on

the back page of this manual.

1. Prior to using the tool, make sure it

is unloaded and then do the functional

check: Check the functioning of the tool,

without a powder load or fastener, by

pushing down against the work surface,

making sure the groove on the barrel

aligns with the markings on the receiver.

Repeat this several times to insure tool is

operating properly.

2. Always check the material being fastened into, by performing the Center

Punch Test: Using a fastener as a center punch, strike the fastener against the

work surface using an average hammer blow and check the results. Wear eye

protection while performing this test.

3. If the base material is suitable for powder

actuated fasteners, make a test fastening

into a suitable base material with a num-

ber 1 (gray) load. If the number 1 load

does not fully set the fastener, try the next

higher power load until the proper level

is found. Failure to properly test fire to

determine correct power level may result

in overpowering the fastener, causing

it to pass completely through the work

material, injuring someone on the other

side. Overpowering the fastener may also

damage the tool.

SAFETY PRECAUTIONS

SAFETY PRECAUTIONS 2

Prepare for Loading

1. If the fastener point

is blunted, material

is too hard.

2. If material cracks or

shatters, material is

too brittle.

3. If the fastener pen-

etrates the material

easily, material is

too soft.

4. If the fastener makes

small indentation into

material, material is

suitable for fastening.

(Typical base materials: poured concrete, structural steel and masonry.)

NOTE: Ramset loads are designed for

use with Ramset tools. Do not attempt

to use other power loads. Doing so may

lead to unintentional load discharge as

well as damage to the tool. This tool is

NOT designed to use red (5) or purple

(6) power level loads. Using red (5) or

purple (6) loads can result in serious

injury to the operator or bystanders.

Power Levels Available for HD22:

Power Level No. Color

1. Gray Weakest

2. Brown

3. Green

4. Yellow Strongest

SAFETY PRECAUTIONS

3 SAFETY PRECAUTIONS

1. Always point the tool away from people

and in a safe direction.

2. Never use tool when explosives or flam-

mable materials are nearby.

3. Never fire the tool without a fastener.

The piston will protrude from the muzzle

of the tool, enter the work surface and

possibly cause injury to the operator or a

bystander. Firing without a fastener may

also damage the tool.

4. Always hold the tool perpendicular to the

work surface to avoid serious injury or

death from ricocheting fasteners. Use a

spall guard* whenever possible.

5. Never set a fastener too close to another

fastening or a free edge. This can cause

the fastener to ricochet. Always follow

the minimum spacing and edge distance

requirements.

6. Never fire into very hard or brittle mate-

rials such as cast iron, tile, glass or

rock. These materials can shatter, causing

sharp fragments and/or the fastener to fly

freely.

*To order optional spall guard,

call 1-877-ITW-BRANDS (1-877-489-2726)

Operating the Tool

SAFETY PRECAUTIONS

SAFETY PRECAUTIONS 4

7. Never fasten into structural steel base

material thinner than 3/16". Never fasten

into concrete base material thinner than 3

times shank penetration. Always maintain

minimum penetration requirements.

8. Fastening into block and masonry is not

recommended. When it is necessary to fas-

ten into masonry walls, it is recommended

that fasteners be driven into the horizontal

joints only. Published holding values for

these materials is not available due to the

inconsistency of the materials.

9. Never fasten through or into a hole. Always

maintain at least 1/2" distance from any

pre-drilled or pre-punched hole.

10.

Should you decide not to make a fastening

after the tool has been loaded, always

remove the powder load first, then the

fastener. Never attempt to pry an unfired load

out of the tool. Call The Technical Department

at 1-877-ITW-BRANDS (1-877-489-2726) for

assistance.

1. Never leave a loaded tool unattended.

Someone may pick it up, not know it is

loaded and accidentally discharge the tool

causing serious injury or death. Never load

the tool until you are prepared to complete

the fastening. Always store loads and tool,

unloaded, under lock and key.

Handling Tool and Powder Loads

STEEL CONCRETE

SAFETY PRECAUTIONS

5 SAFETY PRECAUTIONS

2. Never carry fasteners or other hard

objects in the same pocket or container

with powder loads. The loads could be set

off, causing serious injury or death.

3. A person that is color blind must be extra

careful when loading the tool. One must

only take a load from a box that is identi-

fied by powder load number. Never use

loose loads that can be misidentified.

Powder loads must never be used in fire-

arms. They are more powerful than the

charges normally used in small firearms.

This could result in serious injury or death.

1. A powder actuated fastener, after it has

been installed, is considered a permanent

fastening. Do not attempt to pull a fastener

out of concrete or steel. Attempting to do

so may result in serious injury.

If the tool fails to fire, hold the tool firmly against

the material for 30 seconds. Remove the tool

from the work surface, open the barrel to reset

the piston. Re-chamber the load and repeat

firing sequence. If the tool fails to fire again,

hold for 30 seconds, unload the tool, and then

discard the load into a bucket of water. Never

attempt to pry an unfired load out of the tool.

Call The Technical Department at

1-877-ITW-BRANDS (1-877-489-2726) for

assistance.

Fasteners

Operating Problems

SAFETY PRECAUTIONS

SAFETY PRECAUTIONS 6

.300 Head Plastic Fluted Drive Pins

Shank Shank

Length Diameter

1/2" .145

5/8" .145

3/4" .145

1" .145

1-1/4" .145

1-1/2" .145

1-3/4" .145

2" .145

2-3/8" .145

2-1/2" .145

.300 Head Plastic Fluted Drive Pin

with 7/8" Washer

Shank Shank

Length Diameter

1" .145

1-1/4" .145

1-1/2" .145

2" .145

2-1/2" .145

2. Never unload or disassemble a jammed,

stuck or broken tool which contains a

live powder load. This may cause the

tool to fire unintentionally. Always point

a jammed tool away from yourself

and other people. Immediately store

a jammed or broken tool in a locked

container after tagging it "Defective -

Do Not Use". Call 1-877-ITW-BRANDS

(1-877-489-2726) for technical assistance.

RAMSET FASTENER SELECTION GUIDE

CAUTION!Be sure to read and understand all safety precautions

and complete the Operator's Exam before attempting to

operate the tool. Check to be sure the tool is unloaded and no foreign objects or

fasteners are in the barrel. Perform daily function test before operating.

OPERATION

Check the functioning of the tool, without a powder load or fastener in the tool, by

pushing down against the work surface, checking to be sure the groove portion of

the barrel aligns with the arrows on the tool body. Function unloaded tool several

times and insure that the breech parts and firing mechanism operate freely before

fastening with the tool.

1. Point the tool in a safe direction and slide

the barrel forward with your other hand.

This action resets the piston for the next

fastening. Loss of power may be the result

of an improperly reset piston.

2. Place a fastener, point out, into the front

end of the barrel until the plastic fluted tip

fits inside. Always load the fastener before

inserting the power load to prevent acci-

dental discharge. Do not use excessive

force when inserting the fastener. Stop if

excessive force is required and call 1-877

ITW-BRANDS for technical assistance.

3. Insert the powder load after making sure

the chamber is clear. The powder load will

not fully set until the tool is compressed

against the work surface. Always start

with the lowest level and increase until the

proper level is found. Note: Overpowering

a fastener into steel or concrete is

dangerous.

Note: Before making the fastening, the base material should be center punch tested

for suitability of powder actuated fastenings (see pg. 2).

TOOL OPERATION

7 TOOL OPERATION

TOOL OPERATION

TOOL OPERATION 8

4. Close tool by pulling the barrel back to

the semi-closed position. Never attempt

to close the tool by exerting force on the

front of the barrel. Never place your fingers

or hands over the muzzle end of the bar-

rel. The proper position of the hands and

fingers are shown in the illustration.

5. With the tool in the semi-closed position,

place it against the material to be fastened.

Hold the tool firmly at 90º with one hand and

completely depress, check to be sure the

groove on the barrel aligns with the marking

on the receiver.

6. Using a one pound hammer, strike the

firing pin button with a sharp, firm blow.

If the tool fails to fire, follow the misfire

procedure on page 5.

Note: It is important to strike the firing pin button

firmly and squarely. A light blow or one off-center

may not activate the load, however it will jar the

piston out of position which will cause a reduction in

power. (See Troubleshooting, page 10.)

7. To prepare for the next fastening, point the

tool in a safe direction, and slide the barrel

firmly forward. This action ejects the fired

load out of the tool and properly resets the

piston. The tool is now ready for the next

fastening.

Semi-close

position

THOROUGH CLEANING

To maintain your tool in good working condition, it is recommended that the tool be

cleaned after heavy use or constant exposure to dirt and debris. Call 1-877-ITW-BRANDS

(1-877-489-2726) for service information.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Herramientas eléctricas de RAMSET

RAMSET

RAMSET InsulFast GT3 Manual de usuario

RAMSET

RAMSET XT540 Guía de mantenimiento y servicio

RAMSET

RAMSET RT400 M Guía de mantenimiento y servicio

RAMSET

RAMSET D60 Guía de mantenimiento y servicio

RAMSET

RAMSET D45A Guía de mantenimiento y servicio

RAMSET

RAMSET GYPFAST Guía de mantenimiento y servicio

RAMSET

RAMSET CUAR18 Manual de usuario

RAMSET

RAMSET SA270 Guía de mantenimiento y servicio

RAMSET

RAMSET TrakFast TF1100 Manual de usuario

RAMSET

RAMSET RW150ES Manual de usuario

RAMSET

RAMSET MD380 Guía de mantenimiento y servicio

RAMSET

RAMSET D45A Manual de instrucciones

RAMSET

RAMSET LOW VELOCITY POWDER ACTUATED TOOL Guía de instalación

RAMSET

RAMSET D45 Guía de mantenimiento y servicio

RAMSET

RAMSET FrameBoss pat003 Manual de usuario

RAMSET

RAMSET T4 Manual de usuario

RAMSET

RAMSET T2 Manual de usuario

RAMSET

RAMSET COBRA+ Guía de instalación

RAMSET

RAMSET M70 Manual de usuario

RAMSET

RAMSET RA27 Manual de usuario

RAMSET

RAMSET TF1200 Manual de usuario

RAMSET

RAMSET T2 Guía de mantenimiento y servicio

RAMSET

RAMSET D60 Manual de usuario

RAMSET

RAMSET GYPFAST Manual de usuario

Manuales populares de Herramientas eléctricas de otras marcas

AEG

AEG OMNI-JS Manual de usuario

SIP

SIP 01533 Manual de usuario

Ribimex

Ribimex PRS499 Manual de usuario

3M Fiber Optic Connector Crimp Tool Manual de usuario

Ryobi

Ryobi P524 Manual de usuario

ROJEK

ROJEK FSN 300A Manual de usuario

Kemper

Kemper 1740PRO Manual de usuario

WABCO

WABCO OptiTire Manual de usuario

EINHELL

EINHELL TE-MS 18/210 Li Manual de usuario

Orgapack

Orgapack OR-T 85 Guía rápida

TOUGHCUT

TOUGHCUT Diamond 400 Manual de usuario

Yaros

Yaros PB-3603 Manual de usuario

Fein

Fein BSS 2.0 E Guía de configuración

Baileigh Industrial

Baileigh Industrial SS-2725 Manual de usuario

Milwaukee

Milwaukee 2674-20 Manual de usuario

Fein

Fein BLs 1.6 Manual de usuario

Princess

Princess Electric Multi Sharpener Manual de usuario

FOREDOM

FOREDOM K.1050 Manual
