Cat. No. 43-732

OWNER’S MANUAL

Please read before using this equipment.

TAD-732

900 MHz Digital Answering System

with 20-Channel Cordless Telephone

43-732.fm Page 1 Friday, August 13, 1999 1:42 PM

RadioShack is a registered trademark used by Tandy Corporation.

FEATURES

Your RadioShack TAD-732 900 MHz

Digital Answering System uses ad-

vanced cordless telephone technology

to give you superior audio quality. Its

cordless operation lets you move freely

around your home or office.

The TAD-732 stores all messages on a

computer chip. This gives you better

performance than tape-based answer-

ing machines. For example, you can de-

lete an individual message while saving

the rest. Because your TAD is fully digi-

tal, there are no tapes to bother with and

no tape mechanisms to wear out.

You can operate the TAD-732 remotely

from a touch-tone phone, even if it is not

turned on.

TAD Features

Date/Time Stamp — records the day

and time each message was recorded.

Two User Mailboxes and a Message

Center — stores messages (each up to

60 seconds long) in one of the user mail-

boxes or in the general message center.

Volume Control — lets you adjust the

volume of incoming message playback.

Pre-Recorded Message — gives you

the option of using the TAD-732’s exist-

ing outgoing message or recording your

own (up to 60 seconds long).

Announce-Only — lets you play an an-

nouncement for callers to hear, without

recording their messages.

LED Message Counter — shows the

number of messages the TAD has re-

corded.

Remote Operation — lets you use a

touch-tone phone (or rotary phone and

pocket tone dialer) to operate the TAD

while you are away from your home or

office.

Remote Answer-On — lets you turn on

the TAD from a remote location even

when it is not set to answer calls.

Programmable Remote Operation Se-

curity Code — you can set a two-digit

security code for remote operation.

Call Screening — lets you listen as a

caller leaves a message so you can de-

cide whether or not to answer the call.

Memo Recording — lets you leave

messages for yourself or others in your

home or office.

Adjustable Ring Number — lets you

set the TAD to answer after four or sev-

en rings.

Toll-Saver — lets you avoid unneces-

sary long-distance charges when you

call by long distance to check your mes-

sages.

43-732.fm Page 2 Friday, August 13, 1999 1:42 PM

ANSWER Button — lets you turn the

TAD on or off without disconnecting it.

Phone Pick-U

Detection — stops re-

cording when you pick up any phone on

the same line as the TAD.

Telephone Features

900 MHz O

eration — provides better

sound and less interference than many

other cordless phones.

20 Channels — automatically selects a

clear channel when you make or answer

a call. You can also manually change

channels during a call.

Securit

Access-Protection Code —

helps prevent other cordless phones

from using your phone line while the

handset is off the base.

9-Number Memor

Dialin

— lets you

store up to 9 phone numbers in memory

for easy dialing.

e —lets you send a paging signal

from the base to the handset to page

someone or locate the handset when it is

away from the base.

Flash — sends an electronic switch-

hook signal for use with special phone

services such as Call Waiting.

Redial — lets you quickly dial the last

number dialed.

Mute — prevents the person on the oth-

er end of the phone line from hearing

your conversation with someone in the

room.

Tone or Pulse Dialin

— lets you use

your phone with either type of dialing.

Headset Jack — lets you connect an

optional headset (available at your local

RadioShack store) for hands-free con-

venience.

Detachable Belt Cli

— lets you hang

the handset on your belt for easy porta-

bility.

Hearin

Aid Com

atible — lets you

use this telephone with hearing aids that

have a T (telephone) switch.

This symbol is intended to alert you to

the presence of uninsulated danger-

ous voltage within the product’s enclo-

sure that might be of sufficient

magnitude to constitute a risk of elec-

tric shock. Do not open the product’s

case.

This symbol is intended to inform you

that important operating and mainte-

nance instructions are included in the

literature accompanying this product.

RISK OF ELECTRIC SHOCK.

DO NOT OPEN.

CAUTION: TO REDUCE THE RISK OF

ELECTRIC SHOCK, DO NOT REMOVE

COVER OR BACK. NO USER-SERVICE-

ABLE PARTS INSIDE. REFER SERVIC-

ING TO QUALIFIED PERSONNEL.

Warnin

: To prevent fire or shock

hazard, do not expose this product

to rain or moisture.

CAUTION

43-732.fm Page 3 Friday, August 13, 1999 1:42 PM

This telephone device has been tested

and found to comply with all applicable

UL and FCC standards.

We recommend you record the TAD’s

serial number here. The number is on

the bottom of the base.

Serial Number ________________

Important: Cordless phones such as

this one require AC power to operate.

When AC power is off, you cannot dial

out or receive incoming calls using your

TAD-732. For this reason, the TAD-732

should not be your only telephone. To

be safe, you should also have a phone

that does not require AC power to oper-

ate (not a cordless phone) so you can

still make and receive calls if there is an

AC power failure.

READ THIS BEFORE

INSTALLATION

Your TAD-732 conforms to federal regu-

lations, and you can connect it to most

telephone lines. However, each device

you connect to the telephone line draws

power from the telephone line. We refer

to this power draw as the device’s

ringer

equivalence number

, or REN. The REN

is on the label on the back of the base.

If you are using more than one phone or

other device on the line, add up all the

RENs. If the total is more than five, your

phone might not ring and your answer-

ing system might not answer. In rural ar-

eas, a total REN of three might impair

ringer operation. If ringer operation is

impaired, remove a device from the line.

FCC STATEMENT

Your TAD-732 complies with Part 68 of

FCC Rules

. You must, upon request,

provide the FCC Registration Number

and the REN to your phone company.

These numbers are on the label on the

back of the base.

You must not connect your phone to any

of the following:

• coin-operated systems

• party-line systems

• most electronic key phone systems

Note: Your telephone operates on stan-

dard radio frequencies, as allocated by

the FCC. Even though the security

access-protection code prevents unau-

thorized use of your phone line, it is pos-

sible for other radio units operating on

similar frequencies within a certain area

to unintentionally intercept your conver-

sations and/or cause interference. This

lack of privacy can occur with any cord-

less phone.

43-732.fm Page 4 Friday, August 13, 1999 1:42 PM

CONTENTS

Preparation .............................................................................................................. 7

Selecting a Location ........................................................................................... 7

Installing the Handset’s Antenna ........................................................................ 7

Installing the Phone ............................................................................................ 8

Placing the Base on a Desk Top .................................................................. 8

Mounting the Base on a Wall Plate .............................................................. 9

Mounting the Base Directly on the Wall ..................................................... 10

Connecting and Charging the Handset Battery Pack ....................................... 12

Setting the Dialing Mode .................................................................................. 14

Turning the Ringers Off or On .......................................................................... 14

Setting the Number of Rings ............................................................................ 15

Setting the Day and Time ................................................................................. 15

With the Handset ....................................................................................... 15

With the Base ............................................................................................ 16

Telephone Operation ............................................................................................ 17

Making and Receiving a Call ............................................................................ 17

Setting the Handset’s Volume .......................................................................... 17

Changing the Channel ...................................................................................... 17

Using Redial ..................................................................................................... 18

Using Flash ...................................................................................................... 18

Using Mute ....................................................................................................... 18

Using Tone Services on a Pulse Line ............................................................... 19

Using Page........................................................................................................ 19

Memory Dialing ................................................................................................ 19

Storing a Number in Memory ..................................................................... 19

Entering a Pause ....................................................................................... 20

Dialing a Stored Number ........................................................................... 20

Chain-Dialing Service Numbers ................................................................. 20

Testing Stored Emergency Numbers ......................................................... 20

Using an Optional Headset .............................................................................. 21

Removing the Belt Clip ..................................................................................... 21

TAD Operation ....................................................................................................... 22

Setting the TAD to Answer Calls ...................................................................... 22

Using the Mailboxes ......................................................................................... 22

Recording an Outgoing Message ..................................................................... 22

Using the Handset ..................................................................................... 23

Deleting an Outgoing Message ................................................................. 23

Using the Announce-Only Feature ................................................................... 24

Screening Calls ................................................................................................ 24

Adjusting the TAD’s Volume ............................................................................. 24

43-732.fm Page 5 Friday, August 13, 1999 1:42 PM

Recording Incoming Messages ........................................................................ 25

Recording a Memo ........................................................................................... 25

Using the Handset ..................................................................................... 25

Playing Messages ............................................................................................ 27

Deleting Messages ........................................................................................... 28

Changing the Remote Operation Security Code .............................................. 28

Remote Operation ................................................................................................. 29

Using Toll-Saver ............................................................................................... 29

Using Remote Answer-On ................................................................................ 29

Using Remote Commands ............................................................................... 29

Remote Commands ................................................................................... 30

Troubleshooting .................................................................................................... 31

Care and Maintenance .......................................................................................... 32

Replacing the Battery Pack .............................................................................. 33

The FCC Wants You to Know ........................................................................... 34

Lightning ........................................................................................................... 34

43-732.fm Page 6 Friday, August 13, 1999 1:42 PM

PREPARATION

SELECTING A LOCATION

You can place the phone on a desk top

or table, mount it on a standard wall

plate, or mount it directly on the wall. Se-

lect a location that is:

• near an AC outlet

• near a telephone line jack

• out of the way of normal activities

• away from electrical machinery,

electrical appliances, metal walls or

filing cabinets, wireless intercoms,

alarms, and room monitors

The base’s location affects the phone’s

range. If you have a choice of several lo-

cations, try each to see which provides

the best performance.

Caution: The supplied AC adapter was

designed specifically for your TAD-732.

Use only the supplied adapter.

Notes:

• Your telephone connects directly to

a modular telephone line jack. If

your phone line jack is not a modu-

lar jack, you can update the wiring

yourself, using jacks and adapters

available at your local RadioShack

store. Or, you can let the phone

company update the wiring for you.

• The USOC number of the jack to be

installed is RJ11C (RJ11W if you

want to mount it on a wall plate).

INSTALLING THE

HANDSET’S ANTENNA

Screw the antenna

into the hole at the top

of the handset.

43-732.fm Page 7 Friday, August 13, 1999 1:42 PM

INSTALLING THE PHONE

Placing the Base on a

Desk Top

1. Remove the mounting bracket by

holding in both tabs and gently pull-

ing out the wide end of the bracket.

2. Plug one end of the supplied long

modular cord into the telephone jack

on the back of the base.

3. Plug the modular cord’s other end

into a modular phone line jack.

4. Insert the supplied AC adapter’s

barrel plug into the DC 9V jack on

the back of the base.

5. Route the adapter’s cord through

the strain relief slot on the back of

the base.

6. Insert the tabs on the narrow end of

the bracket into the inner pair of

slots near the bottom of the base as

shown and snap the tabs at the wide

end of the bracket into place.

43-732.fm Page 8 Friday, August 13, 1999 1:42 PM

7. Plug the adapter into a standard AC

outlet. The TAD-732 beeps and 00

appears.

8. Raise the base’s antenna to a verti-

cal position.

Mounting the Base on a Wall

Plate

1. Remove the mounting bracket by

holding in both tabs and gently pull-

ing out the wide end of the bracket.

2. Plug one end of the supplied short

modular cord into the telephone jack

on the back of the base.

3. Insert the supplied AC adapter’s

barrel plug into the DC 9V jack on

the back of the base.

4. Route the modular cord through the

left groove on the bottom of the

base and the adapter cord through

the groove below the strain relief

slot.

Strain

Relief

Slot

43-732.fm Page 9 Friday, August 13, 1999 1:42 PM

5. Route the end of the modular cord

through the hole in the bracket, and

insert the tabs on the narrow end of

the bracket into the inner pair of

slots near the top of the base as

shown.

6. Snap the tabs at the wide end of the

bracket into place.

7. Plug the modular cord into the wall

plate jack. Align the base’s keyhole

slots with the wall plate studs and

slide the base downward to secure

it.

8. Plug the AC adapter into a standard

AC outlet. The TAD-732 beeps and

00 appears.

9. Raise the base’s antenna to a verti-

cal position.

Mounting the Base Directly on

the Wall

To mount the base directly on the wall,

you need two screws (not supplied) with

heads that fit into the keyhole slots on

the bottom of the base.

43-732.fm Page 10 Friday, August 13, 1999 1:42 PM

Tabla de contenidos

Otros manuales de Contestador automático de Radio Shack

Radio Shack

Radio Shack 14 Minute Manual de usuario

Radio Shack

Radio Shack TAD-759 Manual de usuario

Radio Shack

Radio Shack 43-3880 Manual de usuario

Radio Shack

Radio Shack Digital Answering System with Big Button Trim... Manual de usuario

Radio Shack

Radio Shack TAD-1024 Manual de usuario

Radio Shack

Radio Shack 900MHz Manual de usuario

Radio Shack

Radio Shack 43-3803 Manual de usuario

Radio Shack

Radio Shack TAD-222 Manual de usuario

Radio Shack

Radio Shack 900MHz Manual de usuario

Radio Shack

Radio Shack TAD-1006 Manual de usuario

Radio Shack

Radio Shack Digital Telephone Answering Device Manual de usuario

Radio Shack

Radio Shack TAD-1007 Manual de usuario

Radio Shack

Radio Shack TAD-1009 Manual de usuario

Radio Shack

Radio Shack TAD 3809 Manual de usuario

Radio Shack

Radio Shack TAD-779 Manual de usuario

Radio Shack

Radio Shack TAD-739 Manual de usuario

Radio Shack

Radio Shack TAD-716 Manual de usuario

Radio Shack

Radio Shack TAD-3806 Manual de usuario

Radio Shack

Radio Shack TAD-764 Manual de usuario

Radio Shack

Radio Shack TAD-799 Manual de usuario

Radio Shack

Radio Shack TAD-1029 Manual de usuario

Radio Shack

Radio Shack TAD-277 Manual de usuario

Radio Shack

Radio Shack TAD-1005 Manual de usuario

Radio Shack

Radio Shack 43-3801 Manual de usuario

Manuales populares de Contestador automático de otras marcas

AT&T

AT&T 2455 Manual de usuario

Panasonic

Panasonic KX-TG2583CB Manual de usuario

Panasonic

Panasonic KX-TGE820E Manual de usuario

BellSouth

BellSouth GH9488 Guía de seguridad

GE 2-9985 Manual de usuario

Panasonic

Panasonic KX-TG2631 Manual de usuario

Panasonic

Panasonic KX-TCD961CXB Manual de usuario

Krown

Krown PortaPrinter 2000STD Manual de usuario

AT&T

AT&T 1717 Manual de usuario

Alcatel

Alcatel TEMPORIS 55-CE Manual de usuario

AT&T

AT&T E2562 Manual de usuario

Telstra

Telstra Monitor 420 Manual de usuario

Kortex

Kortex IAM V90 Manual de usuario

Panasonic

Panasonic EASA-PHONE KX-T1451 Manual de usuario

Philips

Philips VOIP8551B/05 Manual de usuario

Topcom

Topcom LUCCA Answering Machine Manual de usuario

Panasonic

Panasonic KX-TGM420 Manual de usuario

Panasonic

Panasonic KX-TCD320E Manual de usuario
