Quectel L80 Manual de usuario

L80&L80-R&L86&LC86L

EVB User Guide

GNSS Module Series

Version: 2.0

Date: 2020-12-22

Status: Released

www.quectel.com

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 1 / 30

Our aim is to provide customers with timely and comprehensive service. For any assistance,

please contact our company headquarters:

Quectel Wireless Solutions Co., Ltd.

Building 5, Shanghai Business Park Phase III (Area B), No.1016 Tianlin Road, Minhang District, Shanghai

200233, China

Tel: +86 21 5108 6236

Email: [email protected]om

Or our local office. For more information, please visit:

http://www.quectel.com/support/sales.htm.

For technical support, or to report documentation errors, please visit:

http://www.quectel.com/support/technical.htm

Or email to support@quectel.com.

General Notes

Quectel offers the information as a service to its customers. The information provided is based upon

customers’ requirements. Quectel makes every effort to ensure the quality of the information it makes

available. Quectel does not make any warranty as to the information contained herein, and does not

accept any liability for any injury, loss or damage of any kind incurred by use of or reliance upon the

information.All information supplied herein is subject to change without prior notice.

Disclaimer

While Quectel has made efforts to ensure that the functions and features under development are free

from errors, it is possible that these functions and features could contain errors, inaccuracies and

omissions. Unless otherwise provided by valid agreement, Quectel makes no warranties of any kind,

implied or express, with respect to the use of features and functions under development. To the maximum

extent permitted by law, Quectel excludes all liability for any loss or damage suffered in connection with

the use of the functions and features under development, regardless of whether such loss or damage

may have been foreseeable.

Duty of Confidentiality

The Receiving Party shall keep confidential all documentation and information provided by Quectel,

except when the specific permission has been granted by Quectel. The Receiving Party shall not access

or use Quectel’s documentation and information for any purpose except as expressly provided herein.

Furthermore, the Receiving Party shall not disclose any of the Quectel's documentation and information

to any third party without the prior written consent by Quectel. For any noncompliance to the above

requirements, unauthorized use, or other illegal or malicious use of the documentation and information,

Quectel will reserve the right to take legal action.

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 2 / 30

The information contained here is proprietary technical information of Quectel. Transmitting, reproducing,

disseminating and editing this document as well as using the content without permission are forbidden.

Offenders will be held liable for payment of damages.All rights are reserved in the event of a patent grant

or registration of a utility model or design.

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 3 / 30

About the Document

Revision History

Version

Date

Author

Description

1.0

2014-08-18

Bond SUN

Initial

2.0

2020-12-22

Ronnie HU

1. Incorporated the information of L80, L80-R and L86

EVB user guides (created separately years ago) into

this manual.

2. Added the applicable module LC86L.

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 4 / 30

Contents

About the Document...................................................................................................................................3

Contents.......................................................................................................................................................4

Table Index...................................................................................................................................................5

Figure Index.................................................................................................................................................6

1Introduction..........................................................................................................................................7

1.1. Safety Information.......................................................................................................................7

2General Overview.................................................................................................................................8

2.1. Top View......................................................................................................................................8

2.2. EVB KitAccessories ...................................................................................................................9

2.3. EVB and Accessories Assembly...............................................................................................10

3EVB Interfaces....................................................................................................................................12

3.1. Micro-USB Interface..................................................................................................................12

3.2. Antenna Interface......................................................................................................................12

3.3. Switches and Buttons ...............................................................................................................13

3.4. Status Indication LEDs..............................................................................................................14

3.5. Test Points.................................................................................................................................15

4EVB Operation Procedures...............................................................................................................17

4.1. Communication Through Micro USB Interface.........................................................................17

4.2. Firmware Upgrade....................................................................................................................18

5Using PowerGPS................................................................................................................................20

5.1. COM and Baud Rate Setting....................................................................................................20

5.1.1. Interface Explained ........................................................................................................21

5.2. PMTK Command Sending........................................................................................................22

5.3. Automatic TTFF Testing............................................................................................................23

6Appendix A References.....................................................................................................................28

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 5 / 30

Table Index

Table 1:Available Interfaces ........................................................................................................................8

Table 2: List of Accessories........................................................................................................................ 10

Table 3: Switches and Buttons...................................................................................................................14

Table 4: Status Indication LEDs.................................................................................................................15

Table 5: Pin Description of Test Points (J401)........................................................................................... 16

Table 6: PowerGPS Interface Explained.................................................................................................... 21

Table 7: Related Documents...................................................................................................................... 28

Table 8: Terms and Abbreviations..............................................................................................................28

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 6 / 30

Figure Index

Figure 1: Top View of the EVB.....................................................................................................................8

Figure 2: EVB Kit Accessories .....................................................................................................................9

Figure 3: EVB and Accessories Assembly..................................................................................................11

Figure 4: Micro-USB Connector.................................................................................................................12

Figure 5: Antenna Connector..................................................................................................................... 13

Figure 6: Switches and Buttons................................................................................................................. 13

Figure 7: Status Indication LEDs................................................................................................................14

Figure 8: GNSS EVB Test Points (J401).................................................................................................... 15

Figure 9: USB Ports ...................................................................................................................................17

Figure 10: COM Port Setting Interface of QCOM......................................................................................17

Figure 11: FlashTool Configurations for Firmware Upgrade...................................................................... 18

Figure 12: PowerGPS Interface (Not Connected)..................................................................................... 20

Figure 13: PowerGPS Interface (Connected)............................................................................................ 21

Figure 14: PMTK Command Sending via PowerGPS............................................................................... 23

Figure 15: Static TTFF Testing via PowerGPS ..........................................................................................24

Figure 16: Choose Reference Location..................................................................................................... 24

Figure 17: Click Use Mean Position...........................................................................................................25

Figure 18: Click Configuration....................................................................................................................25

Figure 19: Set TTFF Time-out (Sec).......................................................................................................... 26

Figure 20: Click Run/Stop Button............................................................................................................... 27

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 7 / 30

1Introduction

In this document you can find the information on how to use the evaluation board (EVB) to develop and

test Quectel L80, L80-R, L86, and LC86L modules.

1.1. Safety Information

The following safety precautions must be observed during all phases of operation, such as usage, service

or repair of any terminal incorporating Quectel L80, L80-R, L86 and LC86L modules. Manufacturers of the

terminal should distribute the following safety information to users and operating personnel and include

these guidelines into all manuals supplied with the product. Otherwise, Quectel assumes no liability for

customers’ failure to comply with these precautions.

Ensure that the use of the product conforms to the national safety and

environmental regulations, and is allowed to be used in the country and in the

required environment.

Keep away from explosive and flammable materials. The use of electronic

products in extreme power supply conditions and locations with potentially

explosive atmospheres may cause fire and explosion hazards.

The product must be powered by a stable voltage source. Additionally, the wiring

must conform to security and fire prevention regulations.

Proper ESD handling procedures must be applied throughout the mounting,

handling and operation of any application that incorporates the module to avoid

ESD damages.

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 8 / 30

2General Overview

2.1. Top View

The following figure illustrates the top view of the EVB.

Figure 1: Top View of the EVB

Table 1: Available Interfaces

SN.

Reference Number

Description

J403

Antenna connector 1)

D303, D304, D305, D306,

D307

Indication LEDs 2) (see Chapter 3.4 for details)

GNSS Module Series

L80&L80-R&L86&LC86L EVB User Guide

L80&L80-R&L86&LC86L_EVB_User_Guide 9 / 30

1. 1) The antenna connector is invalid for the L80-R module, as the module does not support an external

antenna.

2. 2) The L80-R does not support active antenna detection interface, so the D307 (AADET_N) is invalid for

this module as well. Additionally, D305 and D306 are not supported by any of the applicable modules.

3. 3) The L80 and L80-R modules do not support the FORCE_ON interface, so the FORCE_ON button is

invalid for those modules.

2.2. EVB Kit Accessories

Figure 2: EVB Kit Accessories

J401

Test points

U404

The module

S201

USB ←→ SD Card (USB/SD Card alternation switch)

S101

POWER switch

J103

Micro-USB connector

S302

FORCE_ON button 3)

S301

RESET button

NOTES
