MultiRAE Plus

Using the

MultiRAE Plus

personal multigas

monitor

Firmware v 3.12B

The Hazardous Environment Detection Company

Training Agenda

• MultiRAE Plus features

• Turning on the MultiRAE Plus

• Recommended Daily Start-up Procedure

• User displays

• Alarm modes

• Programming displays

• Calibration

The Hazardous Environment Detection Company

MultiRAE Plus Features: Sensors

• Oxygen: 0-30%

• Combustibles: 0-100% of LEL

• Toxic sensors: select two from CO,

H2S, SO2, NO, NO2, Cl2, HCN, NH3,

PH3

• VOC monitor: 0-2000 PPM

The Hazardous Environment Detection Company

MultiRAE Plus Features: Easy Sensor Access

• New innovative

casing design

• Easy access to

sensors with

penny, nickel, or

dime

The Hazardous Environment Detection Company

MultiRAE Plus Features: Reliability

• Extremely rugged for extensive field use

• Weather proof case

•-4

°F to 113°F (-20°C to 45°C)

• 4-way power: Li-Ion(NiCad), alkaline or

run continuously on 110 VAC and 12 VDC

• Runs 10-12 hours with pump

• RFI protection against radio interference

• Intrinsically safe: Class I, Division I,

Groups A, B, C, D; UL, cUL, ATEX

• LEL over-range protection

The Hazardous Environment Detection Company

MultiRAE Plus Features: Rugged Case

Buzzer &

Exhaust

Display Charger

Port Serial

Port

The Hazardous Environment Detection Company

MultiRAE Plus Features: Simple Faceplate

Light

Sensor

Alarm LEDs

• Three buttons on a sealed membrane

faceplate:

– Y/+ (horn): clears & tests alarms

– N/- (light): turns on manual backlight for

90 seconds

–MODE(ON)

The Hazardous Environment Detection Company

MultiRAE Plus Features: Rugged Boot

External Filter

Rugged

Rubber

Boot

Belt Clip

The Hazardous Environment Detection Company

MultiRAE Plus Features: Internal Pump

• Makes remote sampling easy

• Sample draw over 100 feet!

• External filter for added protection

• Pump stall feature: when moisture is detected

or when pump is blocked the pump will shut

off, protecting the MultiRAE Plus from

potential damage

• ~150cc/min at low flow, ~250cc/min at high

flow

• Only use teflon tubing when PID is installed

The Hazardous Environment Detection Company

MultiRAE Plus Features: External Filter

• Always use the external filter

• Replace when it looks very dirty

• Replace when MultiRAE Plus is in

pump alarm with the filter on and you

can clear the pump alarm with the

filter off.

You wouldn’t leave your house

without putting on your pants

so don’t use the MultiRAE Plus

without its external filter!
