Radio Shack CD-3315 Manual de usuario

Cat. No. 14-539

OWNER’S MANUAL

Please read before using this equipment.

Portable AM/FM Stereo Single Cassette Recorder

with CD Player

CD-3315

14-539.fm Page 1 Wednesday, June 30, 1999 1:50 PM

FEATURES

Your Radio Shack CD-3315 Portable

AM/FM Stereo Single Cassette Re-

corder with CD Player is an all-in-one

musicsystem.Itissmalland portable

so you can take it anywhere, indoors

or out. Anywhere you go, at work or

play, you can listen to the radio, pre-

recorded cassette tapes, or compact

discs, or even make your own re-

cordings!

CASSETTE DECK FEATURES

Automatic Stop—protects the tape

and tape-handling parts by automati-

cally stopping the tape when it reach-

es the end.

Soft Cassette Tape Eject—softly

opens the cassette compartment

door so the cassette does not pop

out.

One-Touch Recording—lets you

start recording by pressing a single

button.

Automatic Level Control—auto-mati-

cally adjusts the recording level.

Tri-Source Recording—lets you

record from the CD player or radio, or

make live recordings using the built-

in microphone.

CD PLAYER FEATURES

Automatic Search Music System —

lets you quickly find any track on a

CD.

Programmable Play—lets you pro-

gram and play up to 20 tracks in any

sequence.

Repeat Play—lets you repeat a

track, an entire CD, or a series of pro-

grammed tracks.

OTHER SPECIAL FEATURES

Extended Bass System—provides

richer, fuller bass.

Power Options—let you power your

system from AC power or internal

batteries. You can power it from your

vehicle using an optional DC-to-AC

inverter.

For your records, we recommend

you record the CD-3315’s serial

numberin the space below. The seri-

al number is on the back of the CD-

3315.

Serial Number: ________________

Read this manual carefully. It will

help you get the most enjoyment

from your system.

1995 Tandy Corporation.

Radio Shack is a registered trademark used by Tandy Corporation.

14-539.fm Page 2 Wednesday, June 30, 1999 1:50 PM

Compact discs that you can play on

your system’s CD player have this

mark on them.

Warning: This system employs a la-

ser light beam. Only a qualified ser-

vice person should remove the cover

or attempt to service this device, due

to possible eye injury.

Warning: To prevent fire or shock

hazard, do not expose this system to

rain or moisture.

This symbol is intended to

alert you to the presence of

uninsulated dangerous

voltage within the system’s

enclosure that might be of

sufficient magnitude to

constitute a risk of electric

shock. Do not open the

system’s case.

This symbol is intended to

inform you that important

operating and mainte-

nance instructions are in-

cluded in the literature

accompanying this system.

The graphical symbols with the sup-

plemental markings are located on

the back of the unit.

RISK OF ELEC-

TRIC SHOCK.

DO NOT OPEN.

CAUTION: TO REDUCE THE

RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER OR

BACK. NO USER-SERVICE-

ABLE PARTS INSIDE. REFER

SERVICING TO QUALIFIED

PERSONNEL.

CAUTION

14-539.fm Page 3 Wednesday, June 30, 1999 1:50 PM

14-539.fm Page 4 Wednesday, June 30, 1999 1:50 PM

CONTENTS

POWER SOURCES 5

Using Internal Batteries 5

Using the AC Power Cord 6

Powering the CD-3315 In

Your Home 6

Powering the CD-3315 In

Your Vehicle 6

USING HEADPHONES 7

Listening Safely 7

Traffic Safety 7

RADIO OPERATION 8

CD PLAYER OPERATION 10

Loading/Unloading a CD 10

Playing a CD 10

Automatic Search Music System

11 Repeat Play 11

Programmed Play 12

Checking a Programmed

Sequence 12

Editing a Programmed

Sequence 12

CASSETTE PLAYER OPERATION

13 Playing a Cassette Tape 13

Recording 13

Recording from the CD

Player 14

Recording from the Radio

15 Making Live Recordings 15

CARE AND MAINTENANCE 16

CD Care Tips 17

Tape Tips 17

Erasing a Cassette Tape 17

Preventing Accidental Era-

sure 17

Cleaning the Tape-Han-

dling Parts 18

Restoring Tape Tension and

Sound Quality 18

SPECIFICATIONS 19

14-539.fm Page 5 Wednesday, June 30, 1999 1:50 PM

POWER SOURCES

You can power the CD-3315 from:

• Internal battery power, using six D batteries

• Standard AC power, using the

supplied AC power cord and an

AC outlet or your vehicle and an

optional DC-to-AC inverter

USING INTERNAL BATTERIES

You can power the CD-3315 from six

D batteries (not supplied). For the

best results, we recommend alkaline

batteries, such as Radio Shack Cat.

No. 23-550.

1. Press down on the two tabs

above the battery compartment

cover and pull out the cover to

remove it.

2. If necessary, remove and dis-

pose of the old batteries.

Cautions:

• To protect the CD-3315 from

possible battery leakage,

never leave dead, weak, or

old batteries in the CD-3315.

• If you do not plan to use the

CD-3315 for a month or more,

or if you plan to use the exter-

nal AC power cord, remove

the batteries.

3. Insert six D batteries in the com-

partment as indicated by the

polarity symbols (+ and –)

marked above the compartment.

Cautions:

• Use only fresh batteries of the

recommended size and type.

• Never mix fresh and old bat-

teries.

4. Replace the battery compart-

ment cover.

Note: If the CD-3315’s sound weak-

ens or distorts, replace the batteries.

14-539.fm Page 6 Wednesday, June 30, 1999 1:50 PM

USING THE AC POWER CORD

Powering the CD-3315 In Your

Home

Plug the supplied AC power cord into

AC IN on the back of the CD-3315.

Then plug the other end into a stan-

dard AC outlet.

Caution: To avoid exposure to haz-

ardous voltage, always plug the AC

power cord into the CD-3315 before

you plug it into the standard AC out-

let. Always unplug the AC power cord

from the standard AC outlet before

you unplug it from the CD-3315.

Note: The CD-3315 automatically

disconnects internal batteries when

you connect the AC power cord.

Powering the CD-3315 In Your

Vehicle

Convert your vehicle’s DC power to

120V AC using a DC-to-AC inverter,

such as Radio Shack Cat. No. 22-

132 (not supplied). Follow the in-

structions included with the inverter

to connect it to your vehicle’s ciga-

rette-lighter socket. Then plug the

supplied AC power cord into AC IN

on the back of the CD-3315 and plug

the other end into the AC outlet on

the inverter.

Caution: To avoid exposure to haz-

ardous voltage, always plug the AC

power cord into the CD-3315 before

you plug the power cord into the in-

verter. Always unplug the AC power

cord from the inverter before you un-

plug the power cord from the CD-

3315.

If the CD-3315 hums when you turn it

off, just unplug the inverter from your

vehicle’s cigarette-lighter socket.

14-539.fm Page 7 Wednesday, June 30, 1999 1:50 PM

USING HEADPHONES

For private listening, you can insert a

pair of stereo headphones (not sup-

plied) with a 1/8-inch plug into the

PHONES jack.

Notes:

• Your local Radio Shack store

carries a wide selection of ste-

reo headphones.

• Connecting headphones auto-

matically disconnects the built-in

speaker.

LISTENING SAFELY

To protect your hearing, follow these

guidelines when you use head-

phones.

• Set the volume to the lowest set-

ting before you begin listening.

After you begin listening, adjust

the volume to a comfortable

level.

• Do not listen at extremely high

volume levels. Extended high-

volume listening can lead to per-

manent hearing loss.

• Once you set the volume, do not

increase it. Over time, your ears

adapt to the volume level, so a

volume level that does not

cause discomfort might still

damage your hearing.

TRAFFIC SAFETY

Do not wear headphones while oper-

ating a motor vehicle or riding a bicy-

cle. This can create a traffic hazard

and is illegal in some areas.

Even though some headphones are

designed to let you hear some out-

side sounds when listening at normal

volume levels, they still present a

traffic hazard.

14-539.fm Page 8 Wednesday, June 30, 1999 1:50 PM

RADIO OPERATION

Warning: To protect your hearing, set

VOLUME to its lowest setting before

you turn on the radio.

1. Set FUNCTION/POWER to

RADIO. The POWER indicator

lights, and the radio turns on.

2. Set AM/FM to AM or FM.

3. Set FM MODE using these

guidelines.

• To listen to FM stereo, set it to

STEREO. The FM STEREO

indicator lights when you

receive a stereo FM broad-

cast.

• To listen to FM monaural, set

it to MONO.

4. Adjust TUNING to the desired

station.

Notes:

• For the best AM reception,

rotate the CD-3315 to position

the built-in AM antenna.

• For the best FM reception,

fully extend the telescoping

antenna and swivel it to the

position that produces the

best reception.

• If FM stereo reception gets

noisy while FM MODE is set

to STEREO, set FM MODE to

MONO. The sound is no

longer in stereo, but reception

should improve.

5. Adjust VOLUME to a comfort-

able level.

14-539.fm Page 9 Wednesday, June 30, 1999 1:50 PM

6. Press E-BASS to ON for an

enhanced bass effect. Press it to

OFF for normal bass sound.

7. To turn off the radio, set FUNC-

TION/POWER to TAPE. The

POWER indicator turns off.

14-539.fm Page 10 Wednesday, June 30, 1999 1:50 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reproductor de casetes de Radio Shack

Radio Shack

Radio Shack DX-392 Manual de usuario

Radio Shack

Radio Shack 14-1117 Manual de usuario

Radio Shack

Radio Shack SCP-107 Manual de usuario

Radio Shack

Radio Shack SCP-102 Manual de usuario

Radio Shack

Radio Shack Portable Cassette Recorder Manual de usuario

Radio Shack

Radio Shack AM/FM Auto Reverse Cassette Manual de usuario

Radio Shack

Radio Shack 14-1107A Manual de usuario

Radio Shack

Radio Shack CCR-81 Manual de usuario

Radio Shack

Radio Shack Portable Cassette Recorder Manual de usuario

Radio Shack

Radio Shack TCR-100 Manual de usuario

Radio Shack

Radio Shack AM/FM Cassette Car Stereo Manual de usuario

Radio Shack

Radio Shack CTR-102 Manual de usuario

Radio Shack

Radio Shack Portable Cassette Recorder Manual de usuario

Radio Shack

Radio Shack 14-1132 Manual de usuario

Radio Shack

Radio Shack SCP-107 Manual de usuario

Radio Shack

Radio Shack SCR-65 Manual de usuario

Radio Shack

Radio Shack CTR-80A Manual de usuario

Radio Shack

Radio Shack CCR-82 Manual de usuario

Radio Shack

Radio Shack 14-1117 B Manual de usuario

Radio Shack

Radio Shack CTR-117 Manual de usuario

Radio Shack

Radio Shack 14-1266 Manual de usuario

Radio Shack

Radio Shack 14-1128 Manual de usuario

Radio Shack

Radio Shack SCR-64 Manual de usuario

Radio Shack

Radio Shack CTR-80A Manual de usuario

Manuales populares de Reproductor de casetes de otras marcas

Aiwa

Aiwa TP-VS535 Manual de usuario

Philips

Philips AW 7300 Manual de usuario

Philips

Philips Video Cassette Recorder Manual de usuario

Yamaha

Yamaha MT8X Manual de usuario

Manta

Manta MA408 Manual de usuario

Sherwood

Sherwood Newcastle D-480 Manual de usuario

Tascam

Tascam 122MKIII Guía

GPO

GPO W0162B Manual de usuario

Sony

Sony HST-471 Manual de usuario

Sharp

Sharp JC-AV1 Manual de usuario

Pioneer

Pioneer CT-W103 Manual de usuario

Aiwa

Aiwa HS-JX899 Manual de usuario

Sony

Sony TC-K615S Manual de usuario

Sony

Sony CFS-B15 - Am/fm Stereo Cassette Recorder Manual de usuario

Sony

Sony WMFS220 - Portable Sports AM/FM Cassette... Manual de usuario

Aiwa

Aiwa HS-TA21 Manual de usuario

Sanyo

Sanyo MCD-ZX700F Manual de usuario

Aiwa

Aiwa CS-P77 Manual de usuario
