TX3000

1 / 8UserManual Rev. 1.0-02/12/02

1. Introduction

ThismanualdescribestheTX3000SS,aradiotransmitterforfrequencymodulation

audiobroadcastiong.

The TX3000SS is a modular device, built up of components assembled in a 19”

rack,completewithelectrical and RF wiring.

Thismanualshallbereadtogetherwiththemanualsofthedifferentcomponents,that

areattached herewith.

Detailsaboutwarranty,safety,workingpriciplesandtechnicalspecificationsaregiven

inthe single manuals.

2. Configurations

2.1 General

Theessentialcomponentsof the TX3000SS are:

•1 PTX100LCD/s Exciter;

•1 PJ3000MAmplifier:

•3 PJ1000M LCD amplifiers;

•1HC3hybridcoupler.

Different configurations of the transmitter are available. The costumer will choose

theonethatbestfits his need in terms, e.g. of redudancyor telecontrol capabilities.

Thischapter describes the differentconfigurationstheTX3000SScanhave. Please

notethattransmitterslayoutsgivenhereinarereferenceones;theheightoftheracks

and the disposition of the modules may vary and will be specified at the time of

placing the order. The model names of the different transmitters refer to the

componentsincluded.

TX3000

2 / 8 UserManualRev.1.0- 02/12/02

2.2 TX3KSSRD/RDS

This version is the most complete version of the TX500SS. With respect to the

“essential”components,it features:

•Double exciters (2 PTX100LCD/s);

•Double RDS encoders (2 TRDS4001);

•Automaticchange-over(SCM1+1LCD);

•Telemetryunit(TLC300);

Ofcourse,it also includes the amplifier (PJ3000M).

TX3000

3 / 8UserManual Rev. 1.0-02/12/02

2.3 TX3KSSRD

Thisversionofthetransmittergivestothecustomerthe benefitofredundant exciters

andremotecontrol.Itis composed of:

•Double exciters (2 PTX100LCD/s);

•Automaticchange-over(SCM1+1LCD);

•Telemetryunit(TLC300);

•Amplifier(PJ3000M).

TX3000

4 / 8 UserManualRev.1.0- 02/12/02

2.4 TX3KSSD/RDS

ThisversionofthetransmittergivesredundantexcitersandRDScoders.

Itconsists of:

•Double exciters (2 PTX100LCD/s);

•Double RDS encoders (2 TRDS4001);

•Automaticchange-over(SCM1+1LCD);

•Amplifier(PJ3000M).

TX3000

5 / 8UserManual Rev. 1.0-02/12/02

2.5 TX3KSSD

Thisversion is composed of:

•Doubleexciters (2 PTX30LCD/s);

•Automaticchange-over(SCM1+1LCD);

•Amplifier(PJ3000M).

TX3000

6 / 8 UserManualRev.1.0- 02/12/02

2.6 TX3KSSR/RDS

Thisversionofthetransmitteristele-controllableandincludestheRDScoder.

Itis composed of:

•Exciter(PTX30LCD/s);

•RDS encoder (TRDS4001);

•Telemetryunit(TLC300);

•Amplifier(PJ3000M).
