Quell Baery Operated Carbon Monoxide Alarm
EN50291-1 : 2010
License No. KM98848
Part Number: 130415 Model: PD04
USER GUIDE
Quell®is a registered trade ark of Chubb Fire & Security Pty Ltd
Copyright © 2012 Chubb Fire & Security Pty Ltd. All rights reserved.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 1
1
Contents
1. What is Carbon Monoxide (CO)?
2. Important Sa ety In ormaon
3. Switching on Your CO Alarm
4. Installaon Instrucons – Recommended Locaons
5. Installaon Instrucons – Mounng
6. Using your CO Alarm
Warning Signals, Tesng / Re-seng, LCD read-outs , Peak Level Display
7. Replacement Baeries / End-o -Li e
8. What To Do If Your Alarm Sounds
9. Maintenance o your Alarm
10. Troubleshoong
11. Product Specificaons
12. Warnings and Important Noces
13. Warranty In ormaon
14. Environmental Protecon
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 1
2
Model: PD04
Green,
Power LED
Red,
Alarm LED
Test / Reset
Button
Peak Level Button
Digital Display
Alarm
Move to
Fresh Air
Operate
Test/Reset
Peak Level
Carbon Monoxide Alarm
Model: PD04
PPM of CO displayed
LB= Low Battery
End= End of Unit Life
Product Features and Speci caons
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 2
3
1. What is Carbon Monoxide?
Carbon monoxide (CO) is a highly poisonous gas with no taste, colour or smell.
Potenal Sources of CO
•Wood-burning stoves
•Gas boilers and res
•Gas stoves
•Oil and coal burning appliances
•Portable gas heaters
•Blocked flues and chimneys
•Fumes from integral garages
•Barbecues
THIS CO ALARM IS NOT A SUBSTITUTE FOR THE CORRECT
MAINTENANCE OF YOUR APPLIANCES.
Carbon monoxide can be produced from poorly burning appliances
or from blocked flues and chimneys.
If your alarm has sounded and you have venlated the room the CO
may have dispersed before help arrives. It is crucial that the source
of CO is determined and appropriate maintenance carried out.
Carbon monoxide is a cumulave poison. Longterm exposure to low levels may cause symptoms.
This Quell alarm is me-weighted – the higher the level o CO, the sooner it will alarm.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 3
4
2. Further informaon for Caravan and Boat Owners
The ollowing can lead to carbon monoxide being produced:
• Using LPG cooking appliances or space heang
• Leaving LPG appliances on overnight
• Barbecues within the boat cabin or near a caravan door (e.g. under an awning)
To be sa e, know the possible sources o CO in your home. Keep uel burning appliances,
chimneys and vents in good working condion. Learn the early symptoms o exposure, and i
you suspect CO poisoning, move outside into resh air and get emergency help. Your first line o
de ence is an annual inspecon and regular maintenance o your appliances. Contact a licensed
contractor or call your local ulity company or assistance.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 4
5
2. Alarm levels as de ned by European Norm EN50291-2010*
The table below shows the response mes at which your CO alarm will sound:
CO Advice and Informaon
The table below shows the physiological effects o exposure to increasing concentraons o CO:
Parts per Million (PPM) of CO Time unl Alarm
50 60 – 90 minutes
100 10 – 40 minutes
300 Must alarm in less than 3 minutes
Parts per Million (PPM) Effects on Adults
100 Slight headache, nausea, ague (flu-like symptoms)
200 Dizziness and headache within 2 – 3 hours
400 Nausea, rontal headache, drowsiness, con usion and rapid heart rate.
Risk to li e aer over 3 hours o exposure
800 Severe headaches, convulsions, vital organ ailures. Death possible within
2 – 3 hours
* EN50291-2010 is a European Standard or "Electrical apparatus or the detecon o carbon monoxide in domesc premises - Part 1: Test
methods and per ormance requirements"
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 5
6
2. Important Safety Informaon
If you recognise any of the above symptoms consult your Doctor immediately.
Young children, the elderly as well as pets are more suscepble to the dangers of CO.
Your Quell CO alarm is designed to detect CO gas. It is not designed to detect smoke,
re or other gas such as natural gas.
Ideal for use in domesc premises such as bedrooms, living areas, and caravans,
motor homes and boats.
The advice and informaon on page 5 are intended as a general guide only.
Sensivity and symptoms may vary with the individual depending for instance on
age, medical history and pre-exisng medical condions. Individuals with certain
speci c medical condions may require an alarm that operates at lower levels of
concentraon. You should consult a quali ed medical praconer for further
guidance.
IMPORTANT: Ensure that all family members are familiar with the symptoms of CO
poisoning and how your alarm works.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 6
7
3. Switching on Your CO Alarm
NOTE: Your CO alarm must be installed by a competent person using the guidance that ollows:
1. Remove the baeries rom the pack and insert them into the baery compartment. Make
sure that you fit the baeries correctly to the polarity markings (+ or -) shown within the
baery compartment. I correctly installed, the alarm will give a short beep.
2. To test the alarm, press the test buon. The alarm will sound ully or 10 seconds. This
confirms that the alarm is powered up and working.
3. The LCD screen will show “---“ and then “888” be ore seling at “0”
4. Check that the green LED flashes at 30 second intervals to show that the alarm has power.
This is easiest to see in a dark area, or with lights switched off.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 7
8
4. Installaon Instrucons – Recommended Locaons
*It is recommended that at least one Quell carbon monoxide alarm is installed on each level of the home.
Recommended Locaons Not Recommended
Place the alarm at least 2 metres rom uel
burning appliances, and not more than 4
metres away
Do not place closer than 2 metres rom uel
burning appliances
Away rom draughts, such as doors and
windows
Do not wall-mount close to obstrucons
(e.g. behind curtains, shelving or urniture)
Within hearing distance o bedrooms*
I heang appliance is in the bedroom place
the alarm at sleeping height
Do not fit in dusty, dirty or greasy areas
(e.g. garages or workshops)
I wall-mounng, install at eye-level (approx
1.5m), and at least 30cm rom adjoining walls
or ceiling
Do not wall-mount within 30cm o the ceiling
as this is a “dead air” space
I ree-standing, the unit should be placed
no more than 1 metre rom the ground
(to avoid permanent damage in case
accidently knocked)
Avoid areas subject to high humidity (e.g.,
bathrooms), cold (< 0°C) or hot (>40°C) areas
and away rom sinks
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 8
Smoke Alarms for
Minimum Protection
Smoke Alarms and Carbon
Monoxide Alarms for
Maximum Protection
9
4. Installaon Instrucons – Recommended Locaons
Map showing the recommended locaons or your Quell carbon monoxide
alarms, smoke alarms, fire exnguishers and fire blankets.
2530-7205-04(130415)_quell:_ 2016.2.17 11:49 AM Page 9
